Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L

Certification
Good quality Stainless Steel Elbow for sales
Good quality Stainless Steel Elbow for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner .

—— Thailand ---Dave Mulroy

ASTM A182 F55 Super Duplex Flange ,Good quality , we like that ! And delivery time in time also ,very professional.

—— USA ---Alfaro

I'm Online Chat Now

Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L

China Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L supplier
Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L supplier Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L supplier Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L supplier Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L supplier

Large Image :  Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L

Product Details:

Place of Origin: China
Brand Name: TOBO
Certification: SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: Butt weld

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: USD Depending on quantity
Packaging Details: PLY-WOODEN CASE OR PALLET
Delivery Time: 10-100 days depending on quantity
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,0000pcs per month
Contact Now
Detailed Product Description
Material: UNS S32750 UNSS32760 Standard: DIN,EN,ASTM,BS,JIS,GB,etc.
DN: 15-1200 Size: 1/2-60 Inch
Type: Seamless Or Weld

Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L Size 1/2-60 inch



1.Stainless steel tee
2.sch5s-schxxs
3.ISO9001,ISO9000
4.Market:America,Africa,Middle East,Southeast of Asia

Size: 1/2''-48''
Wall thickness: SCH10-SCH160, XS,XXS,STD
Degree: 45D,90D,180D
Standard:DIN,ASTM,ANSI
Certificate:ISO9001;CE

1. Product Item No.: 005fittings-Cosco Steel

2. Size: NPS 1/2"-120"(DN15-3000)

3. Varieties: SCH5S/10S, SCH20/40/8 Pipe Fitting Stainless steel SMLS reducer tee 0/160, STD/XS/XXS, SGP

4. Material:
Carbon steel: ASTM A234 GR WPB , ST37.2 , ST35.8…
Alloy steel: A234 WP5/WP9/WP11/WP22/WP91, A420 WPL6, A860 WHPY 42/52/60/65/70/80…
Stainless steel: A403 WP304/TP304 , WP304L/TP304L , WP316/TP316 , WP316L/TP316L, WP321/TP321 , WP310/TP310…

5. Standard: ANSI B16.9/ANSI B16.28/MSS SP43/MSS P75/JIS2311/JIS 2312/JIS2313/ DIN2615/GB-12459/GB-T13401,Gost17376,we can also produce according to drawing by customers.

6. Surface treatment:
Carbon steel:Shot blasted, black painting, rust-proof oil, transparent oil,galvanizing,, hot galvanizing
Alloy steel:Shot blasted, black painting, rust-proof oil, transparent oil, galvanizing,, hot galvanizing
Stainless steel: pickled,

7. Trade term: FOB, CNF&CFR, CIF

8. Usage: Petroleum/ Power/ Chemical use/ Construction use/ Gas/ Metallury/ Shipbuilding

9. Certificate:GB/T19001-2008-ISO 9001:2008

10. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size

11. Packing: Wooden box or wooden pallet.

12. H.S Code: 73072300

Size 1/2"-48"
Type Elbow:L/R;S/R;15Degree;45Degree;90degree;180Degree,etc
Reducer:eccentric;concentric
Tee:equal;reducing
Cross:equal;reducing
Cap,and so on.
Connection Welding
Thickness Sch5-Sch160, STD, XS, XXS
Material Stainless Steel: A403 WP 304L,316L,F304L,F316L, 321,347, 660 , 718ETC
Pressure PN40, 64, 100, 160, 250, 320, 1500, 2000, 2500, 3000, 6000,9000LBS
Standard ASME,ASTM,ANSI,DIN,GB,B16.9,JIS,BS
Inspection a) Factory in-house
b) Third party inspection available upon request
c)Different accessories are available
Treatment a) Annealed
d) as per customer's requirement
Certificate ISO9001: 2000, CE
Term of payment T/T(in advance)
Packing Plywood case, wooden cases, pallet, or as per customers requirement
Delivery time 7~15days after order confirmation and receive deposit
Application Petroleum, chemical, machinery, papermaking, construction, etc



