ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness

  • ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness
  • ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness
  • ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness
  • ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness
  • ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number ASTM B338 GR.3
Minimum Order Quantity 100KGS
Price negotiable
Packaging Details Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time 10days->
Payment Terms T/T, L/C, Western Union,
Supply Ability 1500 tons per month
Product Details
Standard ASTM B338 GR.3 Color White Silver Gold
Types Stainless Steel Welded Pipe Outer Diameter 1.5mm-101.6mm
Highlight

SS Welded Tube

,

Welded Stainless Steel Tubing
Leave a Message
Product Description

ASTM B337,ASTM B338 GR.3 Titanium Alloy Tubes Thickness: 0.5 - 50 mm

Quick Details



Available Sizes
Products OD WT Length
Inch MM Inch MM Ft max. M max.
Tube 1/2"-3" 12.0-76.2 0.02"-0.5" 0.5-12.0 105' 32.00
Pipe NPS1/2"-6" 21.34-168.3 Sch10-Sch80 2.11-12.7 98' 30.00
Super Length Tube/Pipe is our advantages.





  • Standard: API, ASTM, API 5L, ANSI A213-2001
  • Thickness: 0.5 - 50 mm
  • Section Shape: Round
  • Outer Diameter: 6 - 200 mm
  • Place of Origin: China
  • Secondary Or Not: Non-secondary
  • Application: Condensers and Heat Exchangers
  • Technique: Cold Drawn
  • Certification: API
  • Surface Treatment: Bright
  • Alloy Or Not: Non-alloy
  • Type1: ASTM B338 GR.1 tubes
  • Type2: ASTM B338 GR.2 tubes
  • Type3: ASTM B338 GR.5 tubes
  • Type4: ASTM B338 GR.7 tubes
  • Type5: ASTM B338 GR.9 tubes
  • Type6: ASTM B338 GR.12 tubes
  • Type7: ASTM B338 GR.23 tubes
  • Type8: ASTM B338 GR.1 Titanium tubes
  • Type9: ASTM B338 GR.2 Titanium tubes
  • Type10: ASTM B338 GR.2 Titanium tubes for condensers and heat exchangers



ASTM B338 GR.3 Titanium alloy tubes



1. Titanium Pipe, Titanium Tube

Item name Titanium Pipe
Standard ASTM B337,ASTM B338,ASTM B861,ASTM B862
Material Gr1,Gr2,Gr3,Gr4,Gr5,Gr7,G9,Gr12,Gr23
Length can be customized
Application Chemical processing,Oil and chemicals,medical industry etc
Packaging Plywood case lined with foam or as per clients requirements
Payment T/T in advance or Irrevocable L/C at sight
MOQ 20Kg
Leadtime Within 15~20 days based on MOQ after deposit
Payment terms Payment terms: T/T or Irrevocable L/C at sight

2. Manudacturable Scope

ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness



3. Chemical requirements



  N C H Fe O Al V Pa Mo Ni Ti
Gr 1 0.03 0.08 0.015 0.20 0.18 / / / / / bal
Gr 2 0.03 0.08 0.015 0.30 0.25 / / / / / bal
Gr 3 0.05 0.08 0.015 0.30 0.35 / / / / / bal
Gr 5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
Gr 7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal
Gr 9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
Gr12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal


4. Tensile requirements

Grade Tensile strength(min) Yeild strength(min) Elongation(%)
ksi MPa ksi MPa
Grade1 35 240 20 138 24
Grade 2 50 345 40 275 20
Grade 3 65 450 55 380 18
Grade 5 130 895 120 828 10
Grade 7 50 345 40 275 20
Grade 9 90 620 70 438 15
Grade 12 70 438 50 345

18



ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm ThicknessASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness

ASTM B337 ASTM B338 GR.3 12" Std Titanium Alloy Tubes 6m length 0.5 - 50 mm Thickness
