| Place of Origin: | China |
|---|---|
| Brand Name: | TOBO |
| Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Model Number: | ASTM A815 UNS S31803/S32205/S32750/S32760 |
| Minimum Order Quantity: | 100KGS |
| Price: | negotiable |
| Packaging Details: | in plastic bags then in bundles |
| Delivery Time: | 15days-> |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 1500 tons per month |
| Standard: | ASTM A815 UNS S31803/S32205/S32750/S32760 | Color: | White, Silver |
|---|---|---|---|
| Material: | Stainless Steel | Type: | ELBOW |
| Highlight: | Pipe Fittings Elbow,Stainless Steel 90 Degree Elbow |
||
| Brand Name: | TOBO |
| Model Number: | ASTM A815 UNS S31803/S32205/S32750/S32760 |
| Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Place of Origin: | China |
| Product Name | Stainless steel elbow | Product Type | pipe fittings |
| Size | 1/2"--48" | DN15-DN1200 | 15-1200 |
| Material Grrade | Duplex Stainless Steel | THK | SCH5S--SCH160 XXS |
| Standard | 904l, 316ti, 2507/32750 Grade Seamless, ANSI B16.9 | Standard | DIN,EN,ASTM,BS,JIS,GB,etc. |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc | ||
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 3,0000pcs per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | PLY-WOODEN CASE OR PALLET |
| Packaging Details: | Packing: plywood case or fumigated woodern case or as per customers' requests. |
| Delivery Detail: | 2 - 10 days after receiving the deposit |
1) SS & Duplex tube fitting
2) Size:DN15(1/2")---DN1200(48") THK: SCH5S--SCH160 XXS
3) Material:317L/304/304L/304H/316/316L/321/321H/309S/310S 347/347H/904L/duplex 2205
Stainless Steel Elbow, 904l, 316ti, 2507/32750 Grade Seamless, ANSI B16.9
Detailed product description
Features:
1) Type: butt welded and seamless pipe fitting
2) Size: we can also produce other specifications according to customers' requirements.DN15-DN1200 (1/2"-48").
3) Wall thickness: SCH5S-SCH160S.
4) Standard: ASME/ANSI B16.9, GB/T12459, GB/T13401, SH3408, SH3409, HG/T21635, HG/T21631, MSS SP-43, DIN 2605, JIS B2313.
5) Material: Stainless steel (304, 304L, 316, 316L, 317L,321, 321H, 310S, 347H,S31803,904L,)
6) Our products are corrosion and high-temperature resistant.
7) Applications range: For use in the petroleum, smelting, foodstuff, power, papermaking,
chemical, medical equipment, aviation, boiler heat exchanger, and other fields.
Packing: as per customers' requests
| Tee Type | Stainless steel ELBOW | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Size | 1/2’’~48’’(Seamless);16’’~72’’(Welded) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Wall thickness | Sch5~Sch160XXS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Manufacture Standard: | ASME B16.9,ASME B16.11,ASME B16.28 ,MSS SP-43,JISB2311,JIS B2312,JIS B2313,DIN 2605,DIN 2606 ,DIN2615,DIN2616 ,BG12459-90,GB/T13401,HGJ514 ,SH3408 ,SH3409, HG/T21635, HG/T21631, | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Material | Carbon steel, stainless steel, alloy steel, duplex stainless, nickel alloy steel | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Carbon steel | ASTM A234 WPB, WPC; | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Stainless steel |
304/SUS304/UNS S30400/1.4301 304L/UNS S30403/1.4306; 304H/UNS S30409/1.4948; 309S/UNS S30908/1.4833 309H/UNS S30909; 310S/UNS S31008/1.4845; 310H/UNS S31009; 316/UNS S31600/1.4401; 316Ti/UNS S31635/1.4571; 316H/UNS S31609/1.4436; 316L/UNS S31603/1.4404; 316LN/UNS S31653; 317/UNS S31700; 317L/UNS S31703/1.4438; 321/UNS S32100/1.4541; 321H/UNS S32109; 347/UNS S34700/1.4550; 347H/UNS S34709/1.4912; 348/UNS S34800; |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alloy steel |
ASTM A234 WP5/WP9/WP11/WP12/WP22/WP91; ASTM A860 WPHY42/WPHY52/WPHY60/WPHY65; ASTM A420 WPL3/WPL6/WPL9; |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Duplex steel |
