Shining Food Grade Stainless Steel Tubing 304 304L 316L Welding SS Pipes
| Place of Origin | China/Japan/Germany |
|---|---|
| Brand Name | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification | ISO/PED/TUV/SGS/LR/BV |
| Model Number | OD: 6mm – 400mm, WT:0.5mm – 10mm |
| Minimum Order Quantity | 0.5-1 tons |
| Price | negotiable |
| Packaging Details | Plastic bag in bundle,Wooden box,etc |
| Delivery Time | According to the qty |
| Payment Terms | T/T, L/C, Western Union, |
| Supply Ability | 10000 Metric Tons Per Year |
Product Details
| Standard | ASTM / DIN | Color | White Silver Gold |
|---|---|---|---|
| Types | Stainless Steel Welded Pipe | Outer Diameter | 6mm – 400mm |
| Size | 8 In. To 48 In | ||
| Highlight | SS Welded Tube,Large Stainless Steel Pipe |
||
Product Description
304 / 304L / 316L Welded SS Pipe For Food Industry, Such As Sugar Factory,Beverage Industry
Quick detail:
Welded Stainless Steel Pipes, ASTM / DIN / EN , 304 / 304L / 316L/1.4301 / 1.4307 / 1.4404, Bright Annealing Or Anneal&Pickled For Sugar Factory,Beverage Industry
Description:
Size Details:
Product | Size | Length |
Welded Stainless Steel Pipes | 6mm - 400mm x 0.5mm - 10mm | Max 18000mm |
Standards:
ASTM A249, ASTM A269, ASTM A268, ASTM A312, ASTM A688, ASTM A789, DIN 17457 /EN 10217-7
American standards: | ||
ASTM A249: Standard specification for welded austenitic steel boiler,superheater, heat-exchanger and | ||
ASTM A269:Standard specification for welded austenitic stainless steel tubing for general service | ||
ASTM A688:Standard specification for welded austenitic stainless steel feedwater heater tubes. | ||
ASTM A268:Specification for seamless and welded Ferritic/Martensitic stainless steel tubing for | ||
ASTM A789:Specification for seamless and welded Ferritic/Austenitic stainless steel tubing for | ||
ASTM A312:Seamless/Welded austenitic stainless steel pipe | ||
Germanic standards: | ||
DIN17457: Welded circular austenitic stainless steel tubes subject to special requirements; technical
|
Specifications:
|
② Material Grade: 304 / 304L / 316L/1.4301 / 1.4307 / 1.4404 |
③ Brand: KORER |
④ Standard: ASTM / DIN |
⑤ Delivery Condition: Bright Annealing Or Annealed&Pickled |
⑥ Application: For Sugar Factory,Beverage Industry |
⑦ Out Diameter:6mm – 400mm |
⑧ Wall Thickness:0.3mm – 10mm |
⑨ Packing: Bundles With Plastic Bags, Wooden Box With Angle Steel Frame Or others |
⑩ Delivery Time: Generally 15Days – 45Days Or Depends on the quantity and Customers’ Request |
Competitive Advantage: 1.We Professionally Manufacture Welded Stainless Steel Tubes About 20years ; 2.We Are Approved By Iso 9001 And Manufacture License Of Pressure Pipes. 3.We Have Friendly And Long Term Business Relationships With The Customers Based On The Good Quality, Timely Delivery And Competitive Prices. |
Chemical Compositions of Material 304 / 304L / 316L/1.4301 / 1.4307 / 1.4404:
Grade | Chemical Composition(%) | Remark | |||||||||
C≤ | Mn≤ | P≤ | S≤ | Si≤ | Cr | Ni | Mo | N | Cu | ||
304 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 18.0~20.0 | 8.0~10.50 |
| 0~0.1 |
|
|
304L | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 18.0~20.0 | 8.0~12.0 |
| 0~0.1 |
|
|
316L | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 16.0~18.0 | 10.0~14.0 | 2.0~3.0 | 0~0.1 |
|
|
1.4301 | 0.07 | 2 | 0.045 | 0.015 | 1 | 17.0~19.0 | 8.0~10.50 |
| 0~0.1 |
|
|
1.4307 | 0.03 | 2 | 0.045 | 0.015 | 1 | 17.5~19.5 | 8.0~10.0 |
| 0~0.1 |
|
|
1.4404 | 0.03 | 2 | 0.045 | 0.015 | 1 | 16.5~18.5 | 10.0~13.00 | 2.0~2.5 | 0~0.1 |
|
|
Applications:
The Pipes are Used For Liquid Delivery In Paper / Pulp, Phamaceuticals, Diary, Food, Beverages Industry Etc.
