ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205

Certification
Good quality Stainless Steel Elbow for sales
Good quality Stainless Steel Elbow for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner .

—— Thailand ---Dave Mulroy

ASTM A182 F55 Super Duplex Flange ,Good quality , we like that ! And delivery time in time also ,very professional.

—— USA ---Alfaro

I'm Online Chat Now

ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205

China ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205 supplier
ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205 supplier ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205 supplier ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205 supplier ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205 supplier ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205 supplier

Large Image :  ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205

Product Details:

Place of Origin: China/Japan/Germany
Brand Name: TOBO/TPCO/TISCO/VALIN/METAL
Certification: ISO/PED/TUV/SGS/LR/BV
Model Number: ASTM A790 UNS S31803 S32205

Payment & Shipping Terms:

Minimum Order Quantity: 0.5-1 tons
Price: negotiable
Packaging Details: in plastic bags then in bundles
Delivery Time: According to the qty
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 6000TONS/MONTH
Contact Now
Detailed Product Description
Standard:: ASTM A790 Color: White Silver Gold
Types:: Duplex Stainless Steel Pipe Material Grade: UNS S31803 S32205
Outer Diameter: 6mm-710mm

ASTM A790 Standard for Duplex Stainless Steel Pipe UNS S31803 S32205



Standards: ASTM/ASME A789/SA789, A790/SA790,A450,A530

Material: UNS S31803(Cr22Ni5Mo3/1.4462)/2205,UNS S32750(1.4410),UNS S31500(Cr18NiMo3Si2),

UNS32760(1.4501)



ASTM A790 covers seamless and straight-seam welded ferritic/austenitic duplex stainless steel pipe for general corrosive service, with particular emphasis on resistance to stress corrosion cracking. The pipe shall be made by the seamless or an automatic welding process, with no addition of filler metal in the welding operation. Heat analysis shall be made to determine the percentages of the elements specified. Tension tests, hardening tests, flattening tests, hydrostatic test and nondestructive electric tests shall be made to conform to the specified requirements.

Chemical Composition

Grade

C

 max

Si

max

Mn

max

P

max

S

max

Cr

Ni

Mo

N

UNS S32750

0.030

0.8

1.2

0.030

0.015

24.0-26.0

6.0-8.0

3.0-5.0

0.24-0.32

UNS S31803

0.030

1.0

2.0

0.020

0.020

21.0-23.0

4.5-6.5

2.5-3.5

0.08-0.20

UNS S31500

0.030

1.0

1.2-2.0

0.030

0.030

18.0-19.0

4.5-5.5

2.5-3.5

0.05-0.10



 Physical Properties

Grade

Y.S.MPa min

T.S.Mpa min

Elongation %

Hardness HRC

UNS S32750

550

800

15

20

UNS S31803

450

620

25

20

UNS S31500

440

630

30

20



Duplex Stainless Steel Pipe Application:

Chemical processing, Transport and Storage.

Oil and gas exploration and offshore rigs.

Oil and gas refining.

Marine environments.

Pollution control equipment.

Pulp and paper manufacturing

Chemical process Plant



Some of the quality tests carried out by us includes:

Corrosion Test

Conducted only when specially requested by the client

Chemical Analysis

Test done as per required quality standards

Destructive / Mechanical Testing

Tensile | Hardness | Flattening | Flare | Flange

Reverse-bend and Re. flat tests

Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end

Eddy Current Testing

Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System

Hydrostatic Testing

100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s .

Air Under Pressure Test

To check any evidence of air leakage

Visual Inspection

After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections



Supplementary Testing : Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. The tests conducted under this include:

  • Eddy Current Testing
  • O.P Testing

Radiography Testing

  • Corrosion Testing
  • Micro Testing

Macro Testing

  • IGC Testing
  • Ultrasonic testing

Liquid Penetrate testing
