Duplex 2205 Stainless Steel Seamless Pipe ASME SA790 for Chemical Processing Oil
Product Details
| Product Name | Duplex 2205 Stainless Steel Seamless Pipe ASME SA790 For Chemical Processing Oil | Size | 1/2”-24” |
|---|---|---|---|
| Temperaturerange | -50°C To 300°C | Steel Grade | S32750/2507 |
| Item | 201/202/304 /430 Stainless Steel Pipe | Surface Finish | 2B/BA/HAIRLINE/8K/NO.4/No.1 |
| End | BE | Extrudets | SJSZ51/105 |
| Types | Seamless | Standard | ASME B16.9 |
| Certifications | ISO/EN 10204 Type 3.1 / 3.2 Available | Type | Seamless / Welded |
| Prodcut | Steel Pipe Tube | Application | Gas Pipe |
| Ndt | ET, UT, HT , PT | Technology | Hot Rolled/cold Drawn/polished |
Product Description
Duplex 2205 Stainless Steel Seamless Pipe ASME SA790 for Chemical Processing Oil
1. Product Description
Duplex stainless steel pipe is a two-phase (austenite + ferrite) tubular product offering an optimal combination of high strength and corrosion resistance. It is produced in seamless and welded forms per ASTM A789/A790, with standard grades including 2205 (S32205), 2507 (S32750), and 2304 (S32304). The material is delivered in solution-annealed and pickled condition, with full traceability and mill test certification.
2. Product Applications
| Sector | Typical Services |
| Offshore Oil & Gas | Subsea flowlines, topside piping, manifolds |
| Chemical Processing | Organic acids, chloride-bearing media, heat exchangers |
| Marine Engineering | Seawater systems, desalination, FPSO piping |
| Energy | Geothermal, FGD systems, hydrogen transmission |
| Pulp & Paper | Bleaching lines, digesters |
3. Product Advantages
-
Yield strength approx. 2× that of 316L (450 MPa vs. 170 MPa for 2205)
-
PREN 35–42+ provides superior pitting/crevice resistance
-
Outstanding resistance to chloride SCC up to ~250°C
-
Weight savings 30%+ vs. austenitic grades through reduced wall thickness
-
Lower Ni content provides cost stability and nickel-price independence
-
Good weldability without PWHT for thickness ≤ 20mm
4.Key Specifications
| Parameter | 2304 (S32304) | 2205 (S32205) | 2507 (S32750) |
| Cr % | 21.5–24.5 | 22.0–23.0 | 24.0–26.0 |
| Ni % | 3.0–5.5 | 4.5–6.5 | 6.0–8.0 |
| Mo % | 0.05–0.60 | 3.0–3.5 | 3.0–5.0 |
| N % | 0.05–0.20 | 0.14–0.20 | 0.24–0.32 |
| Yield Strength (MPa) | 400 | 450 | 550 |
| PREN | ~26 | ~35 | ~42+ |
| Max. Temp (°C) | 250 | 280 | 300 |
| MDMT | -40°C | -40°C | -40°C |
FAQ
1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.
2.How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
