Home ProductsCopper Nickel Tube

C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner

Certification
Good quality Stainless Steel Elbow for sales
Good quality Stainless Steel Elbow for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner .

—— Thailand ---Dave Mulroy

ASTM A182 F55 Super Duplex Flange ,Good quality , we like that ! And delivery time in time also ,very professional.

—— USA ---Alfaro

I'm Online Chat Now

C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner

China C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner supplier
C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner supplier C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner supplier C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner supplier C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner supplier C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner supplier

Large Image :  C70600 70/30 90/10 B5 Copper Nickel Tube , C70500 Cupronickel Pipe For Air Conditioner

Product Details:

Place of Origin: China
Brand Name: TOBO
Certification: SGS
Model Number: TOBO-45

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: 1 USD PER PCS
Packaging Details: by Plywood case, about 1 metric ton per case.
Delivery Time: 7-15 WORK DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 TON PER MONTH
Contact Now
Detailed Product Description
Product Name: TOBO Copper Nickel Tube Material: C70600/70500
Length: 100mm-8000mm Thickness:: 0.35 -12mm
Standard: ASTM B111 Place Of Origin: Shanghai China
Outer Diameter: 2mm~914mm

C70600 70/30 Copper Nickel tubes C70500 Cupronickel pipe 90/10 B5 pipe for air conditioner

Packaging & Delivery

Packaging Details

Wooden boxes, pallet, according to customer requirements,

Delivery Time

Shipped in 15 days after payment


Product Description



Copper Nickel tubes C70400 Cupronickel pipe 95/5 B5 pipe

Chemical composition

Cu+Ag : REM; NI+Co: 4.8 - 6.2 % ; Pb: max 0.05% ;Fe: 1.0-1.7% ;Zn: max 0.3% ; Mn: 0.3 -1.0%

Size,Temper,

Soft : OD:5 -30MM WT: 0.35 - 5 mm Length:<8000mm

half and hard : OD:5 -260MM WT: 0.35 - 12mm Length:<20000mm

OD Range min -0.1mm~ -0.12mm; max -0.5 ~ - 0.8mm

Mechanical Properties

Soft: Tensile Strength Rm (N/mm2) Min 290; ElongationA% Min 30%

Half Hard: Tensile Strength Rm (N/mm2) Min 345; ElongationA% Min 10%

Hard: Tensile Strength Rm (N/mm2) Min 480;



Copper nickel alloy of copper with nickel, Cu Ni, silvery white, with metallic luster, named copper nickel alloy. Copper and nickel can be infinitely dissolve each other, so as to form a continuous solid solution, namely, no matter how much proportion to each other, while the constant α – phase alloy. When the nickel melt into the copper D200, content is more than 16%, the alloy color becomes relatively near white as silver, nickel content is high, the color is white, but, after all, and copper fusion, as long as the nickel content ratio does not exceed 70%, the naked eye can see the Yellow copper. And the content usually copper nickel for the general 25%. Copper is copper nickel alloy bills, density between copper and nickel 8.9-8.8
Nickel copper nickel alloy (also known as Yang Baitong), use: crystal oscillation components, crystal shell, a device for slides, medical machinery, building materials etc..

In copper alloy, copper nickel alloy with excellent corrosion resistance, and easy molding, machining and welding structure, widely used in shipbuilding, petroleum, chemical, construction, electric power, precision instruments, medical equipment, instruments and other departments for corrosion resistance. Some copper and special electrical properties, can produce resistance element, thermocouple compensation wire materials.

Other Grade : C70100, C70200,C70400,C70500,C70600, C70610,C70690,C71100,C71300



Specifications (for reference only)

OD: 4.0mm, Thickness: 0.40/0.45/0.50mm

OD: 4.76mm=3/16'', Thickness: 0.35mm - 1.00mm

OD: 6.00mm, Thickness: 0.35mm - 1.00mm

OD: 6.35mm=1/4'', Thickness: 0.35mm - 1.20mm

OD: 7.94mm=5/16'', Thickness: 0.30mm - 1.20mm

OD: 8.00mm, Thickness: 0.30mm - 1.20mm

OD: 9.52mm=3/8'', Thickness: 0.30mm - 1.50mm

OD: 12.00mm, Thickness: 0.35mm - 1.50mm

OD: 12.70mm=1/2'', Thickness: 0.35mm - 1.50mm

OD: 14.00mm, Thickness: 0.40mm - 1.50mm

OD: 15.00mm, Thickness: 0.40mm - 1.50mm

OD: 15.88mm=5/8'', Thickness: 0.40mm-1.50mm

OD: 16.00mm, Thickness: 0.50mm - 1.50mm

OD: 19.05mm=3/4'', Thickness: 0.60mm - 1.50mm

OD: 28.57mm = 1 1/8'', Thickness: 0.70mm - 1.50mm

Features:



    • Excellent corrosion resistant
    • Excellent strength
    • High conductivity
    • Dimensional accuracy



Copper Nickel Tube is mainly preferred when the severity of service condition (Cooling water, steam, condensate, temperature etc.) is such as to virtually rule out all other copper metals. Due to its hardness and to the type of oxide whereby its surfaced is self protected and widely used in sea water. It has very good corrosion resistance to clean or moderately polluted marine or estuary water, even containing dissolved incondensable gases. This alloy is virtually immune From stress-corrosion cracking and hot spot denickelification. We offer Copper Nickel 70/ 30, 90/ 10 and 95/ 5.

