MS Equal / Unequal Black & Galvanized Steel Angle Bar Incoloy Alloy 25-6MO

  • MS Equal / Unequal Black & Galvanized Steel Angle Bar Incoloy Alloy 25-6MO
  • MS Equal / Unequal Black & Galvanized Steel Angle Bar Incoloy Alloy 25-6MO
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number Alloy 25-6MO
Minimum Order Quantity 1 ton
Price Depending on quantity
Packaging Details PLY-WOODEN CASE OR PALLET
Delivery Time 10-100 days depending on quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 10000 Tons per month
Product Details
Product Name Super Alloy Incoloy Alloy 25-6MO Steel Bar Product Type Steel Bar
Side And Slot Milling Finishing - 0.050" Depth - 0.009"/tooth Feed - 140SFM Reaming Feed - Same As Drilling - 100 SFM
Drilling 1/4" Dia Hole - 0.004"/rev Feed - 60 SFM 1/2" Dia Hole - 0.007"/rev Feed - 60 SFM 3/4" Dia Hole - 0.010"/rev Feed - 60 SFM Steel Standard ABS,LR,DNV,BV,GL,CCS,KR,NK,RINA
Surface Treatment Hot Rolled And Coated Or Shot Blasting And Painting Application Shipbuilding Steel Plates Are Mainly Used To Contribute Hull Of Ships And The Cranes Of Break Bulker And Vessels In Low Temperature Oceans.
Highlight

Stainless Steel Bright Bars

,

Stainless Steel Flat Bar
Leave a Message
Product Description

MS Equal / Unequal Black & Galvanized Steel Angle Bar  Incoloy Alloy 25-6MO





High Performance Alloys stocks and produces this grade in the following forms: Bar, billet, sheet fasteners and forgings.Request quote on this grade in sheets 0.062, 0.074 and 0.125" thick.



Overview

INCOLOY alloy 25-6HN is a 6% molybdenum super-austenitic stainless steel. It offers an excellent combination of strength, ductility and resistance to corrosion by a variety of media at an economical price. It is readily formed and welded. The properties of the alloy are enhanced by its content of nitrogen. Its high content of nickel results in thermal stability and resistance to stress corrosion cracking. Designated as UNS N08367, alloy 25-6HN directly competes with Allegheny Ludlum alloy AL6XN®. The alloys are covered by the same ASTM, ASME, and NACE specifications. Applications are found in the air pollution control, power, chemical processing, marine, pulp and paper, and oil and gas industries. Alloy 25-6HN is a new addition to Special Metals existing line of high performance, super-austenitic stainless steels, INCOLOY alloys 25-6MO and 27-7MO.



MS Equal / Unequal Black & Galvanized Steel Angle Bar Incoloy Alloy 25-6MOMS Equal / Unequal Black & Galvanized Steel Angle Bar Incoloy Alloy 25-6MO

Characteristics

  • PREN 48.3 Typical for ASTM G48, CPT per G48-C 75C, CCT per G48-D 35C
  • Density 0.290 Lbs/cubic inch
  • Magnetic permeability 1.003 (200 Oersteds at Room Temp)
  • Coefficient of thermal expansion (68-212F) 8.49x10 in/in Deg F
  • Higher strength than conventional austenitic grades (304/316)


Applications

  • Marine enviroments
  • Desalination systems
  • Flue gas desulfurization equipment
  • Reaction vessels for pharmaceutical production



Chemistry

Chemical Requirements



Ni

C

Mn

Cr

N

Si

Mo

Fe

Max

25.5

.03

2.0

22.0

0.25

1.0

7.0

Bal

Min

23.5





20.0

0.18



6.0





Tensile Data

Mechanical Property Requirements



Ultimate Tensile

Yield Strength (0.2% OS)

Elong. in 2 in. or 50mm or 4D, min., %

R/A

Hardness

Annealed

Typical

107 KSi

55 KSi

48



Rb 90



D- Forging quality is furnished to chemical requirements and surface inspection only. No mechanical properties required.


Specifications

Form

Standard

Metal Type

UNS N08367

Bar

ASTM B691 / ASME SB691

Wire

ASTM B691 / ASME SB691

Sheet

ASTM B688, A240 / ASME SB688 SA240

Plate

ASTM B688, A240 / ASME SB688 SA240

Tube

ASTM B676 WELDED

Pipe

ASTM B675 WELDED

Fitting

ASTM B366 / ASME SB366 / ASTM B462 / ASME SB462

Forging

ASTM B472 / ASTM B462 / ASME SB462

Weld Wire

622, 686 or 625

Weld Electrode

Inconel 112, 122 or INCOWELD 686CPT

Din





Machining



Machinability Ratings


MACHINING DATA
Carbide tools are suggested
for rates better than 50% of Type 304.
Machining Type Suggested starting rates are:
Single Point turning : Roughing - 0.15" depth, 0.018"/rev feed -200 SFM
Finishing - 0.025" depth, 0.007"/rev feed - 350 SFM
Drilling : 1/4" Dia hole - 0.004"/rev feed - 60 SFM
1/2" Dia hole - 0.007"/rev feed - 60 SFM
3/4" Dia hole - 0.010"/rev feed - 60 SFM
Reaming : Feed - same as drilling - 100 SFM
Side and Slot Milling : Roughing - 0.25" depth - 0.007"/tooth feed - 125SFM
Finishing - 0.050" depth - 0.009"/tooth feed - 140SFM
These rates are for carbide tools,
Type C-2 for roughing, drilling and reaming.
Type C-3 for finishing.
