Copper Nickel 70/30 Elbow CuNi Long Radius Elbow 90° DIN 86090

Basic Information

Place of Origin:	Shanghai, China (Mainland)
Brand Name:	TOBO
Certification:	SGS/BV/ABS/LR/TUV/DNV
Model Number:	Copper Nickel 70/30

Minimum Order Quantity:	1pieces
Price:	Negotation
Packaging Details:	Ply-wooden case or plate
Delivery Time:	7~30days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	50000 Piece/Pieces per Month

Get Best Price Contact Now

Material:	Copper Nickel 70/30	Type:	90 Degree LR
Size:	30MM-610MM	Head Code:	Round
Product Name:	90 Degree LR Elbow	Usage:	Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding Etc
OD:	57MM	Wall Thickness:	1.5MM
Highlight:	butt welded pipe fittings , butt weld tube fittings

Copper Nickel 70/30 Elbow CuNi Long Radius Elbow 90° DIN 86090

Product Description

Outside diameter of pipe		DIN86090
Outside diameter of pipe		10bar				14bar
ØD		Wall	Radius		Theoretical	Wall	Radius		Theoretical
ØD		thickness			weight	thickness			weight
nominal	actual	e	a	s	Kg/piece	e	a	s	Kg/piece
inch	mm	mm	mm	mm	Kg/piece	mm	mm	mm	Kg/piece
1	30	1.5	30	12	0.02	1.5	30	12	0.02
1.25	38	1.5	32.5	14	0.04	1.5	32.5	14	0.04
1.5	44.5	1.5	40	17	0.06	1.5	40	17	0.06
2	57	1.5	52.5	22	0.1	1.5	52.5	22	0.1
2.5	76.1	2	70	29	0.22	2	70	29	0.22
3	88.9	2	82.5	34	0.32	2.5	82.5	34	0.4
4	108	2.5	100	41	0.58	2.5	100	41	0.58
5	133	2.5	125	52	0.9	3	125	52	1.08
6	159	2.5	150	62	1.3	3	150	62	1.56
7	193.7	2.5	180	75	1.9	3.5	180	75	2.66
8	219.1	3	210	87	3	3.5	210	87	3.5
10	267	3	255	106	4.4	4	255	106	5.87
12	323.9	4	305	126	8.6	5	305	126	10.75
14	368	4	352.5	146	11.3	5.5	352.5	146	15.54
16	419.1	4	400	166	16.4	6	400	166	21.87
18	457.2	4	455	188	20.4	6	455	188	30.6
20	508	4.5	505	209	28.1	6.5	505	209	42.15
24	610	5	610	253	40.9	8	610	253	65.45

Brand Name	TOBO
Product Name	90 Degree LR Elbow
Item	Copper Nickel 70/30 Elbow
Certification	SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Place of Origin	Shanghai China (Mainland)
Size	DN15-DN1200 / 1-48 inch
Material	Carbon steel(ASTM A105,A350LF2,A350LF3,)
	Stainless steel(ASTM A182 F304, F304L,F316,F316L,F321, F347,F310F44F51,A276 S31803, A182,
	F43, A276 S32750,A705 631,632,A961, A484,
	Alloy steel(ASTM A694 F42,F46,F52,F56,F60,F65,F70, A182 T91 (P91)
	F12,F11,F22,F5,F9,F91,F1ECT)
Standard	DIN,EN,ASTM,BS,JIS,GB,ASME(ASME16.9/16.20)
Application	Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc
Minimum Order Quantity	1kg
Price	Depending on quantity
Payment Terms	T/T or Western Union or LC
Supply Ability	30tons per month
Delivery Time	10-50 days depending on quantity
Packaging Details	PLY-WOODEN CASE

Product Name	Nickel Alloy Pipe fittings	Product Type	buttweld
Size	1/2 Inch (16 mm OD) to 16 Inch (419 mm OD)	Cu(Min)	90%
Connection	Welding	Shape	Equal
Wall Thickness	Sch5S-Sch160, XS,XXS	Applications	Petroleum,chemical,power,gas,metallurgy, shipbuilding, construction, etc
Standard	EEMUA,ANSI/ ASTM B16.9, DIN, JIS, ISO, GB AND etc

Minimum Order Quantity:	1pcs
Price:	Depending on quantity
Payment Terms:	T/T or Western Union or LC
Supply Ability:	3,0000pcs per month
Delivery Time:	10-100 days depending on quantity
Packaging Details:	PLY-WOODEN CASE OR PALLET
