UNS S32750 UNS S32760 Stainless Steel Tube Tee 8” 12” SCH40S SCH80S ASME B16.9

  • UNS S32750 UNS S32760 Stainless Steel Tube Tee 8” 12” SCH40S SCH80S ASME B16.9
  • UNS S32750 UNS S32760 Stainless Steel Tube Tee 8” 12” SCH40S SCH80S ASME B16.9
  • UNS S32750 UNS S32760 Stainless Steel Tube Tee 8” 12” SCH40S SCH80S ASME B16.9
  • UNS S32750 UNS S32760 Stainless Steel Tube Tee 8” 12” SCH40S SCH80S ASME B16.9
  • UNS S32750 UNS S32760 Stainless Steel Tube Tee 8” 12” SCH40S SCH80S ASME B16.9
Place of Origin CHINA
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number UNS S32750 , UNS S32760
Minimum Order Quantity 2PCS
Price Discussion
Packaging Details PLY-WOODEN CASE OR PALLET
Delivery Time 15 Days
Payment Terms T/T, L/C, Western Union, D/A, D/P
Supply Ability 19000000PCS PER MONTH
Product Details
Material UNS S32750 , UNS S32760 Tee Type Stainless Steel Tee, Pipe Tee , Equal Tee ,reducer Tee.
Size 1/2’’~48’’(Seamless);16’’~72’’(Welded) Wall Thickness Sch5~Sch160\XXS
Highlight

stainless steel pipe tee

,

butt weld tee
Leave a Message
Product Description



UNS S32750 , UNS S32760 Stainless Steel Tee 8” 12” SCH40S SCH80S ASME B16.9





Form:
1/8" NB TO 48" NB. (Seamless & Welded)
Thickness
SCH: 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS & NS available with NACE MR 01-75


Type:
· Equal & unequal tee.

Standard:
· ASME: ANSI B16.9, ANSI B16.28, MSS SP75
· DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
· SGP: JIS B2313
· EN: EN10253-1, EN10253-2
Material:
Stainless Steel : ASTM A403 WP 304/ 304L/ 304H/ 316/ 316L/ 317/ 317L/ 321/ 310/ 347/ 904L/ etc.
Carbon Steel : ASTM A234 WPB / A420 WPL3/ A420 WPL6/ MSS-SP-75 WPHY 42/46/52/56/60/65/70 etc.
Alloy Steel : ASTM A234 WP1/ WP5/ WP9/ WP11/ WP22/ WP91/ etc.
Other materials : Monel, Nickel, Inconel, Hastalloy, Copper, Brass, Bronze, Titanium, Tantalum, Bismuth, Aluminium, High Speed Steel, Zinc, Lead, etc.



Specifications

ASTM A 815 ASME SA-815 WP UNS S32760 tee equal
1.Competitive&credible price.
2.High Quality&Fast Delivery

ASTM A 815 ASME SA-815 WP UNS S32760  tee equal



SuperDuplex stainless like Duplex, is a mixed microstructure of austenite and ferrite (50/50) which has improved strength over ferritic and austenitic steel grades. The main difference is that Superduplex has a higher Molybdenum and Chromium content which gives the material greater corrosion resistance.



Chemical Composition

UNS No

Grade

C

Si

Mn

P

S

Cr

Mo

Ni

N

Other

S32750

2507

0.030

0.80

1.20

0.035

0.020

24.0/26.0

3.0/5.0

6.00/8.00

0.24/0.32

Cu:0.50



UNS No

C

Si

Mn

P

S

Cr

Mo

Ni

N

Other

S32760

0.030

1.00

1.00

0.030

0.010

24.0/26.0

3.0/4.0

6.00/8.00

0.20/0.30

Cu:0.50/1.00
W:0.50/1.00





Tee Type

Equal/Straight tee, Reducing tee, Lateral tee, BW/butt weld tee,

Standard

ASME/ANSI B16.9

Size

1/2'' ~ 48''(Seamless); 16'' ~72''(welded); DN15-DN1200

Wall thickness

Sch5~Sch160XXS

Manufacturing process

Push, Press, Forge, Cast, etc.

