Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN

  • Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN
  • Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN
  • Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN
  • Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number Incoloy 825 UNS NO8825
Minimum Order Quantity 1 Ton/Tons neogotiationTrial Order
Price US $ 1,000 - 3,000 / Ton
Packaging Details Wooden Cases
Delivery Time delivery time is according to the actual order
Payment Terms L/C, T/T, Western Union
Supply Ability 3000 Ton/Tons per Week neogotiation
Product Details
Product Name Incoloy 825 UNS NO8825 Steel Plate Product Type Steel Plate
Standard AISI, ASTM, BS, DIN, GB, JIS Grade Ni-Cr-Fe Alloy
Ultimate Strength (≥ MPa) 550 Ni (Min) 38
Elongation (≥ %) 35 Application Nitrate Condenser,Steam Heating Pipes,etc
Length 1000-12000mm
Highlight

Stainless Steel Coils

,

Thin Stainless Steel Sheet
Leave a Message
Product Description

Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN


Quick Details

Place of Origin:
Shanghai, China (Mainland)
Type:
Nickel plate
Application:
Nitrate condenser,Steam heating pipes,etc
Grade:
Ni-Cr-Fe alloy
Ni (Min):
38
Powder Or Not:
Not Powder
Ultimate Strength (≥ MPa):
550
Elongation (≥ %):
35
Model Number:
Incoloy 825
Brand Name:TOBO

Packaging & Delivery

Packaging Details:Wooden Cases
Delivery Detail:delivery time is according to the actual order

Specifications

Incoloy 825 UNS NO8825 steel plate:
1)Size:1000mm x 2000mm
2)Thk:1mm-60mm
3)Standard:ASTM B424/ASME SB424,ASTM B906/ASME SB90

Incoloy 825 UNS NO8825 steel plate :
1)Size:1000mm x 2000mm
2)Thk:1mm-60mm
3)Standard:ASTM B424/ASME SB424,ASTM B906/ASME SB906
Incoloy 825 Chemical composition:
Alloy
%
Ni
Cr
Fe
C



Mn
Si
Cu
Mo
Al
Ti
P
S
825

Min.

38
19.5
balance



1.5
2.5
1.0
0.6


Max.
46
23.5
balance
0.05
1
0.5
3
3.5
0.2
1.2
0.02
0.03

Incoloy 825 Physical properties
Density
8.1 g/cm³
Melting point
1370-1400°C

Incoloy 825 Alloy mi nimum mechanical properties in the room temperature
Alloy state
Tensile strength
Rm N/mm²
Yield strength
R P0. 2N/mm²
Elongation
A 5 %
Brinell hardness
HB
825
550
220
30
≤200

Characteristic as below :
1. Good stress corrosion cracking resistance performance
2. Good resistance for pitting and crevice corrosion performance
3. Good anti-oxidation and non-oxidzing heat acid performance
4. Good mechanical performance in both room temperature and up to 550°C
5. Have the pressure vessel authenticate when manufacture temperature up to 450°C

Incoloy 825 Metallurgical structure:
825 is the face-centered cubic lattice structure.


Incoloy 825 Corrosion resistance
825 is an all-purpose project alloy, have good corrosion resistance of the acid and alkali metal property in both oxidation and reduction environments. High nickel content made it with effective stress corrosion cracking resistance performance. 825 have excellent corrosion resistance in different kinds of media, such as sulfuric acid, phosphoric acid, nitric acid and organic acid, alkali metal such as sodium hydroxide, potassium hydroxide, and hydrochloric acid. A variety of media corrosion of nuclear-burning dissolver show 825 high integrated prpperty, like sulfuric acid, nitric acid and potassium hydroxide are all dealing in a same device.


Incoloy 825 Application field:
825widely use in many kinds of industry field that the working temperature no more than 550°C.


Incoloy 825 Typical application field:
1. Sulfuric acid factory usage for heating pipe, container, basket,chain and so on.
2. Cooling heat exchanger, marine product pipeline system and gas pipeline of acidic environment.
3. Heat exchanger, steam machine, washing, impregnation pipe, etc. for phosphoric acid produce
4. Oil refining in the air heat exchanger
5. Food project
6. Chemical process
7. Application of high pressure oxygen flam-retardant alloy

 Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN


Incoloy 825 UNS NO8825 steel plate JIS, AISI, ASTM, GB, DIN, EN
