10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow

Certification
Good quality Stainless Steel Elbow for sales
Good quality Stainless Steel Elbow for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner .

—— Thailand ---Dave Mulroy

ASTM A182 F55 Super Duplex Flange ,Good quality , we like that ! And delivery time in time also ,very professional.

—— USA ---Alfaro

I'm Online Chat Now

10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow

China 10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow supplier
10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow supplier 10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow supplier 10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow supplier 10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow supplier 10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow supplier

Large Image :  10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow

Product Details:

Place of Origin: CHINA
Brand Name: TOBO
Certification: SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: A420 WPL9

Payment & Shipping Terms:

Minimum Order Quantity: 500kgs
Price: negotiable
Packaging Details: in plastic bags then in bundles
Delivery Time: 15days->
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 7500 tons per year
Contact Now
Detailed Product Description
Standard:: 304,304L,TP316L,316L,316Ti,321,310S,317L,2205,347etc Color: White Silver Gold
Types:: Elbow Size: 1/2"---72"

Elbow Seamless 10” SCH STD LR 90° A420WPL9 ANSI B16.9



Material Carbon Steel Technics Forged Type Tee
Place of Origin China Model Number: Elbow Pressure 45 60 90 120 180
Wall thickness SCH10 SCH20 SCH40 Standard ANSI B16.9
Delivery Detail 7-90 Days




Specifications

ANSI B16.9 Elbow
1.Size:1/2""-72"
2.Material: A234-WPB
3.Wall Thickness: SCH10-XXS
4Certificate:ISO,PED

We specialized in manufacturing the carbon steel pipe and carbon steel pipe fittings

(elbows,reducers,tees, pipe caps, flanges) for more than 20 years

butt welded carbon steel pipe fittings is one of our main products,

the following are the details for your reference:



The specification sheet:

Size 1/2"---72"
Wall Thickness

SCH10,SCH20,SCH30,STD,SCH40,SCH60,XS,SCH80,SCH100,SCH120,

SCH140,SCH160,XXS, DIN, JIS standard thickness

Standard

ASTMA234,ASTM A420,ANSI B16.9/B16.28/B16.25,ASME B16.9,

JIS B2311-1997/2312, JIS B2311/B2312, DIN 2605-1/2617/2615,

GB 12459—99,EN Standard etc.

Material

Q235, 20#, 10#, Q345

A234 WPB, WP5, WP9, WP11,

ST37.0, ST35.8, ST37.2, ST35.4/8, ST42, ST45, ST52, ST52.4

STP G38, STP G42, STPT42, STB42, STS42, STPT49, STS49

Application Low and middle pressure fluid pipeline,boiler, petroleum and natural gas industry,drilling,chemical industry, electric industry,shipbuilding,fertilizer equipment and pipeline, structure, petrochemical, pharmaceutical industry
Surface Black painting, varnish paint, anti rust oil, hot galvanized, cold galvanized, 3PE, etc.
Package Plastic film,wooden cases ,wooden pallet,or on customers' request
Certificate ISO 9001:2008, SGS, BV, etc
Capacity 50,000 tons/year
Advantages

1.Reasonable price with excellent quality

2.Abundant stock and prompt delivery

3.Rich supply and export experience, sincere service

4.Reliable forwarder, 2-hour away from port.



anufacturing Standards



ASME: ANSI B16.9, ANSI B16.28, MSS-SP-43

DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011

EN: EN10253-1, EN10253-2



ASTM A403 /ASME SA403 - Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings



ASME B16.9 - Factory-Made Wrought Fittings Butt welding



ASME B16.25- Butt welding Ends



ASME B16.28- Wrought Steel Short Radius Elbows and Butt welding Returns



MSS SP-43 - Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Pipe Elbow

Material Grade



Stainless Steel Elbow; ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L



Carbon Steel Elbow: ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.



Low Temperature Carbon Steel Elbow: ASTM A420 WPL3, A420 WPL6



Alloy Steel Elbow: ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91



Duplex Steel Elbow: ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462



Nickel Alloy Elbow: ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 )





TOBO is a leading manufacturer and supplier of short radius and long radius elbows.

The long radius elbows have a center to end distance that is 1.5 times the NPS in inches (R=1.5D), while the short radius is equal to the NPS in inches (R=1.0D).

Short radius elbows are generally used in tight areas, and long radius elbows are used when space is available and flow is more critical.

We can also manufacture and supply carbon steel elbows and stainless steel elbows in non-standard size angles such as 60°, 100°, 120° or 150°.



10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow

10” SCH STD LR 90° A420WPL9 ANSI B16.9 Seamless Elbow ANSI B16.9 Elbow
