Home ProductsCopper Nickel Tube

C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm

Certification
Good quality Stainless Steel Elbow for sales
Good quality Stainless Steel Elbow for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner .

—— Thailand ---Dave Mulroy

ASTM A182 F55 Super Duplex Flange ,Good quality , we like that ! And delivery time in time also ,very professional.

—— USA ---Alfaro

I'm Online Chat Now

C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm

China C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm supplier
C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm supplier C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm supplier C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm supplier C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm supplier C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm supplier

Large Image :  C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm

Product Details:

Place of Origin: China/Japan/Germany
Brand Name: TOBO/TPCO/TISCO/VALIN/METAL
Certification: ISO/PED/TUV/SGS/LR/BV
Model Number: Copper Nickel alloy 70/30

Payment & Shipping Terms:

Minimum Order Quantity: 300 Kilogram/Kilograms
Price: US $ 10 - 100 / Kilogram
Packaging Details: Plywood cases or customized
Delivery Time: 20 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50 Metric Ton/Metric Tons per Month
Contact Now
Detailed Product Description
Product Name: Copper-Nickel Tube Type: Copper Pipe
Material Grade: Copper Nickel Alloy 70/30 Application: Water Heater
Outside Diameter:: 2mm~910mm Wall Thickness: 0.2mm~120mm
Cu (Min): 90% Shape: Round Pipe
Length: 6-12m

C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm



Product Description

Name: copper tube copper nickel pipe

1.OD:2mm~910mm
2.WT:0.2mm~120mm
3.Length:as your requirement
4.High quality, good price, short delivery time

5.Standard: 70/30 copper nickel

6.Type: Copper pipe

7.Shape: Round pipe





Quick Details



Type: Straight Copper Pipe Application: Water Heater Grade:Copper copper
Length: as required Cu (Min): 90% Alloy Or Not:Alloy Is Alloy
Wall Thickness: 0.8 - 1.5mm Outside Diameter: 6 - 8mm Place of Origin:China Shanghai, China (Mainland)
contact person: Angel Zhao contact detail: Skype: +86 17717052304 Email:Angel@tobo-group.com
color: brass



  DIN 17664
2.0872
DIN 86019
2.1972
BS 2871
CN 102
EEMUA
144-1987
UNS C7060x
MIL-T-16420K
ASTM B 466
C 70600
JIS H 3300
C 7060T
Cu+Ni+Fe
Cu%

Ni%

Fe%

Mn%

C %

Pb%

S %

P%

Zn%

Other imp.
rem.

9.0 - 11.0

1.0 - 2.0

0.5 - 1.0

max. 0.05

max. 0.03

max. 0.02

max. 0.02

max. 0.50

max. 0.30
rem.

9.0 - 11.0

1.5 - 1.8

0.5 - 1.0

max. 0.05

max. 0.01

max. 0.005

max. 0.02

max. 0.05

max. 0.20
rem.

10.0 - 11.0

1.0 - 2.0

0.5 - 1.0

max. 0.05

max. 0.01

max. 0.05

-

-

max. 0.30
rem.

10.0 - 11.0

1.5 - 2.0

0.5 - 1.0

max. 0.05

max. 0.01

max. 0.02

max. 0.02

max. 0.20

max. 0.30
rem.

9.0 - 11.0

1.0 - 1.8

max. 1.00

max. 0.05

max. 0.02

max. 0.02

max. 0.02

max. 0.50

-
rem.

9.0 - 11.0

1.0 - 1.8

0.2 - 1.0

-

max. 0.05

-

-

max. 0.50

Cu+Ni+Fe+Mn : min 99.5%





Copper pipe/Copper tube

1. Item Copper & Brass Pipe/copper Tube,Cu-Ni Alloy Tube
2. Standard ASTM,DIN,EN,ISO,JIS,GB
3. Material

T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,

C10920,TP1,TP2,C10930,C11000,C11300,C11400,C11500,C11600,C12000,

C12200,C12300,TU1,TU2,C12500,C14200,C14420,C14500,C14510,C14520,

C14530,C17200,C19200,C21000,C23000,C26000,C27000,C27400,C28000,

C33000,C33200,C37000,C44300,C44400,C44500,C60800,C63020,

C68700,C70400,C70600,C70620,C71000,C71500,C71520,C71640,etc

4. Shape Round, square, rectangular, etc
5. Specifications Round Wall thickness: 0.2mm~120mm
Outside Diameter: 2mm~910mm
Square Wall thickness: 0.2mm~120mm
Size: 2mm*2mm~1016mm*1016mm
Rectangular Wall thickness: 0.2mm~120mm
Size: 2mm*4mm~1016mm*1219mm
6. Length 5.8m,6m,11.8m,12m,or as required
7. Hardness 1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc
8. Surface mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required
9. Price Term Ex-work,FOB,CFR,CIF,etc
10. Payment Term T/T, L/C, Western Union, etc
11. Delivery Time According to order's quantity
12. Package

Export standard package: bundled wooden box, suit for all kinds of transport

or be required

13. Export to

Singapore,Indonesia,Ukraine,Korea,Thailand,Viet Nam,Saudi Arabia,Brazil,Spain,

Canada,USA, Egypt, Iran, India, Kuwait,Dubai,Oman,Kuwait,Peru,Mexico,

Iraq,Russia, Malaysia, etc

14. Application

Copper pipe is the first choice of residential housing water pipes, heating,

cooling pipes installed.

Copper products are widely used in aviation, aerospace, ships, military industry,

metallurgy, electronics, electrical, mechanical, transportation, construction and

other fields of the national economy



C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm





Packaging & Delivery



Packaging Details: Package: Wooden bulk/Wooden case/ Steel strip /Or as required
Delivery Detail: Depend on quantity




C70600 Copper Nickel Tube Round WT 0.2mm ~ 120mm OD 2mm ~ 910mm



FAQ

Q:Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
