Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance

  • Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance
  • Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance
  • Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance
  • Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance
  • Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance
  • Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number Monel K500 UNS N05500
Minimum Order Quantity 300 Kilogram/Kilograms
Packaging Details Export standards or customer requirements
Delivery Time 7-30 working days after received deposit
Payment Terms L/C, T/T, Western Union
Supply Ability 50 Metric Ton/Metric Tons per Month
Product Details
Product Name Tee Product Type Steel Pipe
Grade 200 Series &300 Series &400 Series Shape Round
OD 168.3 - 3048 Mm Surface Painted
Application Oil Pipe Techinque Cold Drawn
Highlight

marine stainless steel tubing

,

seamless stainless steel tube
Leave a Message
Product Description

Monel K500 UNS N05500NACE MR0175 3'' Tee STD Pipe Fittings



What are the characteristics of Monel K500?

· Corrosion resistance in an extensive range of marine and chemical environments. From pure water to non-oxidizing mineral acids, salts and alkalis.

· Excellent resistance to high velocity sea water

· Resistant to a sour-gas environment

· Excellent mechanical properties from sub-zero temperatures up to about 480C

· Non-magnetic alloy

Chemical Composition, %

Ni Cu Al Ti C Mn Fe S Si
63.0-70.0 Remainder 2.30-3.15 .35-.85 .25 max 1.5 max 2.0 max .01 max .50 max

In what applications is Monel K-500 used?

· Sour-gas service applications

· Oil and gas production ety lifts and valves

· Oil-well tools and instruments like drill collars

· Oil well industry

· Doctor blades and scrapers

· Chains, cables, springs, valve trim, fasteners for marine service

· Pump shafts and impellers in marine service



Product Specification
Name pipe fitting elbow
Material stainless steel ASTM A240 304 304L 316L 321 321H 347 347H 904L ASTM A789 S31803 S32205 S32750
Carbon Steel ASTM A234 WPB A420 WPL3 WPL6 A516 GR70 GR65 GR60 GR55 ISO3183/API 5L L36/X52 L415/X60 L450/X65 L485/X70?
Alloy Steel ASTM A335 P11 P22 SA387 GR.11 GR.22
Titanium Gr1 Gr2 Gr3 Gr5 Gr7 Gr12
Copper/Brass We can also produce according to customer's requirements
Standard?? ASME B16.9, ANSI B16.9, ASTM , JISB2312,DIN,BS, GBT12459-05, GB13401-05,GOST
ASME B16.9-2007,MSS SP 43-1991,MSS SP-75,ASTM B363
Wall thickness

Sch5S, Sch10S, Sch40S, Sch80S

Sch10,Sch20,Sch30,STD,Sch40,Sch60,XS,Sch80,Sch100,Sch120,Sch140,Sch160,XXS,
Size 1/2"-96" ? DN15-DN2400
Type Butt welded or Seamless
Shape Equal or Reducing
Product

1.Elbow?L/R & S/R (45/90/180 DEG)

according to customer's requirement can produce the other's degree, such as 22.5 degree 30 degree 60 degree etc.
2. Tee(Straight and Reducing)
3. Reducer(Concentric and Eccentric)
4. Cross
5. Cap(Round and Elliptical)
6. Stub End
Quality Control Good quality control system which covers every process of the manufacturing-Raw material inspection,cutting,bending,sizing,shot blasting,beveling,coating,marking,packing,delivery;
Application Pipe fitting is the occupation of installing or repairing piping or tubing systems that convey liquid, gas, and occasionally solid materials. This work involves selecting and preparing pipe or tubing, joining it together by various means, and the location and repair of leaks.
Surface Black painting ; Pickling ; Sand blasting
Certificate ISO9001 ; ISO9001:2008
Package Wood case or Wooden pallets or according to the customer's requirements.
Features

1) Chemical and Physical characteristic: durable, corrosion resistant and high-temperature resistant

2) We also produce pipes with special specifications according to customers' requirements;
Lead Time Within 30 days or according to the customer's requirements.
MOQ 1 Piece
OEM YES



Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance 0Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance 1Round Stainless Steel Seamless Pipe Fittings Cold Drawn Excellent Resistance 2
