Place of Origin: | China/Japan/Germany |
---|---|
Brand Name: | TOBO/TPCO/TISCO/VALIN/METAL |
Certification: | ISO/PED/TUV/SGS/LR/BV |
Model Number: | HD201370080807 |
Minimum Order Quantity: | 1 ton |
Price: | Depending on quantity |
Packaging Details: | seaworthy packing or as the clients' requirement |
Delivery Time: | 5-30 days depending on quantity |
Payment Terms: | L/C, T/T |
Supply Ability: | 10000 Tons per month |
Product Name: | Stainless Steel Cold Drawn Flat Bar | Product Type: | Flat Bar |
---|---|---|---|
Standard: | JIS,AISI,ASTM,GB,DIN,EN | Grade: | 300 Series |
Type: | Flat | Dimensions: | 3x20-20x200mm |
Special Use: | Valve Steels | Application: | Stainless Steel Bar Applies To Petroleum, Chemical Industry, Electric |
Highlight: | Stainless Steel Bright Bars,Stainless Steel Flat Bar |
DN 441 Stainless Steel Flat Bar Hot Rolled / Cold Drawn HD201370080807 JIS, AISI, ASTM, GB,DIN, EN
Function & Characteristic
Standard: JIS,AISI,ASTM,DIN,EN
Dimensions: 3x20-20x200mm
Grade: 300 Series
Place of Origin: Shanghai, China (Mainland)
Brand Name: TOBO Steel
Type: Flat
Application: Stainless steel bar applies to petroleum, chemical industry, electric
Shape: Square
Certification: ISO
Special Use: Valve Steels
Packaging & Delivery
Packaging Details: Export-sea worthy packing with each bundle tied and protected
Delivery Detail: In a week or depend on order quantity
Specifications
High qualtiy !!EN 441 stainless steel flat bar Hot rolled / cold drawn
1.ISO9001: 2013
2. Made in China
Hot rolled and cold drawn stainless steel flat bar
Name |
Stainless Steel Flat Bar |
|||||
Standard |
ASTM A554, A312, A249, A269 and A270 |
|||||
Material Grade |
304,316,201,202, 316L,430 |
|||||
Size Range |
3x20-20x200mm |
|||||
Length |
6m or as customers' request |
|||||
Tolerance |
a) width: +/-0. 15mm |
|||||
b) Thickness: +/- 0.02mm |
||||||
c) Length:+/-4. 5mm - 0mm |
||||||
Surface |
180G, 320G, 400G Satin / Hairline(Matt Finish, Brush, Dull Finish) 400G, 500G, 600G or 800G Mirror finish |
|||||
Test |
Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT |
|||||
Chemical Composition of Material |
Composition Material |
201 |
202 |
304 |
316 |
430 |
C |
≤0.15 |
≤0.15 |
≤0.08 |
≤0.08 |
≤0.12 |
|
Si |
≤1.00 |
≤1.00 |
≤1.00 |
≤1.00 |
≤1.00 |
|
Mn |
5.5-7.5 |
7.5-10 |
≤2.00 |
≤2.00 |
≤1.00 |
|
P |
≤0.06 |
≤0.06 |
≤0.045 |
≤0.045 |
≤0.040 |
|
S |
≤0.03 |
≤0.03 |
≤0.030 |
≤0.030 |
≤0.030 |
|
Cr |
16-18 |
17-19 |
18-20 |
16-18 |
16-18 |
|
Ni |
3.5-5.5 |
4-6 |
8-10.5 |
10-14 |
||
Mo |
2.0-3.0 |
|||||
Mechanical Property |
Material Item |
201 |
202 |
304 |
316 |
|
Tensile Strength |
≥535 |
≥520 |
≥520 |
≥520 |
||
Yield Strength |
≥245 |
≥205 |
≥205 |
≥205 |
||
Extension |
≥30% |
≥30% |
≥35% |
≥35% |
||
Hardness (HV) |
<253<> |
<253<> |
<200<> |
<200<> |
