Hot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316L

  • Hot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316L
  • Hot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316L
  • Hot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316L
  • Hot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316L
  • Hot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316L
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number Tp304 / 304L, Tp316L, Tp310S, SUS630, SUS631
Minimum Order Quantity 0.5-1 tons
Price negotiable
Packaging Details Plastic bag in bundle,Wooden box,etc
Delivery Time According to the qty
Payment Terms T/T, L/C, Western Union,
Supply Ability 6000TONS/MONTH
Product Details
Standard GB/T12771-2008, ASTM A312, ASTM A789, JIS G3448, Color White Silver Gold
Types Stainless Steel Welded Pipe Outer Diameter 6mm - 200mm
Size 8 In. To 48 In
Highlight

Welded Stainless Steel Tubing

,

Large Stainless Steel Pipe
Leave a Message
Product Description


ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished





Quick Detail:



Surface Finish

1. 2B Finish  2. Pickled Finished  3. Annealed&Pickled

Material

304/L, 316L/Ti, 310S etc.

Outside Diameter

6mm - 200mm

Wall Thickness

0.5-20mm.

Length

As required

Market

USA,Canada,Japanese,European etc.





Description:

  1. Product Item No.: 0050welded-Cosco Steel
  2. Type: Round
  3. Mainly Material

  1. 4301/ SUS304/ AISI304/ S30400,

  1. 4306/ SUS304L/ AISI304L/ S30403,

  1. 4404/ SUS316L/ AISI316L/ S31603, etc.





Standard:



  GB/T12771-2008, ASTM A312, ASTM A789, JIS G3448,

  DIN EN10216-5, DIN EN10217-7, etc.

  1. Size: 8 In. to 48 In.
  2. Wall Thickness: 3mm to 20mm
  3. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size
  4. H.S Code: 7306.4000



Applications:



This type welded tubes/pipes be used in

  1. Industrial fluid conveying pipes
  2. Mechanical structural tubes
  3. Heat ex-changer and condenser tubes
  4. Walled water tubes
  5. Larger caliber industrial welded pipes etc.



Specifications



Designation: A312/A312M-04a

Standard specifications For Seamless,Welded,And Heavily Cold Worked Austenitic

Stainless Steel Pipe



Manufacture Process

ERW Welded ( ELD ) Pipe







Quality Inspection






  1. Metallographic Analysis
  2. Physical And Chemical Analysis
  3. Specification Eccentricity Test
  4. Mechanical Test
  5. PMI Test
  6. Eddy Current Test
  7. Large-Size Ultrasonic Flaw Test
  8. Ultrasonic Flat Test
  9. Thickness Test   etc.







Mechanical Requirements

 Grade    UNS              Tensile Strength   Yield Strength

             Designation     Min Ks i [M pa]     Min Ks i [M pa]

 TP304    S30400             75 [515]         30 [205]

 TP304L   S30403             70 [485]         25 [170]

 TP309S   S30908             75 [515]         30 [205]

 TP310S   S31008             75 [515]         30 [205]

 TP316L   S31603             70 [485]         25 [170]

  ....          ....                .....               .....
  1. Specification No.
  2. Pipe
  3. Grade
  4. NPS
  5. Wall
  6. SMLES OR WELDED ...
  • ASTM A312
  • P
  • TP304
  • 12IN
  • 0.375 IN
  • WELDED .....



Hot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316LHot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316LHot Finished 16 inch Stainless Steel Welded Pipe ASTM A312 TP304 / 304L 316L
