TOBO GROUP
TOBO International Trading(Shanghia)Co.,Ltd Tianda Oil Pipe Co., Ltd
TOBO Pipeline Equipment Co.,Ltd TPCO & TISCO Pipe(Tianjin)Co.,Ltd.
Place of Origin: | China |
---|---|
Brand Name: | TOBO |
Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
Model Number: | A335 Alloy Steel pipe P22 |
Minimum Order Quantity: | 1 pc |
Price: | USD Negotiated |
Packaging Details: | Standard Sea-worthy Packing wooden cases or plastic by bundles as customer's required |
Delivery Time: | 25 work days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 1200 Metric Ton/Metric Tons per Week |
Material: | ASTM A335 P11 P22 P33 P91 A106 High Pressure Steam Boiler Pipe Carbon | Welding Type: | Seamless |
---|---|---|---|
Technique: | Cold Rolled Hot Rolled | Surface: | Varnished / As Per Customer's Requirements |
Thickless: | 0.5-50 Mm | Type: | Mill Test Certificate Steel Pipe |
O0.125 - 72 Inchuter Diameter: | 0.5 - 24 Inch | Application: | Boiler Pipe |
Highlight: | P33 Steam Boiler Pipe,ASTM A335 Steam Boiler Pipe,50mm Thick Steam Boiler Pipe |
ASTM A335 P11 P22 P33 P91 A106 high pressure steam boiler pipe carbon
ASTM A335 /A335M ASME SA335 pipes shall be made by the seamless process and shall be either hot-finished or cold drawn with the finishing treatment.
ASTM A335 /A335M covers nominal wall and minimum wall seamless ferritic alloy-steel pipe intended for high-temperature service. Pipe ordered to this specification shall be suitable for bending, flanging (vanstoning), and similar forming operations, and for fusion welding. Selection will depend upon design, service conditions, mechanical properties, and high-temperature characteristics.
Grade
|
P11
|
P12
|
P22
|
P91
|
C
|
0.05-0.15
|
0.05-0.15
|
0.05-0.15
|
0.08-0.12
|
Mn
|
0.30-0.60
|
0.30-0.61
|
0.30-0.60
|
0.30-0.60
|
P
|
≤0.025
|
≤0.025
|
≤0.025
|
≤0.020
|
S
|
≤0.025
|
≤0.025
|
≤0.025
|
≤0.010
|
Si
|
0.50-1.00
|
≤0.50
|
≤0.50
|
0.20-0.50
|
Cr
|
1.0-1.50
|
0.80-1.25
|
1.90-2.60
|
8.0-9.50
|
Mo
|
0.44-0.65
|
0.44-0.65
|
0.87-1.13
|
0.85-1.05
|
V
|
|
|
|
0.18-0.25
|
Nb
|
|
|
|
0.030-0.070
|
N
|
|
|
|
≤0.40
|
AI
|
|
|
|
≤0.02
|
Others
|
|
|
|
Cb 0.06-0.10
Ti 0.01max
Zr 0.01max
|
Mechanical Properties
|
||||
Grade
|
Tensile
|
Yield
|
Elongation
|
Hardness
|
Strength (Mpa)
|
Strength (Mpa)
|
(%)
|
|
|
P11
P12
|
≥415
|
≥220
|
≥30
|
≤89HRB
|
P22
|
≥415
|
≥220
|
≥30
|
≤89HRB
|
P91
|
≥585
|
≥415
|
≥20
|
91HRB-25HRC
|
Grade
|
UNS
Number
|
Heat Treat Type
|
Austenitizing/ Solutioning
Temperature, min or range °F [°C] |
Subcritical Annealing or Tempering
Temperature, Min or range °F [°C] |
P11
|
K11597
|
full or is othermal anneal normalize and temper
|
|
1200 [650]
|
P12
|
K11562
|
full or isothermal anneal normalize and temper subcritical anneal
|
|
1200 [650]
1200-1300 [650 to 705] |
P22
|
K21590
|
full or isothermal anneal normalize and temper
|
|
1250 [675]
|
P91
|
K91560
|
normalize and temper
quench and temper |
1900-1975[1040-1080]
1900-1975[1040-1080] |
1350-1470[730-800]
1350-1470[730- |
