Seamless Hastelloy Pipe Hastelloy C-4 ( UNS No. N06455 ) Hastelloy C22
| Place of Origin | China/Japan/Germany |
|---|---|
| Brand Name | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification | ISO/PED/TUV/SGS/LR/BV |
| Model Number | TOBO Hastelloy C276, Nickelvac HC-276, Inconel 276, Nicrofer 5716, Hastelloy C22, Inconel 22, Nicrofer5621. |
| Minimum Order Quantity | 1M |
| Price | USD |
| Packaging Details | PLY-WOODCASE |
| Delivery Time | 5-65workdays |
| Payment Terms | T/T, L/C, Western Union, |
| Supply Ability | 3000TON/YEAR |
Product Details
| Standard | ASTM B622, ASTM B619, ASTM B775, ASTM B516, ASTM B626, ISO 6207, DIN 17751, VdTüV 400/12.98 | Length | Single Random, Double Random & Cut Length |
|---|---|---|---|
| End | These Pipes Have Plain End, Beveled End, Threaded And Features Like Hot Dipped Galvanizing, Epoxy & Fbe Coating And Electro Polish | Grade | Hastelloy C276, Nickelvac HC-276, Inconel 276, Nicrofer 5716, Hastelloy C22, Inconel 22, Nicrofer5621. |
| Color | Black Or Red | Types | Seamless |
| ASTM | B622, B619, B622, B626 | Form | Round, Square, Rectangular, Hydraulic Etc |
| Highlight | Hastelloy C22 Pipe,Hastelloy b2 pipe |
||
Product Description
Hastelloy C-4 Pipe
* All time Available
* Resistant Free
* Long Lasting
* Different Sizes & Shapes
Hastelloy C-4 Pipe
.
| Range | ½" NB TO 24" NB IN |
| Type | SEAMLESS / ERW / WELDED/ FABRICATED |
| Form | Round, Square, Rectangular, ETC. |
| Length | Single Random, Double Random & Cut Length |
| End | Plain End, Bevelled End, Threaded |
| Standard | ASTM : B622, B619, B622, B626, B575, B366. |
| Grade | Hastelloy C-4 (UNS No. N06455), C-276 (UNS No. N10276), Hastelloy C 22 (UNS No. N06022), Hastelloy C 2000 |
| Value Added Services | » Electro Polish » Bending » Draw & Expansion » Customized Pipe |
| Test Certificate | Mill Test Certificate as per EN 10204 / 3.1B |
| Our Website | www.ranflexindia.com |
| Email-id | export1 at the rate ranflexmetals dot com |
Specifications
Hastelloy alloy C4 pipe/tube
1.standard: ASTM
2.thickness:0.5-150mm
3.OD:6-1020mm
Hastelloy alloy C4 pipe/tube
HASTELLOY C-4 alloy is a nickel-chromium-molybdenum alloy with outstanding high-temperature stability as evidenced by high ductility and corrosion resistance even after aging in the 1200 to 1900°F (649 to 1038°C) range. This alloy resists the formation of grain-boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in the as-welded condition. C-4 alloy also has excellent resistance to stress-corrosion cracking and to oxidizing atmospheres up to 1900°F (1038°C).
Chemical composition
| Alloy | Ni | Cu | Mo | Cr | Fe | W | Mn | Si | C | other |
| C-4 | 65 | 0.5 | 16 | 16 | 3 | -- | 1 | 0.08 | 0.01 | Ti:0.07 |
| C-22 | 56 | 0.5 | 13 | 22 | 3 | 3 | 0.5 | 0.08 | 0.01 | V:0.35 |
| C-276 | 57 | 0.5 | 16 | 16 | 5 | 4 | 1 | 0.08 | 0.01 | V:0.35 |
| C-2000 | 59 | 1.6 | 16 | 23 | 3 | -- | 0.5 | 0.08 | 0.01 | Al:0.5 |
| B-3 | 65 | -- | 28.5 | 1.5 | 3 | 3 | 3 | 0.1 | 0.01 | Al:0.5 |
| B-30 | 43 | 2 | 5.5 | 30 | 15 | 2.5 | 1.5 | 1 | 0.03 | Cb:1.5 |
Mechanical properties
| Alloy | Tensile strength | Yield strength | Elongation |
| Rm N/mm2 | RP0.2N/mm2 | A5 % | |
| C-4 | 783 | 365 | 55 |
Details
Article | Hastelloy alloy C4 pipe/tube |
type | pipe/tube |
Thickness | 0.5-150mm |
OD | 6-1020mm |
Usage | machine made industry,chemical industry,spin,shipping industry , architecture , food |
Parking | plastic wrapper and wooden packing or as your requirement |
terms conditions | CIF,CFR,FOB |
Payment | Small quantity (within total $20000.00) T/T at sight, 30% in advance , 70% after receiving the B/L Large quantity : L/C at sight |
Delivery Time | 10-25 days after received the deposit of T/T or L/C |
Note | we can produce other standard as the customers' requirement |
Types:
- Seamless
Grades as under:-
- Hastelloy C-4 (UNS No. N06455), C-276 (UNS No. N10276), Hastelloy C 22 (UNS No. N06022), Hastelloy C 2000
ASTM :
- B622, B619, B622, B626
Form:
- Round, Square, Rectangular, Hydraulic etc.
Length:
- Single Random, Double Random & Cut Length
End:
- Plain End, Beveled End, Threaded
| |||||||||||||||||||||||||