Material



Carbon steel

ASTM A234 WPB, WPC;

Stainless steel

304/SUS304/UNS S30400/1.4301

304L/UNS S30403/1.4306;

304H/UNS S30409/1.4948;

309S/UNS S30908/1.4833

309H/UNS S30909;

310S/UNS S31008/1.4845;

310H/UNS S31009;

316/UNS S31600/1.4401;

316Ti/UNS S31635/1.4571;

316H/UNS S31609/1.4436;

316L/UNS S31603/1.4404;

316LN/UNS S31653;

317/UNS S31700;

317L/UNS S31703/1.4438;

321/UNS S32100/1.4541;

321H/UNS S32109;

347/UNS S34700/1.4550;

347H/UNS S34709/1.4912;

348/UNS S34800;

Alloy steel

ASTM A234 WP5/WP9/WP11/WP12/WP22/WP91;

ASTM A860 WPHY42/WPHY52/WPHY60/WPHY65;

ASTM A420 WPL3/WPL6/WPL9;

Duplex steel

ASTM A182 F51/S31803/1.4462;

ASTM A182 F53/S2507/S32750/1.4401;

ASTM A182 F55/S32760/1.4501/Zeron 100;

2205/F60/S32205;

ASTM A182 F44/S31254/254SMO/1.4547;

17-4PH/S17400/1.4542/SUS630/AISI630;

F904L/NO8904/1.4539;

725LN/310MoLN/S31050/1.4466

253MA/S30815/1.4835;

Nickel alloy steel

Alloy 200/Nickel 200/NO2200/2.4066/ASTM B366 WPN;

Alloy 201/Nickel 201/NO2201/2.4068/ASTM B366 WPNL;

Alloy 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC;

Alloy K-500/Monel K-500/NO5500/2.475;

Alloy 600/Inconel 600/NO6600/NS333/2.4816;

Alloy 601/Inconel 601/NO6001/2.4851;

Alloy 625/Inconel 625/NO6625/NS336/2.4856;

Alloy 718/Inconel 718/NO7718/GH169/GH4169/2.4668;

Alloy 800/Incoloy 800/NO8800/1.4876;

Alloy 800H/Incoloy 800H/NO8810/1.4958;

Alloy 800HT/Incoloy 800HT/NO8811/1.4959;

Alloy 825/Incoloy 825/NO8825/2.4858/NS142;

Alloy 925/Incoloy 925/NO9925;

Hastelloy C/Alloy C/NO6003/2.4869/NS333;

Alloy C-276/Hastelloy C-276/N10276/2.4819;

Alloy C-4/Hastelloy C-4/NO6455/NS335/2.4610;

Alloy C-22/Hastelloy C-22/NO6022/2.4602;

Alloy C-2000/Hastelloy C-2000/NO6200/2.4675;

Alloy B/Hastelloy B/NS321/N10001;

Alloy B-2/Hastelloy B-2/N10665/NS322/2.4617;

Alloy B-3/Hastelloy B-3/N10675/2.4600;

Alloy X/Hastelloy X/NO6002/2.4665;

Alloy G-30/Hastelloy G-30/NO6030/2.4603;

Alloy X-750/Inconel X-750/NO7750/GH145/2.4669;

Alloy 20/Carpenter 20Cb3/NO8020/NS312/2.4660;

Alloy 31/NO8031/1.4562;

Alloy 901/NO9901/1.4898;

Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Alloy 926;

Inconel 783/UNS R30783;

NAS 254NM/NO8367;

Monel 30C

Nimonic 80A/Nickel Alloy 80a/UNS N07080/NA20/2.4631/2.4952

Nimonic 263/NO7263

Nimonic 90/UNS NO7090;

Incoloy 907/GH907;

Nitronic 60/Alloy 218/UNS S21800

Packing

Wooden cases, pallets, nylon bags or according to the customers' requirements

MOQ

1pcs

Delivery time

10-100 days depending on quantity

Payment terms

L/C,T/T

Shipment

FOB Tianjin/Shanghai, CIF, CFR, etc

Application

Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc

Remarks

Other materials and drawings are available.
