| Place of Origin: | China/Japan/Germany |
|---|---|
| Brand Name: | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification: | ISO/PED/TUV/SGS/LR/BV |
| Model Number: | S235JR,A283 Grade C,A36,St37-2,A537 Grade 70,SS400,SM400A |
| Minimum Order Quantity: | 1 ton |
| Price: | Depending on quantity |
| Packaging Details: | PLY-WOODEN CASE OR PALLET |
| Delivery Time: | 10-100 days depending on quantity |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000 Tons per month |
| Product Name: | Common Carbon Structural Steel Plate | Product Type: | Steel Plate |
|---|---|---|---|
| Rolling Range: | Thickness*Width*Length 2-700mm*1220-4200mm*5000-18000mm | Test: | Ultrasonic Examination,Normalized,Quenched And Tempered,HIC,SSCC And Third Party Inspections By End User. |
| Main Steel Grades: | S235JR,A283 Grade C,A36,St37-2,A537 Grade 70,SS400,SM400A | Steel Standard: | ABS,LR,DNV,BV,GL,CCS,KR,NK,RINA |
| Application: | Carbon Steel Plates Are Used To Produce Structural Parts Of The Bolted And Welded Steel In Dustrial Area | Surface Treatment: | Hot Rolled And Coated |
| Highlight: | Stainless Steel Coils,Thin Stainless Steel Sheet |
||
Carbon Steel Plate,Common Carbon Structural Steel Plate S235JR, A283 Grade C, A36, St37-2, A537 Grade 70, SS400, SM400A
Steel Name: Carbon steel plate,Common carbon structural steel plate
Main steel grades: S235JR,A283 Grade C,A36,St37-2,A537 Grade 70,SS400,SM400A
Steel standard: EN 10025,DIN 17100,DIN 17102,ASTM,GB/T700,JIS G3106
Main application:Carbon steel plates are used to produce structural parts of the bolted and welded steel in dustrial area.
Rolling range: Thickness*Width*Length 2-700mm*1220-4200mm*5000-18000mm
Surface Treatment: Hot rolled and Coated
Test: Ultrasonic examination,Normalized,Quenched and Tempered,HIC,SSCC and Third party inspections by end user.
Supply Ability: 10000 Tons per month
Additional service:Shot blasting and painting,Cutting and welding as per user’s request.
S235JRG2 steel plate Chemical analysis -% by mass*
| Chemical elements |
C≤ 16mm max |
C>16mm max |
Si max |
Mn max |
P max. |
S max. |
|
%,by mass |
0.17 |
0.17 |
-- |
1.40 |
0.045 |
0.045 |
S235JRG2 steel sheet Mechanical properties
| thickness |
Yield Strength ReH[N/mm2] |
Tensile |
Fracture Elongation[%]transv. min. |
Notch mpactEnergy1) |
|
t≤ 16mm t >16mm |
235 225 |
|
|
Degree: 20 |
|
t< 3mm t ≥ 3mm |
|
360-510 340-470 |
|
|
|
Up to 1.5mm |
|
|
16 |
Want to get more information about Clad steel plate,please CONTACT TOBO NOW
Other steel products we can offer:
Carbon steel plate Boiler steel plate High strength steel plate
Shipbuilding steel plate Oil platform steel plate Low alloy steel plate
Pipeline steel plate Angle steel Bulb flat steel Flat bar Stainless steel plate
Clad steel plate Galvanized steel plate Channel Steel Weathering steel plate
Seamless steel pipe Extra High strength ship plate
All steel grades for Carbon steel plates we can offer as follows:
|
STANDARD |
STEEL GRADE |
|
EN10025 |
S235JR,S235J0,S235J2 |
|
DIN 17100 DIN 17102 |
St33,St37-2,Ust37-2,RSt37-2,St37-3 StE255,WstE255,TstE255,EstE255 |
|
ASTM
ASME |
A36/A36M A36 A283/A283M A283 Grade A,A283 Grade B,A283 Grade C,A283 Grade D A573/A573M A573 Grade 58,A573 Grade 65,A573 Grade 70
SA36/SA36M SA36 SA283/SA283M SA283 Grade A,SA283 Grade B,SA283 Grade C,SA283 Grade D SA573/SA573M SA573 Grade 58,SA573 Grade 65,SA573 Grade 70 |
|
GB/T700 |
Q235A,Q235B,Q235C,Q235D,Q235E |
|
JIS G3106 |
SS330,SS400,SS490,SS540,SM400A,SM400B,SM400C |
