ASTM B 111 C71500 Copper Nickel Tube For Transportation / Military Industry

Basic Information

Place of Origin:	China
Brand Name:	TOBO
Certification:	SGS
Model Number:	TOBO-77

Minimum Order Quantity:	1PCS
Price:	1 USD PER PCS
Packaging Details:	by Plywood case, about 1 metric ton per case.
Delivery Time:	7-15 WORK DAYS
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	500 TON PER MONTH

Get Best Price Contact Now

Product Name:	TOBO Copper Nickel Tube	Material:	NFA51 102 CuNi10 Fe1Mn
Type:	Seamless	Thickness::	0.1mm~50mm
Standard:	ASTM A511 A269 A312 A213,GB/T14976-2002 GB13296-91	Place Of Origin:	Shanghai China
Outer Diameter:	6mm-60 Mm
Highlight:	copper nickel pipe , copper nickel tubing

70/30 copper nickel tube ASTM B 111 C71500 Copper Nickel Tube Heat Exchanger Tubes

Product Description

90/10 Copper Nickel

We are reckoned amongst the trusted manufacturers and exporters of a wide range of 90/10 Copper Nickel Tubes. Known for their flexibility, high corrosion resistance, superior tensile strength, trouble free installation and maintenance, these are in demand in different industries. To ensure complete client satisfaction, the entire array of 90/10 Copper Nickel Tubes is examined thoroughly on standard quality parameters before final delivery.

Technical specifications:

Specification :
90/10 Copper Nickel	ASTM B 111 C 70600 ASME SB 111 C 70600 BS 2871 Part 3 CN 102 EN 12451 CuNi10 Fe 1Mn NFA51 102 CuNi10 Fe1Mn JIS H 3300 C 7060
95/5 Copper Nickel	ASTM B 111 C 70400 ASME SB 111 C 70400 BS 2870 CN 101 ISO 1635 CuNi5Fe1MN JIS C 2532 GCN10

70/30 Copper Nickel

Backed by latest technologies and dexterous workforce, we are able to manufacture, supply and export an impeccable gamut of 70/30 Copper Nickel Tubes, Cupro Nickel Tubes. These are machined in line with the set industry standards using qualitative raw materials that are sourced from authentic vendors of the domain. Our 70/30 Copper Nickel Tubes are sturdy in construction, dimensionally accurate, corrosion resistant, easy to install and maintenance free. Available in different standard specifications, the tubes can also be customized as per the clients' specifications at nominal prices.

Specification :
70/30 Copper Nickel	ASTM B 111 C 71500 ASME SB 111 C 71500 BS 2871 part 3 CN 107 EN 12451 CuNi 30 Fe 1 Mn NFA 51 102 CuNi 30 Fe 1 Mn JIS H 3300 C 7150

BS 2871 PART III/72 CN 102 & 07 EQUIVALENT SPEC.
ASTMB C70600 & 71500

Chemical Requirements	C70600	C71500
Copper	Remainder	Remainder
Iron	1.0 to 2.0%	0.4 to 1.0%
Nickel	10 to 11%	30 to 32%
Manganese	0.5 to 1.0%	0.5 to 1.5%
Total Imp.	0.30% max.	0.30% max.

Physical Properties
Condition	T.S. Kg/mm2	EL% Min	T.S. Kg/mm2	EL% Min
Annealed (O)	35	35%	37.5-46	30%
As manufactured (M)	44 min	-	51 min	-

Further Tests

Drift Test
Hydraulic Test
Microstructure
Eddy Current Optional

Uses
Gr I : Excellent corrosion resistant to turbulently used in condensers for coastal power plants, petroleum refineries and chemical plants.
Gr II : High impingement corrosion resistant to brackish sea water at velocities upto 3 to 4 m/sec used in desalination plants and other sea water condenser application

Specifications

Specifications
1.Item:Copper nickel pipe
2.Grade:C10200,C11000,C12000,C21000,C22000,etc.
3.OD:2~910mm,WT:0.2~120mm,Length:1~12m.

ASTM B 111 C71500 Copper Nickel Tube For Transportation / Military Industry 0

More details ,Pls find me on Skype: 17717932304 / Mail : summer@tobo-group.com

Copper nickel pipe/tube

1.	Item	Cu-Ni Alloy Tube
2.	Standard	ASTM,DIN,EN,ISO,JIS,GB
3.	Material	T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910, C10920,TP1,TP2,C10930,C11000,C11300,C11400,C11500,C11600,C12000, C12200,C12300,TU1,TU2,C12500,C14200,C14420,C14500,C14510,C14520, C14530,C17200,C19200,C21000,C23000,C26000,C27000,C27400,C28000, C33000,C33200,C37000,C44300,C44400,C44500,C60800,C63020, C68700,C70400,C70600,C70620,C71000,C71500,C71520,C71640,etc
4.	Shape	Round, square, rectangular, etc
5.	Specifications	Round	Wall thickness: 0.2mm~120mm
			Outside Diameter: 2mm~910mm
		Square	Wall thickness: 0.2mm~120mm
			Size: 2mm2mm~1016mm1016mm
		Rectangular	Wall thickness: 0.2mm~120mm
			Size: 2mm4mm~1016mm1219mm
6.	Length	5.8m,6m,11.8m,12m,or as required
7.	Hardness	1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc
8.	Surface	mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required
9.	Price Term	Ex-work,FOB,CFR,CIF,etc
10.	Payment Term	T/T, L/C, Western Union, etc
11.	Delivery Time	According to order's quantity
12.	Package	Export standard package: bundled wooden box, suit for all kinds of transport or be required
13.	Export to	Singapore,Indonesia,Ukraine,Korea,Thailand,Viet Nam,Saudi Arabia,Brazil,Spain, Canada,USA, Egypt, Iran, India, Kuwait,Dubai,Oman,Kuwait,Peru,Mexico, Iraq,Russia, Malaysia, etc
14.	Application	Copper pipe is the first choice of residential housing water pipes, heating, cooling pipes installed. Copper products are widely used in aviation, aerospace, ships, military industry, metallurgy, electronics, electrical, mechanical, transportation, construction and other fields of the national economy
