Place of Origin: | CHINA |
---|---|
Brand Name: | TOBO |
Certification: | Customized logo |
Model Number: | available on request |
Minimum Order Quantity: | 1 |
Price: | USD |
Packaging Details: | Wooden box |
Delivery Time: | 5-8 WORK DAYS |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 1 |
Body Connection: | Threaded | Body Material: | Stainless Steel |
---|---|---|---|
Body Pressure Rating: | 3000 Psi | Body Temperature Rating: | 400°F |
Connection: | Threaded | End Connection: | Threaded |
End Pressure Rating: | 3000 Psi | End Size: | 1/2 In |
End Temperature Rating: | 400°F | End Type: | Tee |
Material: | Stainless Steel | Number Of Ends: | 3 |
Pressure Rating: | 3000 Psi | Size: | Tee |
Temperature Rating: | 400°F |
1/2 NPT Female 3000 6000 PSI High Pressure Stainless steel 316 Monel,Duplex,6Mo C276 Instrument Pipe Fittings Female Tee
1.Size range from 1/8" to 2".
|
|||
2.Working temperature:-325℉~800℉ (-198℃~426℃).
|
|||
3.Material grades: SS 304/304L ,SS 316/316S.
|
|||
4.Thread:NPT, BSP, BSPT, UNF, ISO, SAE etc.
|
|||
5.Zero leakage even under tough working conditions.
|
|||
6.All pipe threads meet the requirements of ASME/ANSI B 1.20.1(1983) for tapered pipe threads (NPT).
|
|||
7.Working pressures calculated in accordance with Power Piping Code ANSI B31.1, Refiner Piping Code ASME/ANSI B31.3 and section VIII of ASME Boiler & Pressure Vessel Code.
|
|||
8.Available in wide variety of configurations.
|
-LW3F Female Tee
|
|||||||
Order information
|
T
|
N
|
D
|
W
(HEX)
|
|||
(NPT)
|
(in)
|
(mm)
|
(in)
|
(mm)
|
(in)
|
(mm)
|
|
-LW3F-2
|
1/8
|
0.83
|
21.0
|
0.34
|
8.6
|
0.68
|
17.4
|
-LW3F-4
|
1/4
|
0.94
|
24.0
|
0.45
|
11.4
|
0.82
|
20.8
|
-LW3F-6
|
3/8
|
1.10
|
28.0
|
0.59
|
15.0
|
0.94
|
23.8
|
-LW3F-8
|
1/2
|
1.18
|
30.0
|
0.73
|
18.5
|
1.06
|
27.0
|
-LW3F-12
|
3/4
|
1.46
|
37.0
|
0.94
|
23.9
|
1.30
|
33.0
|
-LW3F-16
|
1
|
1.55
|
39.0
|
1.17
|
29.7
|
1.50
|
38.0
|
