SS304 SS316L Stainless Steel Tee Steel Butt - Weld Pipe Fittings 1-48 Inch

Basic Information

Place of Origin:	China
Brand Name:	Tobo
Certification:	SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number:	Tee

Minimum Order Quantity:	1pcs
Price:	USD Depending on quantity
Packaging Details:	PLY-WOODEN CASE OR PALLET
Delivery Time:	10-100 days depending on quantity
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	90000pcs per mouth

Get Best Price Contact Now

Product Name:

Super Duplex Uns S32750

Size:

1-48 Inch

Standard:

ASME B16.9

Material Grrade:

UNS S32750 UNSS32760

Highlight:

stainless steel pipe tee

steel pipe tee

SS304 SS316L Stainless Steel Tee Steel Butt - Weld Pipe Fittings 1-48 Inch

Specifications

Description:

1. Product Item No.: 005fittings-Cosco Steel

2. Size: NPS 1/2"-120"(DN15-3000)

3. Varieties: SCH5S/10S, SCH20/40/8 Pipe Fitting Stainless steel SMLS reducer tee 0/160, STD/XS/XXS, SGP

4. Material:
Carbon steel: ASTM A234 GR WPB , ST37.2 , ST35.8…
Alloy steel: A234 WP5/WP9/WP11/WP22/WP91, A420 WPL6, A860 WHPY 42/52/60/65/70/80…
Stainless steel: A403 WP304/TP304 , WP304L/TP304L , WP316/TP316 , WP316L/TP316L, WP321/TP321 , WP310/TP310…

5. Standard: ANSI B16.9/ANSI B16.28/MSS SP43/MSS P75/JIS2311/JIS 2312/JIS2313/ DIN2615/GB-12459/GB-T13401,Gost17376,we can also produce according to drawing by customers.

6. Surface treatment:
Carbon steel:Shot blasted, black painting, rust-proof oil, transparent oil,galvanizing,, hot galvanizing
Alloy steel:Shot blasted, black painting, rust-proof oil, transparent oil, galvanizing,, hot galvanizing
Stainless steel: pickled,

7. Trade term: FOB, CNF&CFR, CIF

8. Usage: Petroleum/ Power/ Chemical use/ Construction use/ Gas/ Metallury/ Shipbuilding

9. Certificate:GB/T19001-2008-ISO 9001:2008

10. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size

11. Packing: Wooden box or wooden pallet.

12. H.S Code: 73072300

ASME/ANSI B16.9 Butt-Welded Pipe Fittings/Stainless Steel Tee SS304 SS316L
1.Size:1/2"~72"
2.Thickness:SCH5S~SCH160

Nickel alloy steel:

Alloy 200/Nickel 200/NO2200/2.4066/ASTM B366 WPN;

Alloy 201/Nickel 201/NO2201/2.4068/ASTM B366 WPNL;

Alloy 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC;

Alloy K-500/Monel K-500/NO5500/2.475;

Alloy 600/Inconel 600/NO6600/NS333/2.4816;

Alloy 601/Inconel 601/NO6001/2.4851;

Alloy 625/Inconel 625/NO6625/NS336/2.4856;

Alloy 718/Inconel 718/NO7718/GH169/GH4169/2.4668;

Alloy 800/Incoloy 800/NO8800/1.4876;

Alloy 800H/Incoloy 800H/NO8810/1.4958;

Alloy 800HT/Incoloy 800HT/NO8811/1.4959;

Alloy 825/Incoloy 825/NO8825/2.4858/NS142;

Alloy 925/Incoloy 925/NO9925;

Hastelloy C/Alloy C/NO6003/2.4869/NS333;

Alloy C-276/Hastelloy C-276/N10276/2.4819;

Alloy C-4/Hastelloy C-4/NO6455/NS335/2.4610;

Alloy C-22/Hastelloy C-22/NO6022/2.4602;

Alloy C-2000/Hastelloy C-2000/NO6200/2.4675;

Alloy B/Hastelloy B/NS321/N10001;

Alloy B-2/Hastelloy B-2/N10665/NS322/2.4617;

Alloy B-3/Hastelloy B-3/N10675/2.4600;

Alloy X/Hastelloy X/NO6002/2.4665;

Alloy G-30/Hastelloy G-30/NO6030/2.4603;

Alloy X-750/Inconel X-750/NO7750/GH145/2.4669;

Alloy 20/Carpenter 20Cb3/NO8020/NS312/2.4660;

Alloy 31/NO8031/1.4562;

Alloy 901/NO9901/1.4898;

Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Alloy 926;

Inconel 783/UNS R30783;

NAS 254NM/NO8367;

Monel 30C

Nimonic 80A/Nickel Alloy 80a/UNS N07080/NA20/2.4631/2.4952

Nimonic 263/NO7263

Nimonic 90/UNS NO7090;

Incoloy 907/GH907;

