Place of Origin: | China/Japan/Germany |
---|---|
Brand Name: | TOBO/TPCO/TISCO/VALIN/METAL |
Certification: | ISO/PED/TUV/SGS/LR/BV |
Model Number: | ASTM A790 UNS32750 GR2507 |
Minimum Order Quantity: | 0.5-1 tons |
Price: | negotiable |
Packaging Details: | in plastic bags then in bundles |
Delivery Time: | According to the qty |
Payment Terms: | T/T, L/C, Western Union, MoneyGram |
Supply Ability: | 1500 tons per month |
SIZES: | 1/8"-48" | Material: | 2507 (UNS S32750) |
---|---|---|---|
Color: | White Silver Gold | Standard: | TP310 / TP347 / TP321H Seamless Stainless Steel Pipe With Butt Weld Ends |
Highlight: | seamless stainless steel tube,stainless steel round tube |
ASTM A790 UNS32750 GR2507 SMLS Pipe DN100 SCH160S
Brand Name: | TOBO |
Model Number: |
ASTM A790 UNS32750 GR2507 SMLS Pipe DN100 SCH160S
|
Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
Place of Origin: | China |
|
Standard: | AISI, ASTM, DIN, Etc | Place of Origin: | China | Brand Name: | TOBO |
Model Number: | 2507 Pipe | Type: | 2507 SMLS Pipe | Steel Grade: | 2507 |
Application: | Heat exchanger and condenser, etc | Surface: | as customer's required | Welding Line Type: | EFW |
Thickness: | SCH5~SCH160s | Outer Diameter: | 1/8"-48" |
Packaging Detail: | wooden cases or PPwrapping with bundles as customer's required |
Delivery Detail: | 7- 20 days |
ASTM A790 UNS32750 GR2507 SMLS Pipe DN100 SCH160S
01) Type: 2507 SMLS Pipe
02) Process method: Hot rolled/ cold rolled/ cold drawn
03) Surface finish: Annealed/pickling,mirror,HL
04) Standards: A790, JIS G3459, JIS G3463, DIN 17456, DIN 17458
05) Material: 2507 (UNS S32750), etc
06) Size:
A) O. D.: 6mm - 710mm
B) Thickness: 0.8mm - 50mm
07) Length: Max. 17 meters (specific or random)
08) Delivery conditions: Annealed, pickled & polished
Chemical Composition Of F53 UNS 32750 GR2507 Super Duplex Stainless Steel
GRADE | C≤ | Mn≤ | Si≤ | S≤ | P≤ | Cr≤ | Ni | Mo | Cu≤ | N |
S32750 (2507) 00Cr25Ni7Mo4N |
0.03 | 1.20 | 0.8 | 0.020 | 0.035 | 24.0/26.0 | 6.0/8.0 | 3.0/5.0 | 0.50 | 0.24/0.32 |
Description | ASTM A790 UNS32750 GR2507 SMLS Pipe DN100 SCH160S |
Size Range | O.D.: Φ6 - Φ710mm, W.T: 0.8mm - 50mm |
SCH 5,SCH 10,SCH 20,SCH 40,SCH 80,SCH 120,SCH 160s,SCH XXS | |
Specification | ASTM A213,ASTM A312,ASTM A269,ASTM A778,ASTM A790,DIN 17456,DIN 17458,JIS G3459,JIS G3463 |
Grade | 2507 (UNS S32750), S31803, S32205 (Duplex), etc |
Application | Ship Builders, Automotive Industry, Power Generation, Food Industry, Paper Industry, Pharmaceutical Industry, Chemical Industry, Oil and Gas Industry |