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Nickel alloy steel |
Alloy 200/Nickel 200/NO2200/2.4066/ASTM B366 WPN; Alloy 201/Nickel 201/NO2201/2.4068/ASTM B366 WPNL; Alloy 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC; Alloy K-500/Monel K-500/NO5500/2.475; Alloy 600/Inconel 600/NO6600/NS333/2.4816; Alloy 601/Inconel 601/NO6001/2.4851; Alloy 625/Inconel 625/NO6625/NS336/2.4856; Alloy 718/Inconel 718/NO7718/GH169/GH4169/2.4668; Alloy 800/Incoloy 800/NO8800/1.4876; Alloy 800H/Incoloy 800H/NO8810/1.4958; Alloy 800HT/Incoloy 800HT/NO8811/1.4959; Alloy 825/Incoloy 825/NO8825/2.4858/NS142; Alloy 925/Incoloy 925/NO9925; Hastelloy C/Alloy C/NO6003/2.4869/NS333; Alloy C-276/Hastelloy C-276/N10276/2.4819; Alloy C-4/Hastelloy C-4/NO6455/NS335/2.4610; Alloy C-22/Hastelloy C-22/NO6022/2.4602; Alloy C-2000/Hastelloy C-2000/NO6200/2.4675; Alloy B/Hastelloy B/NS321/N10001; Alloy B-2/Hastelloy B-2/N10665/NS322/2.4617; Alloy B-3/Hastelloy B-3/N10675/2.4600; Alloy X/Hastelloy X/NO6002/2.4665; Alloy G-30/Hastelloy G-30/NO6030/2.4603; Alloy X-750/Inconel X-750/NO7750/GH145/2.4669; Alloy 20/Carpenter 20Cb3/NO8020/NS312/2.4660; Alloy 31/NO8031/1.4562; Alloy 901/NO9901/1.4898; Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Alloy 926; Inconel 783/UNS R30783; NAS 254NM/NO8367; Monel 30C Nimonic 80A/Nickel Alloy 80a/UNS N07080/NA20/2.4631/2.4952 Nimonic 263/NO7263 Nimonic 90/UNS NO7090; Incoloy 907/GH907; Nitronic 60/Alloy 218/UNS S21800 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Package | Wooden cases, pallets, nylon bags or according to the customers' requirements | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| MOQ | 1pcs | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Delivery time | 10-100 days depending on quantity | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Payment terms | T/T or Western Union or LC | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Shipment | FOB Tianjin/Shanghai, CFR, CIF, etc | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Remarks | Other materials and drawings are available. | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Welcome to contact us.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Unit : inch Nominal Pipe Size |
Outside Dia. (OD) |
Wall Thickness (T) | 90o L/R Elbow Center To End A | 45o L/R Elbow Center To End B | 90o S/R Elbow Center To End A | |||
| Sch.5S | Sch.10S | Sch.40S | Sch.80S | |||||
| 1/2 | 0.840 | 0.065 | 0.083 | 0.109 | 0.147 | 1.50 | 0.625 | |
| 3/4 | 1.050 | 0.065 | 0.083 | 0.113 | 0.154 | 1.12 | 0.438 | |
| 1 | 1.315 | 0.065 | 0.109 | 0.133 | 0.179 | 1.50 | 0.875 | 1.00 |
| 1-1/4 | 1.660 | 0.065 | 0.109 | 0.140 | 0.191 | 1.88 | 1.00 | 1.25 |
| 1-1/2 | 1.900 | 0.065 | 0.109 | 0.145 | 0.200 | 2.25 | 1.12 | 1.50 |
| 2 | 2.375 | 0.065 | 0.109 | 0.154 | 0.218 | 3.00 | 1.38 | 2.00 |
| 2-1/2 | 2.875 | 0.083 | 0.120 | 0.203 | 0.276 | 3.75 | 1.75 | 2.50 |
| 3 | 3.500 | 0.083 | 0.120 | 0.216 | 0.300 | 4.50 | 2.00 | 3.00 |
| 4 | 4.500 | 0.083 | 0.120 | 0.237 | 0.337 | 6.00 | 2.50 | 4.00 |
| 5 | 5.563 | 0.109 | 0.134 | 0.258 | 0.375 | 7.50 | 3.12 | 5.00 |
| 6 | 6.625 | 0.109 | 0.134 | 0.280 | 0.432 | 9.00 | 3.75 | 6.00 |
| 8 | 8.625 | 0.109 | 0.148 | 0.322 | 0.500 | 12.00 | 5.00 | 8.00 |
| 10 | 10.750 | 0.134 | 0.165 | 0.375 | 0.500 | 15.00 | 6.25 | 10.00 |
| 12 | 12.750 | 0.156 | 0.180 | 0.375 | 0.500 | 18.00 | 7.50 | 12.00 |
| 14 | 14.000 | 0.156 | 0.250 | 0.375 | 0.500 | 21.00 | 8.75 | 14.00 |
| 16 | 16.000 | 0.165 | 0.250 | 0.375 | 0.500 | 24.00 | 10.00 | 16.00 |
| 18 | 18.000 | 0.165 | 0.250 | 0.375 | 0.500 | 27.00 | 11.25 | 18.00 |
| 20 | 20.000 | 0.188 | 0.250 | 0.375 | 0.500 | 30.00 | 12.50 | 20.00 |
| 24 | 24.000 | 0.218 | 0.250 | 0.375 | 0.500 | 36.00 | 13.50 | 24.00 |