Nitronic 60/Alloy 218/UNS S21800

standards

ASME B16.9-2007

ASME B16.25-2007

ASME B16.5-2007

EN10253-1-1999 EN10253-2-2007 EN10253-3-2008 EN10253-4-2008

DIN2605-1-1992 DIN2605-2-1995

JIS B2311-2009 JIS B2312-2009 JIS B2313-2009

GB/T12459-2005 GB/T13401-2005 GB/T10752-2005

SH/T3408-1996 SH/T3409-1996

SY/T0609-2006 SY/T0518-2002 SY/T0510-1998

DL/T695-1999 GD2000 GD87-1101

HG/T21635-1987 HG/T21631-1990

Dtailed Production Description

1)Size: Seamless: 1/2”-60" SCH10s-XXS

2)Standard: ANSI B16.9/B16.11/B16.28, DIN, JIS, ISO

3)Material:carbon steel:A234-WPB WPC,

alloy steel :A420-WPL6, A234-WP11, A234-WP12, A234-WP5,A234-WP9,A234-WP22,15Mo3,15CrMoV,35CrmoV

stainless steel:A403 WP 304-304L-304H-304LN-304N

A403 WP 316-316L-316H-316LN-316N-316Ti

A403 WP 321-321H

A403 WP 347-347H

low tempture steel: A402 WPL3-WPL6

high performance steel: A860 WPHY 42-46-52-60-55-70

4)Surface treatment: carbon steel: shot blasted, black painting, rust-proof oil,transparent oil, galvanizing,hot galvanizing

alloy steel: Shot blasted, black painting, rust-proof oil,transparent oil, galvanizing,hot galvanizing

stainless steel: pickled ,Polish

5)Nominal wall thickness:SCH5-SCH160, STD, XS, XXS

6)Packing: Wooden case or wooden pallet according to the size of fittings

7)Delivery time:7-10 days for a 20 ft container

8)Others:1) Special design available 2)All the production process are made under the ISO 9001:2000 strictly.

Application

Our products are widely used in pipeline engineering of the industries of oil and gas (including petrochemical), chemical

and pharmaceutial, pulp and paper, fertilizer, desalination, nuclear, electrict power, boiler,heat exchanger,metallurgy, refinery,

machinery,steel fabrication,shipbuilding, water disposal, construction, aviation,textile,ect.

our advangtage

1) Raw material use 100% material steel

2) good service

3) Competive price

4) Fast delivery

5)High quality products

other products

we can provide steel butt weld pipe fittings such as elbow, tee, reducer,cap,bend and so on. Good quality, competitive price

and excellence service are your best choice.

Specification

Norminal Pipe Size	Outside Diameter at Bevel				Center to End
DN	D1		D2		C	M
DN	Series A	Series B	Series A	Series B	C	M
20×20×15	26.9	25	21.3	18	29	29
25×25×20	33.7	32	26.9	25	38	38
25×25×15	33.7	32	21.3	18	38	38
32×32×25	42.4	38	33.7	32	48	48
32×32×20	42.4	38	26.9	25	48	48
32×32×15	42.4	38	21.3	18	48	48
40×40×32	48.3	45	42.4	38	57	57
40×40×25	48.3	45	33.7	32	57	57
40×40×20	48.3	45	26.9	25	57	57
40×40×15	48.3	45	21.3	18	57	57
50×50×40	60.3	57	48.3	45	64	60
50×50×32	60.3	57	42.4	38	64	57
50×50×25	60.3	57	33.7	32	64	51
50×50×20	60.3	57	26.9	25	64	44
65×65×50	76.1(73)	76	60.3	57	76	70
65×65×40	76.1(73)	76	48.3	45	76	67
65×65×32	76.1(73)	76	42.4	38	76	64
65×65×25	76.1(73)	76	33.7	32	76	57
80×80×65	88.9	89	76.1(73)	76	86	83
80×80×50	88.9	89	60.3	57	86	76
80×80×40	88.9	89	48.3	45	86	73
80×80×32	88.9	89	42.4	38	86	70
90×90×80	101.6	--	88.9	--	95	92
90×90×65	101.6	--	76.1(73)	--	95	89
90×90×50	101.6	--	60.3	--	95	83
90×90×40	101.6	--	48.3	--	95	79
100×100×90	114.3	--	101.6	--	105	102
100×100×80	114.3	108	88.9	89	105	98
100×100×65	114.3	108	76.1(73)	76	105	95
100×100×50	114.3	108	60.3	57	105	89
100×100×40	114.3	108	48.3	45	105	86
125×125×100	139.7	133	114.3	108	124	117
125×125×90	139.7	--	101.6	--	124	114
125×125×80	139.7	133	88.9	89	124	111
125×125×65	139.7	133	76.1(73)	76	124	108
125×125×50	139.7	133	60.3	57	124	105
150×150×125	168.3	159	139.7	133	143	137
150×150×100	168.3	159	114.3	108	143	130
150×150×90	168.3	--	101.6	--	143	127
150×150×80	168.3	159	88.9	89	143	124
150×150×65	168.3	159	76.1(73)	76	143	121
200×200×150	219.1	219	168.3	159	178	168
200×200×125	219.1	219	139.7	133	178	162
200×200×100	219.1	219	114.3	108	178	156
200×200×90	219.1	--	101.6	--	178	152
250×250×200	273	273	219.1	219	216	203
250×250×150	273	273	168.3	159	216	194
250×250×125	273	273	139.1	133	216	191
250×250×100	273	273	114.3	108	216	184
300×300×250	323.9	325	273	273	254	241
300×300×200	323.9	325	219.1	219	254	229
300×300×150	323.9	325	168.3	159	254	219
300×300×125	323.9	325	139.7	133	254	216
