CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes

CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes
CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes
Basic Information
Place of Origin: China
Brand Name: TOBO
Certification: SGS
Model Number: TOBO-034
Minimum Order Quantity: 1 TON
Price: negotiable
Packaging Details: Thick Wooden Box Packing
Delivery Time: 7-15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 TON PER MONTH
Get Best Price Contact Now
Product Name: Tobo Copper Nickel Pipe Grade: 90/10
Wall Thickness: 0.90 - 2.50 Place Of Origin: China
OD: 8mm - 70 Mm Length: 9000mm
Brand: TOBO
Highlight:

copper nickel pipe

,

copper nickel tubing

CuNi10Fe1Mn 90/10 copper nickel tubes, heat exchanger copper tubes

CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes 0

CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes 1

90/10 Copper Nickel ( 90/10 Copper Nickel tube )

ASTM B111 C70600/ ASME SB111 C70600/BS 2871 PART 3 CN 102/EN 12451 CUNI1O FE1MN/NFA51 102 CUNI 10FE1MN/JIS H3300 C 7060



We are reckoned amongst the trusted manufacturers and exporters of a wide range of 90/10 Copper Nickel Tubes. Known for their flexibility, high corrosion resistance, superior tensile strength, trouble free installation and maintenance, these are in demand in different industries. To ensure complete client satisfaction, the entire array of 90/10 Copper Nickel Tubes is examined thoroughly on standard quality parameters before final delivery.


70/30 Copper Nickel

Backed by latest technologies and dexterous workforce, we are able to manufacture, supply and export an impeccable gamut of 70/30 Copper Nickel Tubes. These are machined in line with the set industry standards using qualitative raw materials that are sourced from authentic vendors of the domain. Our 70/30 Copper Nickel Tubes are sturdy in construction, dimensionally accurate, corrosion resistant, easy to install and maintenance free. Available in different standard specifications, the tubes can also be customized as per the clients' specifications at nominal prices.

Technical Specification

BS 2871 PART III/72 CN 102 & 07 EQUIVALENT SPEC.
ASTMB C70600 & 71500

Chemical Requirements C70600 C71500
Copper Remainder Remainder
Iron 1.0 to 2.0% 0.4 to 1.0%
Nickel 10 to 11% 30 to 32%
Manganese 0.5 to 1.0% 0.5 to 1.5%
Total Imp. 0.30% max. 0.30% max.



Physical Properties
Condition T.S. Kg/mm2 EL% Min T.S. Kg/mm2 EL% Min
Annealed (O) 35 35% 37.5-46 30%
As manufactured (M) 44 min - 51 min -




Further Tests

  • Drift Test
  • Hydraulic Test
  • Microstructure
  • Eddy Current Optional


Uses
Gr I : Excellent corrosion resistant to turbulently used in condensers forcoastal power plants, petroleum refineries and chemical plants.
Gr II : High impingement corrosion resistant to brackish sea water atvelocities upto 3 to 4 m/sec used in desalination plants and othersea water condenser application.



Service

Q: Are you trading company or manufacturer ?

A: We are manufacturer ,You can see the Alibaba certification.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:

Att:Summer

Tel: 0086 21 31261985



Why Choosing Metal Industrial:

-Sufficient Forging, Heating, Machining Equipment
-In-house Inspection Instruments for Quality Controlling
-Competitive Price & High Quality Assurance
-Fast, Effective and Efficient Services
-Directly supplier of Metallurgical Equipment
-Experienced Professinonals on Communications
