Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes

  • Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes
  • Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes
  • Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes
  • Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes
  • Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number Incoloy 800 / 800H / 800HT Tube
Minimum Order Quantity 0.5-1 tons
Price negotiable
Packaging Details in plastic bags then in bundles
Delivery Time 15days->
Payment Terms T/T, L/C, Western Union,
Supply Ability 7500 tons per year
Product Details
Standard JIS, AISI, ASTM, GB, DI Application Fluid Pipe,Structure Pip
Surface Annealed & Pickled, Bright Annealing, Polished Types Seamless
Thickness 0.5-12mm Outer Diameter 6-219mm
Material ASTM/ASME B/SB 163,AST
Highlight

marine stainless steel tubing

,

seamless stainless steel tube
Leave a Message
Product Description



Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes



Quick Details

Standard:
ASTM, AISI, DIN, EN, GB, JIS, Other
 Place of Origin:
Shanghai, China (Mainland)
 Brand Name: TOBO
Model Number:
SMLS
 Type:
Seamless
 Steel Grade:
Incoloy alloy;Nickel-Iron-Chromium alloy
Application:
Fluid pipe,Structure Pipe,Oil pipe,,Boiler tube,Heat exchanger tube
 Certification:
ISO
 Thickness:
0.5-12mm
Outer Diameter:
6-219mm
 FINISH:
Annealed & Pickled, Bright Annealing, Polished
 Process:
Cold Drawn,Cold Rolled,Precision Cold Rolled
Specification:
ASTM/ASME B/SB 163,ASTM /ASME B/SB407

Packaging & Delivery

Packaging Details:

Packing: Bare packing/bundle packing with woven bag/wooden or steel frame

crate packing/plastic cap protection at the both sides of tubes and suitably

protected for sea-worthly delivery or as requested.
Delivery Detail: 30 Days

Specifications

100% PMI;100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test

Description & Name:   Incoloy 800/800H/800HT tube  UNS N08800/N08810/N08811 nickel alloy seamless pipe/tube

Standard:   ASTM/ASME B/SB 163,ASTM /ASME B/SB407

Material: Incoloy800/800H/800HT,825, Inconel 600,601,625,617,690,693, Monel 400, Monel K500, Alloy20,Alloy28. Hastelloy C276,AL6XN,N08028 etc.

UNS N08800/N08810/N08811 Chemical Composition%
Alloy Designation Element C Ni Cr Mn Fe Si Cu Al Ti S
Incoloy 800 Min. % - 30 19 - 39.5 -  - 0.15 0.15 -
Max. % 0.1 35 23 1.5 - 1 0.75 0.6 0.6 0.015
Incoloy800H Min. % 0.05 30 19 - 39.5 -  - 0.15 0.15 -
Max. % 0.1 35 23 1.5 - 1 0.75 0.6 0.6 0.015
Incoloy800HT Min. % 0.06 30 19 - 39.5 -  - 0.15 0.15 -
Max. % 0.1 35 23 1.5 - 1 0.75 0.6 0.6 0.015





Mechanical Propeties Incoloy 800 Incoloy 800H incoloy  800HT
Density:  7.9g/cm3  7.9g/cm3  7.9g/cm3
Melting Point:  1350-1400°c 1350-1400°c 1350-1400°c
Tensile Strength Min.(Mpa): 520 450 450
Yield Strength Min. (MPa): 0.2% offset 205 170 170
Elongation A 5%(min.):  30 30 30
Rockwell Hardness Max.: B95 B95 B95



Nominal Dia: 1/2 "to 10" NB for seamless pipe

Schedules: 5S, 10S, 40S, 80S, 10, 20, 30...120, 140, 160, XXS
All dimensions are in accordance with ANSI B36.19 and ANSI B36.10
Size Range for tubing: OD:1/4" (6.25mm) to 8" (203mm), WT 0.02" (0.5mm) to 0.5"(12mm)

Length:30 m(Max) or as your requirement

Process:
Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube

Finish: Annealed & pickled, bright annealing, polished

Ends: Beveled or plain end, square cut, burr free ,Plastic Cap at Both end

Packing: Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.

UNS N08800/N08810/N08811  is characterized by:

-High creep strength
-Very good resistance to oxidation
-Good resistance to combustion gases
-Very good resistance to carburization
-Good resistance to nitrogen absorption
-Good structural stability at high temperatures
-Good weldability

The grade can be used at temperatures up to about 1100°C (2010°F). In order to have the best ductility this grade should be used above 700°C (1290°F). Because of its high nickel content and prescribed maximization of (Ti + Al) content, 31HT shows extremely little tendency to precipitation of embrittling phases.




Inspection and Test Procedure





Incoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And TubesIncoloy 800 Nickel Alloy Steel Seamless Pipes , Stainless Steel Pipes And Tubes
1.100% PMI,Spectro Chemical Aanlysis Test for Raw Material
2.100% Dimension & Visual Examination
3. Mechanical Properties Test Include Tension Test,Flaring Test (For Seamless tube/pipe)/ Flange Test (For Welded Pipe & Tube), Hardness Test ,Reversed Flattening Test
4.100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test  (ET or UT)
5.Radiographic Test for Welded Pipe (shall be accordance with specification,or shall be as agreed upon between the purchaser and vendor)
6.Straightness Test  (optional)
7.Roughness Test (optional)
8.Intergranular Corrosion Test(optional)
9.Impact Test (optional)
10.Grain Size Determinations (optional)

NOTES : ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION.
