Nickel alloy material Corrosion resistant alloy incoloy 800 825 Pipe inconel 625 600 718 tube

Place of Origin	CHINA
Brand Name	TOBO
Certification	Customized logo
Model Number	available on request
Minimum Order Quantity	1
Price	USD
Packaging Details	Wooden box
Delivery Time	5-8 WORK DAYS
Payment Terms	L/C, T/T, Western Union
Supply Ability	1

Product Details

Application	Chemical Industry, Food Processing, Pharmaceuticals, Petrochemical, Oil & Gas, Power Generation, Etc.	Corrosion	Resistant
Delivery	Within 15-20 Days	Length	Customized
Manufacturing	Seamless, Welded	Material	Nickel Alloy
Packing	Wooden Cases, Wooden Pallets, Etc.	Pressure	High Pressure
Size	Customized	Standard	ASTM, ASME, EN, JIS, ISO, GB
Surface	Polished	Temperature	High Temperature
Thickness	Customized	Type	Pipe
Highlight	Nickel alloy corrosion resistant pipe , Incoloy 800 alloy tube , Inconel 625 high performance pipe

Leave a Message

Product Description

Nickel alloy material Corrosion resistant alloy incoloy 800 825 Pipe inconel 625 600 718 tube

Key attributes

Industry-specific attributes

Resistance (μΩ.m)

stable

Powder Or Not

Not Powder

Ultimate Strength (≥ MPa)

standard

Elongation (≥ %)

Other attributes

Place of Origin

Jiangsu, China

Type

Nickel Pipe

Application

Industry, Construction

Grade

Nickle Alloy

Ni (Min)

30-35%

Model Number

Incoloy 800/800H/800HT/825/925

Brand Name

DZX

Surface

Bright polished

Shape

Wire/sheet/strip/pipe/bar

Standard

AISI,SUS,ASTM A270,BS,DIN,A554,ANSI,A249,JIS,ASME

Material

Nickel Alloy

M.O.Q.

100kgs

Delivery time

15~25 Days

Condition

Hard (Y)/ Soft (M)/Half Hard (Y2)

Technique

Hot Rolled Cold Rolled

Product name

Corrosion resistant alloy incoloy 800 825 inconel 600 718 tube / bar

Packaging and delivery

Packaging Details

Incoloy 800 tube or bar is packed into wooden cases.<br>Special packaging requirements can also be accommodated. <br>OEM is also acceptable Nickel alloy material Corrosion resistant alloy incoloy 800 825 Pipe inconel 625 600 718 tube 0

Product details

Product Description

Corrosion resistant alloy incoloy 800 825 inconel 600 718 tube / bar

Incoloy 800HT has excellent resistance in chemicals containing sulfuric acid, and has good resistance to environments containing chlorides, phosphoric acid and nitric acid.

It contains niobium for stabilization against sensitization and resultant intergranular corrosion. It also has good mechanical properties and fabricability.

Size Range
Shape	Size(mm)
Wire	0.5-7.5
Rod/bar	8.0-200
strip	(0.05-2.5)*(5-180)
Tube	Custom made
Plate	Custom Made

Product Characteristics

Incoloy800 is a kind of austenitic heat-resistant alloy which is widely used in high-pressure structures at high temperature.The high strength of 800H alloy is mainly due to the addition of carbon, aluminum and titanium, and annealing at the lowest temperature of 1149 ° c to reach the grain size of ASTM5 or coarser. It has excellent corrosion resistance, stress corrosion resistance and processability in extremely high temperature water-based media up to 500 ° c

Parameter

Item	800	800H	800HT	825	925
C	≤0.1	0.05-0.1	0.06-0.1	≤0.05	≤0.03
Mn	≤1.5	≤1.5	≤1.5	≤1	≤1
Fe	rest	rest	rest	rest	rest
P	--	--	--	≤0.02	≤0.03
S	≤0.015	≤0.015	≤0.015	≤0.03	≤0.03
Si	≤1	≤1	≤1	≤0.5	≤0.5
Cu	≤0.75	≤0.75	≤0.75	1.5-3	1.5-3
Ni	30-35	30-35	30-35	38-46	42-46
Al	0.15-0.6	0.15-0.6	0.15-0.6	0.2-1	0.15-0.5
Ti	0.15-0.6	0.15-0.6	0.15-0.6	0.6-1.2	1.9-2.4
Cr	19-23	19-23	19-23	19.5-23.5	19.5-23.5
Mo	--	--	--	2.5-3.5	2.5-3.5

Application

High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation.naval and industrial gas turbines.
