TP304 TP304L TP316L 304 Stainless Steel Seamless Pipe ASTM A213

  • TP304 TP304L TP316L 304 Stainless Steel Seamless Pipe ASTM A213
  • TP304 TP304L TP316L 304 Stainless Steel Seamless Pipe ASTM A213
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number ASTM A213
Minimum Order Quantity 1TON
Price negotiable
Packaging Details Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time 30DAYS
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 500 TONS /MONTH
Product Details
Standard Grade 304 Color White Silver Gold
Types Stainless Steel Instrumentation Tubing Outer Diameter 6mm-710mm
Highlight

304 stainless steel seamless pipe

,

TP316L stainless steel pipe ASTM A213

,

stainless steel seamless pipe with warranty
Leave a Message
Product Description

Grade 304 Stainless Steel Instrumentation Tubing ASTM A269 3/8'' X 0.035'' X 20''



Categories Stainless Steel Instrumentation Tubing
Brand Name: TOBO GROUP
Model Number: TP304 TP304L TP316L Etc.
Certification: ISO9001:2008
Place Of Origin: CHINA
MOQ: Negotiation
Price: Negotiation
Payment Terms: T/T Or L/C
Supply Ability: 1000 TONS / MONTH
Delivery Time: 10 DAYS
Packaging Details: PLY-WOODEN CASE / BUNDLE WITH PLASTIC CAP
WT Range: 0.5MM - 3.05MM
Standard Of Tube: ASTM A213
Length Range: 20FT
Surface Available: Annealed & Pickled, Bright Annealed
Materials Of Tube: TP304, TP304L, TP316L Etc.
OD Available: 6.0MM - 25.40MM



Description:




Stainless steel instrumentation tubings are stainless, duplex, nickel or titanium tubes with mostly relatively thinner walls. The majority of diameter for stainless steel instrumentation tubing varies within 1.5 mm OD to 60 mm OD. on random lengths of 6 meters or on coils up to 1000 meter long without welds.


TOBO. is a global supplier and manufacturer of stainless steel instrumentation tubing, We stock all ASTM A269/A213 bright annealed stainless steel instrumentation tubing sizes from 1/4''(6.35mm) to 2''(50.8mm) OD in 20ft. standard lengths. Custom lengths and sizes are available upon request.




Reference Standards:

ASTM A213 Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes


ASTM A249 Welded Austenitic Steel Boiler, Superheater, Heat Exchanger, and Condenser Tubes


ASTM A269 Seamless and Welded Austenitic Stainless Tubing for General Service.


ASTM A450 General Requirements for Carbon, Ferritic Alloy, and Austenitic Alloy Steel Tubes


ASTM A632 Seamless and welded Austenitic Stainless Steel Tubing (Small-Diameter) for General Service


DIN 2391/EN10305 Precision Seamless Tubes


DIN 17458/2462 Seamless Circular Tubes of Austenitic Stainless Steels with Special Quality Requirements




Stock Sizes:




Stainless Steel Seamless Instrumentation Tubing



OD WT LENGTH GRADE SURFACE TYPE
1/4'' 0.035'' 0.049'' 0.065'' 20' 304/304L, 316/316L AP, BA SMLS, WLD
5/16'' 0.035''     20' 304/304L, 316/316L AP, BA SMLS, WLD
3/8'' 0.035'' 0.049'' 0.065'' 20' 304/304L, 316/316L AP, BA SMLS, WLD
1/2'' 0.035'' 0.049'' 0.065'' 20' 304/304L, 316/316L AP, BA SMLS, WLD
3/4'' 0.035'' 0.049'' 0.065'' 20' 304/304L, 316/316L AP, BA SMLS, WLD
5/8'' 0.035'' 0.049'' 0.065'' 20' 304/304L, 316/316L AP, BA SMLS, WLD
1'' 0.035'' 0.049'' 0.065'' 20' 304/304L, 316/316L AP, BA SMLS, WLD



Technical composition (%) Fe Cr Ni Mo Mn Si P C S
316 min Bal. 16.0 11.0 2.0 - - - - -
  max - 18.0 14.0 3.0 2.00 0.75 0.040 0.080 0.030
316L min Bal. 16.0 10.0 2.0 - - - - -
  max - 18.0 15.0 3.0 2.00 0.75 0.040 0.035 0.030




Mechanical properties 316 316L
Tensile strenght (mpa, min) 510 - 710 460 -690
Yield strength (0.2% offset mpa, min) 205 190
Elongation (%, min) 40 40
Density / weight (g / cm3 / kg) 8.0 8.0



TP304 TP304L TP316L 304 Stainless Steel Seamless Pipe ASTM A213 0TP304 TP304L TP316L 304 Stainless Steel Seamless Pipe ASTM A213 1TP304 TP304L TP316L 304 Stainless Steel Seamless Pipe ASTM A213 2

FAQ

1.Q: Are you manufacture or trade company?
A:We are manufacture specialized in PVC pipes and rubber hoses ; Our produces have CE and ISO certification.


2.Q: How can I get the samples?
A:If you need some samples to test, we can make as per your request .You should pay for the transportation freight of samples and our samples cost, while the samples cost can be refundable after you place the order if the amount meets our requirement.

3.Q:How much the transportation freight of samples?
A:The freight depends on the weight and packing size and your area.

4.Q:How long can I expect to get the sample?
A:The samples will be ready for delivery within one week. The samples will be sent via express and arrive in 4-7 days.

5.Q:Can we have our Logo or company name to be printed on your products or package?
A:Sure.Your Logo can be put on your products by Hot Stamping,Printing,Embossing,UV Coating,Silk-screen Printing or Sticker.

6.Q:How to order?
A: Please send us your purchase order by Email or you can ask us to send you a proforma invoice for your order. We need to know the following information for your order:
1) Product information-Quantity, Specification (Size, Material, Technological and Packing requirements etc.)
2) Delivery time required.
3) Shipping information-Company name, Street address, Phone &Fax number, Destination sea port.
4) Forwarder's contact details if there's any in China.

  •