Norminal Pipe Size Outside Diameter at Bevel Center to End
DN D1 D2 C M
Series A Series B Series A Series B
20×20×15 26.9 25 21.3 18 29 29
25×25×20 33.7 32 26.9 25 38 38
25×25×15 33.7 32 21.3 18 38 38
32×32×25 42.4 38 33.7 32 48 48
32×32×20 42.4 38 26.9 25 48 48
32×32×15 42.4 38 21.3 18 48 48
40×40×32 48.3 45 42.4 38 57 57
40×40×25 48.3 45 33.7 32 57 57
40×40×20 48.3 45 26.9 25 57 57
40×40×15 48.3 45 21.3 18 57 57
50×50×40 60.3 57 48.3 45 64 60
50×50×32 60.3 57 42.4 38 64 57
50×50×25 60.3 57 33.7 32 64 51
50×50×20 60.3 57 26.9 25 64 44
65×65×50 76.1(73) 76 60.3 57 76 70
65×65×40 76.1(73) 76 48.3 45 76 67
65×65×32 76.1(73) 76 42.4 38 76 64
65×65×25 76.1(73) 76 33.7 32 76 57
80×80×65 88.9 89 76.1(73) 76 86 83
80×80×50 88.9 89 60.3 57 86 76
80×80×40 88.9 89 48.3 45 86 73
80×80×32 88.9 89 42.4 38 86 70
90×90×80 101.6 -- 88.9 -- 95 92
90×90×65 101.6 -- 76.1(73) -- 95 89
90×90×50 101.6 -- 60.3 -- 95 83
90×90×40 101.6 -- 48.3 -- 95 79
100×100×90 114.3 -- 101.6 -- 105 102
100×100×80 114.3 108 88.9 89 105 98
100×100×65 114.3 108 76.1(73) 76 105 95
100×100×50 114.3 108 60.3 57 105 89
100×100×40 114.3 108 48.3 45 105 86
125×125×100 139.7 133 114.3 108 124 117
125×125×90 139.7 -- 101.6 -- 124 114
125×125×80 139.7 133 88.9 89 124 111
125×125×65 139.7 133 76.1(73) 76 124 108
125×125×50 139.7 133 60.3 57 124 105
150×150×125 168.3 159 139.7 133 143 137
150×150×100 168.3 159 114.3 108 143 130
150×150×90 168.3 -- 101.6 -- 143 127
150×150×80 168.3 159 88.9 89 143 124
150×150×65 168.3 159 76.1(73) 76 143 121
200×200×150 219.1 219 168.3 159 178 168
200×200×125 219.1 219 139.7 133 178 162
200×200×100 219.1 219 114.3 108 178 156
200×200×90 219.1 -- 101.6 -- 178 152
250×250×200 273 273 219.1 219 216 203
250×250×150 273 273 168.3 159 216 194
250×250×125 273 273 139.1 133 216 191
250×250×100 273 273 114.3 108 216 184
300×300×250 323.9 325 273 273 254 241
300×300×200 323.9 325 219.1 219 254 229
300×300×150 323.9 325 168.3 159 254 219
300×300×125 323.9 325 139.7 133 254 216
350×350×300 355.6 377 323 325 279 270
350×350×250 355.6 377 273 273 279 257
350×350×200 355.6 377 219.1 219 279 248
350×350×150 255.6 377 168.3 159 279 238
400×400×350 406.4 426 355.6 377 305 305
400×400×300 406.4 426 323.9 325 305 295
400×400×250 406.4 426 273 273 305 283
400×400×200 406.4 426 219.1 219 305 273
400×400×150 406.4 426 168.3 159 305 264
450×450×400 457.2 478 406.4 426 343 330
450×450×350 457.2 478 355.6 377 343 330
450×450×300 457.2 478 323.9 325 343 321
450×450×250 457.2 478 273 273 343 308
450×450×200 457.2 478 219.1 219 343 298
500×500×450 508 529 457.2 478 381 368
500×500×400 508 529 406.4 426 381 356
500×500×350 508 529 355.6 377 381 356
500×500×300 508 529 323.9 325 381 346
500×500×250 508 529 273 273 381 333
500×500×200 508 529 219.1 219 381 324



Size 1/2 - 60 Inch Stainless Steel Tee Jis Sus304 Sus 304 Sus304L Sus316 Sus316L
