Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade

Certification
Good quality Stainless Steel Elbow for sales
Good quality Stainless Steel Elbow for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner .

—— Thailand ---Dave Mulroy

ASTM A182 F55 Super Duplex Flange ,Good quality , we like that ! And delivery time in time also ,very professional.

—— USA ---Alfaro

I'm Online Chat Now

Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade

China Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade supplier
Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade supplier Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade supplier Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade supplier Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade supplier Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade supplier

Large Image :  Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade

Product Details:

Place of Origin: China/Japan/Germany
Brand Name: TOBO/TPCO/TISCO/VALIN/METAL
Certification: ISO/PED/TUV/SGS/LR/BV
Model Number: 201,202,301, 321, 304, 304L, 316, 316L, 409,

Payment & Shipping Terms:

Minimum Order Quantity: 0.5-1 tons
Price: negotiable
Packaging Details: in plastic bags then in bundles
Delivery Time: According to the qty
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 6000TONS/MONTH
Contact Now
Detailed Product Description
Standard:: ASTM A554, A312, A249, A269 And A270,A688 Color: White Silver Gold
Types:: Stainless Steel Welded Pipe / Tube Material Grade: 201,202,301,304,316,430,304L,316L
Outer Diameter: 9.53mm-101.6mm

Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade


Quick Detail:

The welded stainless steel pipe is made from stainless steel by electric welding or sheet metal strips by means of forming and welding. Electrically welded tube is made of thermally without subsequent processing and hot-reducing.




Name

Stainless steel welded pipe/ tube

Standard

ASTM A554, A312, A249, A269 and A270,A688

Material Grade

201,202,301,304,316,430,304L,316L

Size Range

20x10mm--100x50mm,10x10mm-100x100mm, 9.53-101.6mm, we can also accept sizes above 101.6mm

Thickness

0.3mm - 3.0mm

Length

6m or as customers' request


Tolerance

a) Outer Diameter:  +/- 0.2mm

b) Thickness: +/- 0.02mm

c) Length: +/- 5mm

Surface

180G, 320G Satin / Hairline(Matt Finish, Brush, Dull Finish)
400G, 600G Mirror finish

Application

Window,Door,Handrail,Curtain rail,Towel rail,Flagpole,Lamp pole,Sanitary Instrument,Billboard,Decoration,Upholstery,
Construction,Accessory,Airport,Bus Stop

Test

Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT


Chemical Composition of Material


Composition

   Material

201

202

304

316L

430

C

≤0.15

≤0.15

≤0.08

≤0.35

≤0.12

Si

≤1.00

≤1.00

≤1.00

≤1.00

≤1.00

Mn

5.5-7.5

7.5-10

≤2.00

≤2.00

≤1.00

P

≤0.06

≤0.06

≤0.045

≤0.045

≤0.040

S

≤0.03

≤0.03

≤0.030

≤0.030

≤0.030

Cr

13-15

14-17

18-20

16-18

16-18

Ni

0.7-1.1

3.5-4.5

8-10.5

10-14



Mo







2.0-3.0




Mechanical Property

Material Item

201

202

304

316

Tensile Strength

≥535

≥520

≥520

≥520

Yield Strength

≥245

≥205

≥205

≥205

Extension

≥30%

≥30%

≥35%

≥35%

Hardness (HV)

<105

<100

<90

<90



ADVANTAGE:

1, Direct material sourcing from Bao Steel, ZPSS, TISCO.
2, More than 5 processing mills to produce the welded titanium tube for us. And also we own a steel tube mill.
3, Strong business cooperation with Bao Steel and Shanghai Minmetals.
4, More than usd$50,000,000 annual turnover.

We are professional manufacturer of stainless steel products, including stainless steel decorative pipes,industrial stainless welded pipes, special-shaped pipes, stainless steel sheet and etc.


 Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 GradeThin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 GradeThin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade
