1 1/2" CL2500 BL Flange Ring Joint Face Incoloy Alloy 825 ASTM B564UNS NO8825 ASME B16.5

  • 1 1/2" CL2500 BL Flange Ring Joint Face Incoloy Alloy 825 ASTM B564UNS NO8825 ASME B16.5
  • 1 1/2" CL2500 BL Flange Ring Joint Face Incoloy Alloy 825 ASTM B564UNS NO8825 ASME B16.5
  • 1 1/2" CL2500 BL Flange Ring Joint Face Incoloy Alloy 825 ASTM B564UNS NO8825 ASME B16.5
Place of Origin CHINA
Brand Name TOBO
Certification BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number Forged Steel Flange
Minimum Order Quantity 0.5-1 tons
Price negotiable
Packaging Details in plastic bags then in bundles
Delivery Time According to the qty
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 6000TONS/MONTH
Product Details
Logo Customized Logo Keyword Steel,A105,NPT Threaded Blind Flange,weld Neck Flange Ansi 150 Rf,Titanium
Application Gas, Petroleum, Auto Parts, Concrete Pump, Water Product Name Flange
Material Alloy 825 Pressure Class150,150#-2500#,5K-30K
Standard Or Nonstandard ASME B16.5 Type Blind,weld Neck Flange,threaded,Pipe Flange,socket Welding
Highlight

1 1/2 inch Incoloy alloy 825 flange

,

CL2500 alloy 825 flange ring

,

ASME B16.5 alloy 825 flange
Leave a Message
Product Description

1 1/2" CL2500 BL Flange Ring Joint Face Incoloy Alloy 825 ASTM B564UNS NO8825 ASME B16.5

We are the manufacturer &exporter of ASTM B564 Incoloy 825 Flanges, N08825 Slip-On Flange,Incoloy 825 Weld Neck Flange,N08825 Blind Flange,Incoloy 825 weld neck flange,alloy 825 flange

Incoloy 825 flanges,also refers to Alloy 825 flange or N08825 Flanges has excellent resistance to chloride-ion-induced stress corrosion cracking, reducing environments containing phosphoric and sulfuric acids, oxidizing environments containing nitric acid and nitrates, and pitting, crevice corrosion and intergranular corrosion. It has good mechanical properties at cryogenic temperatures to moderately high temperatures up to 538℃.

Incoloy 825 flangeChemical composition:

Alloy % Ni Cr Fe C Mn Si Cu Mo Al Ti P S
825 Min. 38 19.5 balance       1.5 2.5 1.0 0.6
Max. 46 23.5 balance 0.05 1 0.5 3 3.5 0.2 1.2 0.02 0.03

Incoloy 825 Flange Physical properties:

Density 8.1 g/cm³
Melting range 1370-1400℃

Incoloy 825 Flange Alloy 825 minimum mechanical properties in the room temperature:

Alloy state Tensile strength Rm N/mm² Yield strength R P0. 2N/mm² Elongation A 5 % Brinell hardness HB
825 550 220 30 ≤200

ASTM Specifications

Pipe Smls Sheet/Plate Bar Forging Fitting
B423 B424 B425 B564 B366, B564



1 1/2" CL2500 BL Flange Ring Joint Face Incoloy Alloy 825 ASTM B564UNS NO8825 ASME B16.5 0

1 1/2" CL2500 BL Flange Ring Joint Face Incoloy Alloy 825 ASTM B564UNS NO8825 ASME B16.5 1

Why Choose Us

1.One-Stop Service,One Single Source.

2.No MOQ.

3.Best quality,competitive price

4.Fast Reply.

5.On-Time Delivery

6.Professional sales and technical team .

FAQ

Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.(View Mor)

Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.

Q3: Will my drawing be e after you get it?
A3: Yes, we will not release your design to third party unless with your permission.

Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.

Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
