Nickel Incoloy 926 Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED

  • Nickel Incoloy 926 Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED
  • Nickel Incoloy 926 Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED
  • Nickel Incoloy 926 Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED
  • Nickel Incoloy 926 Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED
  • Nickel Incoloy 926 Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number n4 n6 n7 n8
Minimum Order Quantity 300 Kilogram/Kilograms
Price US $ 10 - 100 / Kilogram
Packaging Details Plywood cases or customized
Delivery Time 7-30days
Payment Terms L/C, T/T, Western Union
Supply Ability 50 Metric Ton/Metric Tons per Month
Product Details
Product Name Nickel Incoloy 926 Steel Bar Product Type Nickel Steel Bar
Grade Nickel Alloy Ni (Min) 24-26%
Ultimate Strength (≥ MPa) Rm N/mm2 650 Elongation (≥ %) 40
Application Blades, Vanes, Shafts, Tail Cones, Afterburners, Springs, And Fastener Color Shining
Highlight

Stainless Steel Round Rod

,

Stainless Steel Flat Bar
Leave a Message
Product Description



Super Incoloy A286 Stainless Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED



Quick Details

Place of Origin:
Shanghai, China (Mainland)
 Type:
Nickel Bar
 Application:
refractory
Grade:
nickel alloy
 Ni (Min):
24-26%
 Resistance (μΩ.m):
more than 140
Powder Or Not:
Not Powder
 Ultimate Strength (≥ MPa):
Rm N/mm2 650
 Elongation (≥ %):
40
Model Number:
n4 n6 n7 n8 nickel bar
 Brand Name:
TOBO
 Color:
shining

Packaging & Delivery

Packaging Details: Plywood cases or customized
Delivery Detail: 7-30days

Specifications

Incoloy 926
1. Size: 16mm-300mm
2. Material: Inconel, incoloy, hastelloy, Monel, super stainless steel etc.



Product Description


   Nickel alloy Incoloy 926 bar

 Nickel alloy Incoloy 926 Chemical composition:

Alloy

%

Ni

Cr

Fe

C

Mn

Si

Cu

Mo

N

Ti

P

S

926

Min.

24

19

Balance







0.5

6.0

0.15

0.6





Max.

26

21

0.02

2

0.5

1.5

7.0

0.25

1.2

0.03

0.01


Incoloy 926 Physical properties:

Density

8.1 g/cm3

Melting point

1320-1390 °C


Incoloy 926 Alloy Minimum Mechanical properties in the room temperature:

Alloy state

Tensile strength
Rm N/mm2

Yield strength
RP0.2N/mm2

Elongation
A5 %

926

650

295

35


Incoloy 926 Characteristic:
1. It has high resistance to pitting and crevice corrosion when in Halide and H2S contained acid media.
2. In practice, effective in resistance of chloride stress corrosion cracking.
3. A variety of corrosion have good corrosion resistance capability in the normal oxidation and restore environment.
4. Upgrade mechanical properties than Cronifer 1925 LC-Alloy 904 L.
5. Alloys has Improved the stability of metallurgical compared to a range of 18% of the nickel content alloys.
6. With a certification of applied in manufacturing-related  pressure vessel (VdTUV-196~400°C and ASME )








Nickel Incoloy 926 Steel Bar ASTM SGS / BV / ABS / LR / TUV / DNV / BIS / API / PED



Corrosion Resistance:



Incoloy 800, like many austenitic stainless steels, can be sensitized, or made susceptible to intergranular  attack in some aggressive media, by exposure to the temperature range of 1000 to 1400F.





Applications:



For services below 600 degree centigrade the use of soft annealed incoloy 800 is suggested. Incoloy 800 has

 applications in furnae components and equipment, petrochemical furnace cracker tubes, pigtails,headers

 and sheathing for electrical heating elements.
