Stainless Steel Bar 316L 182Mmround Ferrite N0S.<10 ISO Certification

  • Stainless Steel Bar 316L 182Mmround Ferrite N0S.<10 ISO Certification
  • Stainless Steel Bar 316L 182Mmround Ferrite N0S.<10 ISO Certification
  • Stainless Steel Bar 316L 182Mmround Ferrite N0S.<10 ISO Certification
  • Stainless Steel Bar 316L 182Mmround Ferrite N0S.<10 ISO Certification
  • Stainless Steel Bar 316L 182Mmround Ferrite N0S.<10 ISO Certification
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number P11/P12/P22/F11/F12/F22/10CrMo910/SA-182/SA-234/SA-335/SA-336/SA-387
Minimum Order Quantity 300 Kilogram/Kilograms
Price US $ 10 - 100 / Kilogram
Packaging Details STANDARD EXPORT PACKINGS
Delivery Time WITHIN 6-8 WEEKS
Payment Terms L/C, T/T, Western Union
Supply Ability 50 Metric Ton/Metric Tons per Month
Product Details
Product Name Stainless Steel Bar Product Type Round,square,hex,angle,flat,T,H,chanel
Grade 304/304L/316/316L Special Use Valve Steels
Dimensions 3 Mm To 300 Mm Surface Treatment Galvanized
Application Ship Plate Techinque Hot Rolled
Highlight

Stainless Steel Round Rod

,

Stainless Steel Flat Bar
Leave a Message
Product Description

Stainless Steel Bar 316L 182Mmround  Ferrite N0S.<10 ISO Certification



Quick Details

Standard:
JIS, AISI, ASTM, GB, DIN, EN
 Dimensions:
3 mm to 300 mm
 Grade:
304/304L/316/316L
Place of Origin:
Shanghai, China
 Brand Name:
TOBO
 Type:
Round
Application:
ALL
 Shape:
Round
 Certification:
ISO
Special Use:
Valve Steels

Packaging & Delivery

Packaging Details: STANDARD EXPORT PACKINGS
Delivery Detail: WITHIN 6-8 WEEKS

Specifications

STAINLESS STEEL 316L 182mm ROUND BARS FERRITe N0S.<10
QUALITY EXCELLENCE AWARD
ISO 9001; 2008 CERTIFIED COMPANY





Stainless Steel Bar 316L 182Mmround Ferrite N0S.<10 ISO Certification

16/316L is the most commonly used austenitic stainless steel in the chemical process industry. The addition of molybdenum increases general corrosion resistance, improves chloride pitting resistance and strengthens the alloy in high temperature service. Through the controlled addition of nitrogen it is common for 316/316L to meet the mechanical properties of 316 straight grade, while maintaining a low carbon content.

Chemistry

  Ni Cr Mo Mn Si C S P N Fe
MIN 10.0 16.0 2.0 - - - - - - -
MAX 14.0 18.0 3.0 2.0 0.75 0.03 0.03 0.045 0.1 Balance

Specifications

AMS 5507, AMS 5648, AMS 5653
ASME SA 240, ASME SA 312, ASME SA 479
ASTM A 240, ASTM A 276, ASTM A 276 Condition A, ASTM A 276 Condition S, ASTM A 312, ASTM A 479
EN 1.4404
UNS S31600, UNS S31603
W. Nr./EN 1.4401
Werkstoff 1.4404



Inventory

316 / 316L Coil, 316 / 316L Concentric Reducers, 316 / 316L Fittings, 316 / 316L Flanges, 316 / 316L Hex Bar, 316 / 316L Pipe, 316 / 316L Plate, 316 / 316L Round Bar, 316 / 316L Sheet, 316 / 316L Stub Ends, 316 / 316L Tees, 316 / 316L Welding Products

Common Trade Names

316 Stainless, 316L Stainless



Features

  • Improved general and localized corrosion to 304/304L stainless
  • Good formability
  • Good weldability

Applications

  • Food processing
  • Marine
  • Pulp & paper
  • Chemical process vessels
  • Pharmaceutical Equipment

Physical Properties

Density: 0.285 lb/inch3
Poisson's Ratio: 0.3
Electrical Resistivity: 445 Ohm-circ mil/ft

Temperature, °F 70 212 932 1832
Coefficient* of Thermal Expansion, in/in°F x 10-6 - 9.2 10.1 10.8
Thermal Conductivity
Btu • ft/ft2 • hr • °F		 7.8 - - -
Modulus of Elasticity Dynamic, psi x 106 29 - - -

Mechanical Properties

Representative Tensile Properties

Ultimate Tensile Strength, ksi 75
0.2% Yield Strength, ksi 30
Elongation, % 40
Hardness MAX, Brinell 217

Typical Tensile and Impact Properties

Temperature, °F 70 200 400 600 800 1000 1200 1400
Ultimate Tensile Strength, ksi 82.4 75.6 71.1 71.1 71.1 68.4 50.7 30.7
0.2 % Yield Strength, ksi 42.4 - - - 26.5 23.4 22.6 -
Charpy Impact V-notch, ft-lbs 65 - 100 -







Packaging & Shipping





Packaging is one of the best service of Ronsco, in order to prevent the damage from transit, our finished products are packaged carefully. All of our stainless steel sheet products will be transported with steel pallets or wooden pallets.


Customers will be guaranteed that the product they received from TOBO can go directly into the production and out to the customers as finished product.
