4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112

4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112
4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112 4 4 4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112 4 4 4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112 4 4
Basic Information
Place of Origin: CHINA
Brand Name: TOBO
Certification: BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: ASTM A403 Grade WPS31254
Minimum Order Quantity: 0.5-1 tons
Price: negotiable
Packaging Details: in plastic bags then in bundles
Delivery Time: According to the qty
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 7500 tons per year
Get Best Price Contact Now
Type: Elbow,Coupling,seamless,welding Head Code: Round,Square,Hexagon
Packing: Inner Poly Bag,Plastic Bag+Carton,plywood Case Or Pallet,According Customer's Requesment Color: Customer's Requirement
Surface: As Customer's Requirement Size: Customized Size
Application: Connect Pipes,oil Pipelines,Food,Industry,Fire Shape: Equal,ROUND,Equal & Reducing
Thickness: Standard Schedule
Highlight:

WPB Stainless Steel Elbow Fitting

,

Equal Seamless Stainless Steel Pipe

,

45 Degree Elbow Fitting

4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112





ASTM A234 steel pipe fittings dimensions

Standards: ANSI /ASME B16.9, B16.28, MSS-SP-43.
Outer Diameter Range: 1/2” to 48”
Thickness Range: SCH 10, sch 20, SCH 40, SCH STD, SCH 80, SCH XS, SCH 160, SCH XXS etc.
Steel pipe fittings manufacturing types in forged, threaded, butt weld, and seamless.

Alloy steel pipe fittings grades in ASTM A234

The alloy steel pipe fitting is fabricated with alloy elements in such as Chrome, Molybdenum, Nickel alloy, Hastelloy alloy, Monel, Inconel, and etc. To get a higher pressure ratings, better strength, good corrosive resistance, and longer durability. It is widely used in oil and gas pipelines, chemical industries, power plants, nuclear power sites, and in server conditions.

Alloy steel pipe fittings includes buttweld fittings, alloy steel long radius bend, alloy steel forged fittings and so on.

The alloy steel buttweld fittings adopts ASTM A234 standard, has WP1, WP5, WP11, WP12, WP22,WP23 and WP91 grades. Class level in CL1, CL2, CL3.

ASTM A234 alloy steel pipe fittings includes alloy steel elbows in long and short radius, alloy steel eccentric & concentric reducer, alloy steel caps & crosses, alloy steel couplings, alloy steel tees, alloy steel nipples, alloy steel caps and etc more forms. It has seamless, welded and fabricated types.

For alloy steel forged fittings, it adopts ASTM A182 standard refers to steel pipe flanges. Material standard in ASTM A182 F1, F5, F9, F11 Class 1, F12 Class 1, F22 Class 1 ETC.



Chemical Composition

Grade and Marking Symbol
Composition, %
C
Mn
P
S
Si
Cr
Mo
WPB
0.30 max
0.29-1.06
0.050
0.058
0.10 min
0.40 max
0.15 max
WPC
0.35 max
0.29-1.06
0.050
0.058
0.10 min
0.40 max
0.15 max
WP1
0.28 max
0.30-0.90
0.045
0.045
0.10-0.50
…
0.44-0.65
WP12 CL1, WP12 CL2
0.05-0.20
0.30-0.80
0.045
0.045
0.60 max
0.80-1.25
0.44-0.65
WP11 CL1,
0.05-0.15
0.30-0.60
0.030
0.030
0.50-1.00
1.00-1.50
0.44-0.65
WP11 CL2, WP11 CL3
0.05-0.20
0.30-0.80
0.040
0.040
0.50-1.00
1.00-1.50
0.44-0.65
WP22 CL1, WP22 CL3
0.05-0.15
0.30-0.60
0.040
0.040
0.50 max
1.90-2.60
0.87-1.13
WP5 CL1, WP5 CL3
0.15 max
0.30-0.60
0.040
0.030
0.50 max
4.0-6.0
0.44-0.65
WP9 CL1, WP9 CL3
0.15 max
0.30-0.60
0.030
0.030
1.00 max
8.0-10.0
0.90-1.10
WPR
0.20 max
0.40-1.06
0.045
0.050
…
…
…
WP91
0.08-0.12
0.30-0.60
0.020
0.010
0.20-0.50
8.0-9.5
0.85-1.05
WP911
0.09-0.13
0.30-0.60
0.020
0.010
0.10-0.50
8.5-9.5
0.90-1.10

Tensile Requirements

Grade and Marking Symbol
WPB
WPC, WP11 CL1, WP12 CL2
WP1
WP11 CL1, WP22 CL1, WP5 CL1, WP9 CL1
WPR
WP11 CL3, WP22 CL3, WP2 CL3, WP9 CL3
WP91
WP911
WP12 CL1
Tensile strength, range Ksi [MPa]

60-95

[415-655]
70-95 [485-655]
55-80 [380-550]

60-85

[415-585]
63-88 [435-605]
75-100 [520-690]
85-110 [585-760]
90-120 [620-840]
60-85 [415-585]
Yield strength, min, Ksi [MPa] (0.2% offset or 0.5% extension- under-load)
35 [240]
40 [275]
30 [205]
30 [205]
46 [315]
45 [310]
60 [415]
64 [440]
32 [220]


ASTM A234 WPB steel pipe fitting chemical and mechanical features

Grade WPB fittings made from the steel pipes or plates maximum C is 0.35%.

Forging fittings Carbon content 0.35% maximum and Silicon content 0.35% maximum, no minimum.

For each reduce of 0.01 of Carbon content, Manganese maximum content increase 0.06%, up to the maximum 1.35% for Mn.

Copper, Nickel, Niobium and Molybdenum sum content shall not exceed 1.00%.

Niobium + Molybdenum shall not exceed 0.32%.

4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112 0

4" 45° Elbow Long Radius ASME B16.9 BW WROUGHT-S ASTM A 234 GR. WPB GA-E-60112 1







FAQ



1.How can I get the price?
-We usually quote within 24 hours after we get your inquiry(Except weekend and holidays).
-If you are very urgent to get the price, please email us
or contact us in other ways so that we can offer you a quote.
2. Can I buy samples placing orders?
-Yes.Please feel free to contact us.
3.What is your lead time?
-It depends on the order quantity and the season you place the order.
-Usually we can ship within 7-15 days for small quantity,
and about 30 days for large quantity.
4.What is your payment term?
-T/T,Western Union,MoneyGram,and Paypal.This is negotiable.
5.What is the shipping method?
-It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect).
Please confirm with us before placing orders.
6.How do you make our business long-term and good relationship?
-1. We keep good quality and competitive price to ensure our customers benefit ;
-2. We respect every customer as our friend and we sincerely do business
and make friends with them,no matter where they come from.
