ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9

Certification
Good quality Stainless Steel Elbow for sales
Good quality Stainless Steel Elbow for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner .

—— Thailand ---Dave Mulroy

ASTM A182 F55 Super Duplex Flange ,Good quality , we like that ! And delivery time in time also ,very professional.

—— USA ---Alfaro

I'm Online Chat Now

ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9

China ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9 supplier
ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9 supplier ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9 supplier ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9 supplier ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9 supplier ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9 supplier ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9 supplier

Large Image :  ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9

Product Details:

Place of Origin: CHINA
Brand Name: TOBO
Certification: SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: ASTM A234 WP12 / WP22 / WP91

Payment & Shipping Terms:

Minimum Order Quantity: 3PCS
Price: Negotiation
Packaging Details: PLY-WOODEN CASE OR PALLET
Delivery Time: 15DAYS
Payment Terms: T/T, L/C, Western Union
Supply Ability: 9980000PCS Per Month
Contact Now
Detailed Product Description
Material: ASTM A234 WP12 / WP22 / WP91 Surface Finish:: Sand Blast, Black Painting, Galvanizing Finish
Manufacturing Process: Push, Press, Forge, Cast, Etc. Application: Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding Etc
Packaging Details:: Butt Welding Pipe Fitting Commonly Should Be Shipped In Wooden Cases, Wooden Pallets Or As Per Customers Request Standard: ASME / ANSI B16.9 , ASME B16.47 , ASME B16.48 , MSS SP-75



ASTM A234 WP12 / WP22 / WP91 Butt Weld Fittings Deg LR 45 Deg Elbow ASME / ANSI B16.9





Standard Met︰ Specification


ASME STANDARDS
• ASME B 16.5: Steel Pipe Flanges and Flanged Fittings
• ASME B 16.9: Factory-Made Wrought Steel Butt Welding Fittings
• ASME B 16.11: Forged Steel Fittings Socket Ending and Threaded
• ASME B 16.25: Buttwelding Ends
• ASME B 16.31.3: Power Piping
• ASME B 16.31.8: Gas Transmission Distribution and Piping Systems
• ASME B 16.49: Factory-Made Wrought Steel Butt Welding Induction Bends

MSS STANDARDS
• MSS SP-43: Wrought Stainless Steel Butt Welding Fittings
• MSS SP-75: Specification for High Test Wrought Butt Welding Fittings
• MSS SP-79: Socket Welding Reducer Inserts

JIS STANDARDS
• JIS B2311: Steel Butt Welding Pipe Fittings for ordinary use
• JIS B2312: Steel Butt Pipe Fittings
• JIS B2313: Steel Plate Butt Welding Pipe Fittings
• JIS B2316: Steel Socket Welding Pipe Fittings
BB STANDARDS
• BS 1640: Steel Butt Welding Pipe Fittings for petroleum Industry part 1
Wrought Carbon and ferritie Alloy Steel Fittings
• BS 1965: Butt Welding Pipe Fittings for pressure purpose part 1
Carbon Steel & Austenitic Stainless Steel

ASTM STANDARDS
• ASTM A234: Pipe Fittings of Wrough Carbon Steel and alloy steel for Moderate and elevated Temperatures
• ASTM A403: Wrough Autenitic Stainless Steel Pipe Fittings
• ASTM A420: Pipe Fittings of Wrough Carbon Steel and alloy steel for low Temperatures Service
• ASTM A53: Pipe, Steel, Black and Hot Dipped Zinc Coated Welded and Seamless
• ASTM A106: Seamless Carbon Steel for high Temperature Service
• ASTM A105: Forging Carbon Steel for Piping Component
• ASTM A181: Forging Carbon Steel for General Purpose Piping
• ASTM A182: Forged or Rolled Alooy Steel Pipe Flanges, Forged Fittings, and Valves and Parts for high temperature Service
• ASTM A350: Forgin Carbon AND Low-Alloy Steel, requiring Notch Toughness Testing for pipiping Components
• ASTM A815: Wrough Ferritic, Ferritic/Autenitic and martensitic Stainless Steel Pipe Fittings
• ASTM 860: Wrough High Strenght, Low Alloy Steel, Butt Welding Fittings

IPS STANDARD
• IPS-M-PI-150: Standard for Flanges and Fittings

Materials

Carbon Steel for Moderate Temperature
ASTM 234 WPB-WPC

High Yeld carbon steel for pipeline and offshore
ASTM A 860 WPHY42-46-52-60-65-70-80

Carbon Steel for low temperature
ASTM A 420 WPL6

Carbon nickel steel for low temperature
ASTM A 420 WPL3

Carbon Molybdenum steel
ASTM A 234 WP1

Chromium Molybdenum steel
ASTM A 234 WP5-9-11-12-22

Austenitic Stainless steel
ASTM A403 WP304-316-321-347

Nickel and Nickel Alloys
ASTM B366

Ferritic Steel
ASTM 815 WP27-33-429-430-430TI-446 (Duplex)

Ferritic/Austenitic Steel
UNS S331803 (Duplex)
UNS S32750-S32760-32550 (Superduplex)

Martensitic Steel
ASTM 815 WP410

Titanium alloy
ASTM B363



We can produce high quality stainless steel pipe fittings,
JIS B 2312 Sch10S  SUS 304 Elbow
JIS B 2312 SUS 304 Tee
JIS B 2312 SUS 304 Reducer (concentric)

SIZES:
1/2" N. B. TO 24" N. B. Seamless Pipe Fittings(BW)
1/2" N. B. TO 72" N. B. Welded BW
Marking:Standard/ As per request
Packing: Wooden case(Fumigation free) Or as per request
Inspection: In house and third party
Document: MTC EN10204-3.1 can be provided prior to shipment
Surface treatment: Surface galvanized, antirust coating, Epoxy & FBE Coating, Electro Polishing,
For further information about our company and products, please visit our website or contact us directly. You will get our 24X7 hour reply by Email, fax or Phone.




Butt weld fittings range:




Products
Elbow (LR&SR ,180 Deg, 90 Deg. & 45 Deg.other customized ,3D,5D)
Tee (Equal &Reducingl)
Reducer (Concentric & Eccentric)
CAP
Stubend (Long &Short)
Material Stainless Steel: ASTM A403 WP 304/ 304L/ 304H/ 316/ 316L/ 317/ 317L/ 321/ 310/ 347/ 904L/ etc.
Carbon Steel: ASTM A234 WPB / A420 WPL3/ A420 WPL6/ MSS-SP-75 WPHY 42/46/52/56/60/65/70 etc.
Alloy Steel: ASTM A234 / WP5/ WP9/ WP11/ WP22/ WP91
Standard ASME B16.9 16.28/MSS SP-43/DIN 2605/JIS B2312
Size 1/2" - 72"
Wall Wall Thickness: SCH20, SCH40, SCH80, SCH120, SCH160, STD, XS, XXS.
Surface Treatment Surface galvanized, antirust coating, Epoxy & FBE Coating,protected with plastic caps
Packing Pallet/Wooden case(Fumigation free)
Certificate ISO9001,PED,EN10204 3.1 MTC
Quality control In house and third party