Capabilities

Production Range : Rods/ Wires / Hex / Tubes/ Square / Flat / Profiles / Hollows
Tubes 6.35 mm to 110 mm
Round Wires 1 mm to 11 mm
Round Rods 1.2 mm to 250 mm
Hex 5 mm to 60 mm
Square 4 mm to 60 mm
Flat 5 mm Min Thickness and Max Width 120 mm
Profile As per Customer Drawing
Hollow Rods Min Bore Size 20 mm and Max OD 130 mm

Copper Nickel
95/5 Copper Nickel
CuNi 2.2
CuNi 6
CuNi 11



ASTM B 111 C71500 / ASME SB 111 C71500/ BS 2871 part 3 CN 107 / EN 12451 CuNi3Fe1Mn / CW354H NFA 51 102 CuNi30Fe1Mn/ JIS H 3300 C7150
ASTM B 111 C70600 / ASME SB 111 C 70600 / BS 2871 part 3 CN 102/EN 12451 CuNi10 Fe1Mn NFA51 102 cUnI 10 Fe Mn JIS H 3300 C7060 / CW352H
ASTM b 111 C 70400 / ASME SB 111 C70400/ BS 2870 CN 101 / ISO 1635 Cuni5Fe Mn /

JIS C2532 / GCN10
ASTM C70200
ASTM C70500
ASTM C70800



Note:All size can be customerize.

Quality Policy

Fully satisfy our customers, making products of copper and its alloys, using processes that are continuously improved in order to:
- Meet customer requirements.

- Control and prevent any environmental impact.

- Control and prevent risks in the process.

- Comply with legal and other applicable requirements.



Product Description

Good price copper nickel alloy monel 400 pipe / tube



Material Copper nickel pipe
Construction Tube(Pipe), Wire, Ingot, Rod(Bar), Plate, Strip, Foil or Customized
Shape Round, Square, Flat, Hexagon, Oval,Half-round or Customized
Dimension Standard or Customized
Standard GB/T,JIS,ASTM, ISO, DIN, BS, NF etc.
Hardness 1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard.
Place of origin Shanghai , China
Package Plastic film + Wooden case or as per customer requirement
Surface Polished,bright,oiled,hair line,brush,mirror,or as required
MOQ Negotiable
Deliver time According to order's quantity.
Shipment By sea, by air, DHL, UPS, FedEx etc. or as required
Application Electric light industry, machinery manufacturing, Building industry ,defense industry, and other fields Manufacturing industrial .valves and fittings,Instrument sliding bearing



Specification



The Chemical Composition of High Copper Alloys in ASTM

Copper

Alloy No

Cu Fe Sn Zn Al Pb P
C19419 96.7min 1.7-2.3 .05-.18 .10-.40 -- .02 .03
C19450 Rem. 1.5-3.0 .8-2.5 -- -- -- .005-.05
C19500 96.0min 1.0-2.0 .10-1.0 .20 .02 .02 .01-.35
C19520 96.6min .50-1.5 -- -- -- .01-3.5 --
C19700 Rem. .30-1.2 .20 .20 -- .05 .10-.40
C19710 Rem. .05-.40 .20 .20 -- .05 .07-.15
C19720 Rem. .05-.50 .20 .20 -- .05 .05-.15
C19750 Rem. .35-1.2 .05-.40 .20 -- .05 .10-.40
C19800 Rem. .02-.50 .10-1.0 .30-1.5 -- -- .01-.10
C19810 Rem. 1.5-3.0 -- 1.0-5.0 -- -- .10
C19900 Rem. -- -- -- -- -- --
C19910 Rem. .17-.23 -- -- -- -- --

Our service
1.We are the specialized supplier of ss ,steel and copper products, can provide the best price!
2.We have more than 4 years experience in exporting products to worldwide countries, can provide the high quality products!
3.We have five thousand tons of stock in warehouses with abundant capital. Furthermore, we offer charge sales, credit and -day 24-hour services.
4.Wide excellent experiences with after-sale service.
5.Professional packing teams which keep every packing safely.
6.Trial order can be done in one week.

High Quality Copper Nickel CuNi Condenser Tube / Pipe C706 90/10

Packaging & Shipping






High Quality Copper Nickel CuNi Condenser Tube / Pipe C706 90/10



FAQ

1.Can we supply the sample ?

Yes,we can supply the sample of copper nickel pipe.You can tell us the detail size.



2.Can we accept customize?

Yes,we can.We can manufacture as customer's requirement.You can send the CAD or drawing to us.



3.Quality problem?

According to the standard for production.And the products must pass the quality inspection department.We also accept Third Part Inspection.



4.Delivery time?

Prompt delivery for standard size,or under the contract.



5.Payment term?

Under the contract.



6.Other problem?

You can contact our customer service staff to ask help.







H68 end caps copper nickel pipe
