Duplex Stainless Steel Plate Galvanized Polish For Industry / Medical Equipment

  • Duplex Stainless Steel Plate Galvanized Polish For Industry / Medical Equipment
  • Duplex Stainless Steel Plate Galvanized Polish For Industry / Medical Equipment
  • Duplex Stainless Steel Plate Galvanized Polish For Industry / Medical Equipment
Place of Origin Shanghai
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number 001
Minimum Order Quantity 5 tons
Price USD Depending on material and qtys.
Packaging Details Wooden case or pallet as Request
Payment Terms T/T
Supply Ability 500 tons per month
Product Details
Material S31803/s32205/s32750/s32760 Brand TOBO/TPCO/TISCO/VALIN/METAL
Thickness 0.1mm -200mm Wide 1000-2000mm
Grade 200series,300series,400series Standard JIS, AISI, ASTM, GB, DIN
Application Industry,medical Equipment,kitchen Length As Required
Highlight

Stainless Steel Coils

,

Stainless Steel Flat Sheets
Leave a Message
Product Description

Duplex Steel S31803/S32205/S32750/S32760 Hot/Cold Dipped Galvanized Steel Coil / Galvanized Steel Sheet

Quick Details

Standard: AISI, ASTM, BS, DIN, GB, JIS, AISI, ASTM, BS, DIN, GB, JIS Grade: DX51D, SGCC, etc Thickness: 0.15-4.0mm
Place of Origin: Shanghai, China (Mainland) Brand Name: TOBO Model Number: 0.15-4.0mm*100-1800mm
Type: Steel Coil Technique: Cold Rolled, Cold Rolled Surface Treatment: Galvanized, Passivation, anti finger, phosphatizing, oil, passivation oiled.
Application: Container Plate, Construction, Light industry, Automobile, etc Special Use: High-strength Steel Plate Width: 100-1800mm
Length: Customized Product Name: Prime HBIS SGCC hot dipped galvanized steel coil price Certificate: ISO
Yield Strength: 280 to 350Mpa Surface Finish: Chromatic, un-oiled and oiled Zinc Coating: 40-275g/m2
Inside Diameter: 508 and 610mm

Packaging & Delivery

Packaging Details: Export standard, plastic film+water proof paper + steel plate+ packing steel strip. One coil per bundle, inner is the protecting humidity-proof wax paper. Medium is plastic film. Outer is all round steel packing. Coil to be laid on single pallet (one pile per pallet).
Delivery Detail: Shipped in 3 days after payment
Product Description
Product Name Prime HBIS SGCC hot dipped galvanized steel coil price
Supplier HBIS, TangSteel, ShouSteel, AnSteel(Sochi Olympic Supplier), Guofeng, Tianjin Metallurgical NO.1 and another 6 private steel mills.
Steel Grade ASTM: CS (A B C), DS, DDS, EDDS, SS, HSLAS;
EN: DX51D to DX56D, S220GD to S550GD;
JIS: SGCC, SGCD, SGC340 to SGC570; SGH340, SGHC
Size 0.15-4.0mm*100-1800mm
Length Coil: 3-6ton per coil
Sheets: For exporting length , generally, 5-5.8meters for 20ft container.
Sheets: Exporting and fixed length , generally , 6-12m for 40ft container.
Also could be fixed length like 5.8m, 6m, and 11.8m as per your request.
Zinc Coating 40-400g/m2
Surface Treatment Chromated(Cr6) passivation
Chromated(Cr6) and oiled
Cr3 Chromated(Environmental)
Cr3Chromated(Environmental) and oiled
Chrome free
Chrome free and oiled
Oiled
Phosphatizing
Anti-finger
Skin-passed
Non-treatment
Technique Cold Rolled
Spangle Zero spangle, regular spangle
Coil diameter 508mm(20 inch) 610mm (24 inch)
Basic materials Cold Rolled Steel, Hot Rolled Steel
Basic steel type CQ, DQ, DDQ, LFQ, DQSK
Surface Quality FB(03), FC(04), FD(05)
Application Civil use: Water containers, chimney, shells of doors and board, all kinds of containers for grains and dry food, kitchen utensils.
Constructions: Roofing, wall, water fender, warehouse walls, doors, shells etc.
Household appliances: Refrigerator, washer, shower, dust collector etc.
Auto Industry: Car shell, spare parts, oil box, water box etc.
Available Painting OF (Prepainted galvanized steel coils) printed PPGI coils:
Category of Painting Item Code
Polyester PE
High-durability polyester HDP
Silicon modified polyesters SMP
Polyvinylidene fluoride PVDF
Easy-Cleaning —
Painting Thickness Top side: 20+5microns;
Bottom side: 5~7microns.
Color System Produce according to RAL Color System or as per buyer’s color sample.
Painting structure Top surface Bottom surface
Primer coating No coating 1/0
Primer coating Primer coating 1/1
Primer coating + Finish coating No coating 2/0
Primer coating + Finish coating Primer coating or single back coating 2/1
Primer coating + Finish coating Primer coating + Finish back coating 2/2
