ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312

China ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312 supplier
ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312 supplier ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312 supplier ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312 supplier ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312 supplier

Large Image :  ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312

Product Details:

Place of Origin: China
Brand Name: TOBO
Certification: SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: Seamless or weld

Payment & Shipping Terms:

Minimum Order Quantity: 500KG
Price: USD
Packaging Details: Wooden case
Delivery Time: 10-45work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 pcs per month
Contact Now
Detailed Product Description
Size: 1-48inch Standard: ASTM A312
Material: Hastelloy C 276 DN: 15-2400
OD: 1-600mm Thickness: Sch5-Sch160 ,XS,XXS

Hastelloy Pipe Alloy UNS N10276 Hastelloy C Pipe Hastelloy C 276 Tube Size 1-48inch



Hastelloy C276 is a nickel-molybdenum-chromium superalloy with an addition of tungsten designed to have excellent corrosion resistance in a wide

range of severe environments. The high nickel and molybdenum contents make the nickel steel alloy

especially resistant to pitting and crevice corrosion in reducing environments while chromium conveys

resistance to oxidizing media. The low carbon content minimizes carbide precipitation during welding to

maintain corrosion resistance in as-welded structures. This nickel alloy is resistant to the formation of grain

boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process

application in an as welded condition.

Although there are several variations of the Hastelloy nickel alloy, Hastelloy C-276 is by far the most widely

used.

Alloy C-276 is widely used in the most severe environments such as chemical processing, pollution control,

pulp and paper production, industrial and municipal waste treatment, and recovery of sour natural gas.



In what forms is Hastelloy C276 Available at YUHONG HOLDING GROUP?

  • Sheet
  • Plate
  • Pipe & Tube (welded and seamless)
  • Wire
  • Fittings

Corrosion Resistant Hastelloy C276

Considered one of the most versatile corrosion resistant alloys available, Hastelloy C-276 exhibits

excellent resistance in a wide variety of chemical process environments including those with ferric and

cupric chlorides, hot contaminated organic and inorganic media, chlorine, formic and acetic acids, acetic

anhydride, seawater, brine and hypochlorite and chlorine dioxide solutions. In addition, alloy C-276 resists

formation of grain boundary precipitates in the weld heat affected zone making it useful for most chemical

processes in the as-welded condition. This alloy has excellent resistance to pitting and stress corrosion

cracking.



What are the characteristics of Hastelloy C276?

  • Excellent corrosion resistance in reducing environments
  • Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
  • High nickel and molybdenum contents providing good corrosion resistance in reducing environments
  • Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected
  • zones of welded joints
  • Resistance to localized corrosion such as pitting and stress-corrosion cracking
  • One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine
  • dioxide

Chemical Composition, %

Ni Mo Cr Fe W Co Mn C
Remainder 15.0-17.0 14.5-16.5 4.0-7.0 3.0-4.5 2.5 max 1.0 max .01 max
V P S Si / / / /
.35 max .04 max .03 max .08 max / / / /




In what applications is Hastelloy C-276 used?

Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings

Flue gas desulfurization systems

Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping

Sour gas wells

Pulp and paper production

Waste treatment

Pharmaceutical and food processing equipment

Fabrication with Hastelloy C-276



Hastelloy C-276 alloy can be forged, hot-upset and impact extruded. Although the alloy tends to

work-harden, you can have it successfully spun, deep-drawn, press formed or punched. All of the common

methods of welding can be used, although the oxyacetylene and submerged arc processes are not

recommended when the fabricated item is for use in corrosion service.

Hastelloy C-276 Welding Material

Alloy C276 welding products are used as matching composition filler material for welding C276 alloy

wrought and cast products, for dissimilar welding applications including other nickel-chromium-molybdenum alloys and stainless steels, and for weld overlay or cladding of steels.



Specifiacations: ASME-SFA-5.14 ERNiCrMo-4



Forms of C276 Filler Metal Available at TOBO:

  • .031 in or .8 mm in diameter
  • .035 in or .9 mm in diameter
  • .039 in or 1.0 mm in diameter
  • .045 in or 1.1 mm in diameter
  • .047 in or 1.2 mm in diameter
  • .062 in or 1.6 mm in diameter
  • .078 in or 2.0 mm in diameter
  • .093 in or 2.4 mm in diameter
  • .125 in or 3.2 mm in diameter

Filler metals are available in spools and in cut lengths from the above diameters. Straight lengths are

available in 36" lengths.



ASTM Specifications

Pipe Smls Pipe Welded Tube Smls Tube Welded Sheet/Plate Bar Forging Fitting Wire
B622 B619 B622 B626 B575 B574 B564 B366




Mechanical Properties


Typical Room Temperature Tensile Properties of Annealed Material

Product Form Tensile (ksi) .2% Yield (ksi) Elongation %
Bar 110.0 52.6 62
Plate 107.4 50.3 67
Sheet 115.5 54.6 60
Tube & Pipe 105.4 45.4 70


ch5 - Sch160 Alloy UNS N10276 Hastelloy C Pipe 1 - 48 inch ASTM A312
