Cu-Ni ASME B36.19M Copper Nickel Tube UNS C70600 90/10 UNS C71600 70/30

  • Cu-Ni ASME B36.19M Copper Nickel Tube UNS C70600 90/10 UNS C71600 70/30
  • Cu-Ni ASME B36.19M Copper Nickel Tube UNS C70600 90/10 UNS C71600 70/30
  • Cu-Ni ASME B36.19M Copper Nickel Tube UNS C70600 90/10 UNS C71600 70/30
  • Cu-Ni ASME B36.19M Copper Nickel Tube UNS C70600 90/10 UNS C71600 70/30
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number C70600/CuNi10Fe1Mn/CN102
Minimum Order Quantity 100KGS
Price negotiable
Packaging Details T/T, L/C, Western Union,
Delivery Time 10days->
Payment Terms T/T or western Union or LC
Supply Ability 1500 tons per month
Product Details
Material Grade Copper Nickel Tube And Pipe Cu-Ni Thickness 0.15 - 15mm
Length 0.5 - 25 M Outside Diame 3 - 260mm
Highlight

Copper Nickel Alloy Pipe

,

copper nickel tubing
Leave a Message
Product Description

Copper Nickel Tube and Pipe Cu-Ni ASME B36.19M UNS C70600 (90/10) UNS C71600 (70/30)





Specifications



Type Copper Nickel Tube and Pipe Cu-Ni Application Air Condition Or Refrigerator Specification C70600/CuNi10Fe1Mn/CN102
Outer Diameter Air Condition Or Refrigerator Thickness 0.15 - 15mm Length 0.5 - 25 m
Cu (Min) 90% Alloy Or Not Is Alloy Wall Thickness 0.15 - 15mm
Outside Diame 3 - 260mm Model Number ASTM B111/EN12451/DIN17 Place of Origin Shanghai, China (Mainland)



Packaging & Delivery

Packaging Details: Polywood case

Delivery Detail: 15 days after confirmed order



COPPER-NICKEL SEAMLESS & WELDED PIPE & TUBE

TYPE STANDARD CODE
SEAMLESS ASTM (UNS C70400) B466
(UNS C72200) B466
ASME (UNS C70600) SB466
(UNS C71000) SB466
(UNS C71500) SB466
WELDED ASTM (UNS C71500) SB467
ASME (UNS C70600) SB467



Nickel alloys seamless tube factory price NI200, copper nickel pipe price

1.Style: Nickel Tube Ni200

2.Grade: N4 /N6
3.Standard: ASTM B161
4.Certification: ISO9001 : 2008

5. Purity: 99.6%min

6. Feature:

Ingredient Ni Mn Fe
Content 99.5 0.10 0.15
Skin material specification Thickness ≥0.1mm
Width According to customers demand
Silk material specification ≥0.1mm
Tensile strength ≥43kgf/mm2
Elongation ratio (L=100) ≥15
Characteristic and use It is an alloy product with nickel as the essential component. It has the fine mechanical strength, corrosion resistance performance and characteristic of high strength under high temperature. It is applied in manufacturing electronic vacuum devices, electronic instrumentation parts and so on.

7. Application:

-----for electronic vacuum

-----fine mechanical strength

-----good corrosion resistance performance

-----high heat-resistan

8.Physical properties

Grade Tensile strengh,min,Mpa Yield Strength,0.2% offset,Mpa Elongation,min%
  M m M m M m
Nickel 200 379 448 103 267 40 15
Nickel 201 345 414 83 207 40 15
Monel400 483 586 193 375 35 15



9.Compare with 201 and 200 in properties and chemical composition



Properties

  Density Melting point Coefficient of expansion Modulus of rigidity Modulus of elasticity Electrical resistivity
Ni200 8.9g/cm3 1446°C 13.3 µm/m °C (20-100°C) 81kN/mm2 204kN/mm2 9.6μW• cm
Ni201 1446°C 13.1µm/m °C(20-100°C) 82kN/mm2 207kN/mm2 8.5μW• cm



Chemical Composition



Grade Element Composition/%
Ni+Co Mn Cu Fe C Si Cr S
Ni201 ≥99.0 ≤0.35 ≤0.25 ≤0.30 ≤0.02 ≤0.3 ≤0.2 ≤0.01
Ni200 ≥99.0 /≤0.35 ≤0.25 ≤0.30 ≤0.15 ≤0.3 ≤0.2 ≤0.01

















Cu-Ni ASME B36.19M Copper Nickel Tube UNS C70600 90/10 UNS C71600 70/30Cu-Ni ASME B36.19M Copper Nickel Tube UNS C70600 90/10 UNS C71600 70/30
