A403 WP316 Stainless Steel Elbows SCH10 - SCH160 XXS 45 90 180 Degree
| Place of Origin | China |
|---|---|
| Brand Name | TOBO |
| Certification | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Model Number | A403 WP316 Stainless elbow |
| Minimum Order Quantity | 100KGS |
| Price | negotiable |
| Packaging Details | in plastic bags then in bundles |
| Delivery Time | 15days-> |
| Payment Terms | T/T, L/C, Western Union, MoneyGram |
| Supply Ability | 1500 tons per month |
Product Details
| Standard | A403 WP316 Stainless Elbow | Color | Black |
|---|---|---|---|
| Material | Carbon Steel | Type | ELBOW |
| Highlight | Pipe Fittings Elbow,Butt Welding Elbow |
||
Product Description
A403 WP316 Stainless Steel Elbows SCH10 - SCH160 XXS 45 90 180 Degree
Quick Detail:
Name: A403 WP316 Stainless elbow
Size: 1/2”-48”
Thickness: SCH10-SCH160 XXS
Material: Stainless steel, alloy steel
Angle: 45°, 90°, 180°
Description:
A403 WP316 Stainless Steel Elbows SCH10 - SCH160 XXS , 45°, 90°, 180°
Elbow, Material including stainless, Carbon steel,
Alloy steel.
Specifications:
| Weld | Seamless |
Nominal size | DN250-DN1800 | DN15-DN700 |
Wall thickness | STD, XS,XXS,SCH10,SCH20,SCH30,SCH40,SCH60,SCH80,SCH160, etc. | |
Bending radius | R=1.5D-10D | |
Bending Angle | 45°, 90°, 180° | |
Stanard | ||
ASME | ANSI B16.9, ANSI B16.28, MSS SP75 | |
DIN | DIN2605, DIN2615, DIN2616, DIN2617, DIN28011 | |
SGP | JIS B2313 | |
EN | EN10253-1, EN10253-2 | |
Material | ||
| Carbon steel: A234 WPB | |
Stainless steel: A403 WP304, A403 WP304L, A403 WP316, A403 WP316L, A403 WP321 | ||
Alloy steel: A234 WP12, A234 WP11, A234 WP22, A234 WP5, A420 WPL6, A420 WPL3 | ||
DIN | Carbon steel: St37.0, St35.8, St45.8 | |
| Stainless steel: 1.4301, 1.4306, 1.4401, 1.4571 | |
| Alloy steel: 1.7335, 1.7380, 1.0488 (1.0566) | |
JIS | Carbon steel: PG370, PT410 | |
| Stainless steel: SUS304, SUS304L, SUS316, SUS316L,SUS321 | |
| Alloy steel: PA2, PA23, PA24, PA25, PL380 | |
GB | 10#,20#,20G,20R,Q235, 16Mn, 16MnR, 1Cr5Mo,12CrMo,15CrMo, 15CrMoG, 12Cr1MoVG, 12Cr1MoV. | |
TOBOGROUP deal with stainless steel welded pipe and tube already more than 10 years,
every year sell
more than 80000 tons of stainless steel pipe and tube. Our client already cover more than 45 countries.
Our stainless steel seamless pipe and tube was width used in Mining, Energy,
Petrochemical, Chemical
Industry, Food plant, Paper plant, Gas and Fluid Industry etc.
Why choose us!
1. We are the specialized supplier of stainless steel materials, can provide the best price!
2. We have more than 30 years experience in exporting products to worldwide countries, can provide the high quality products!
3. We have three thousand tons of stock in warehouses with abundant capital. Furthermore, we offer charge sales, credit and 7-day 24-hour services.
4. Wide excellent experiences with after-sale service.
5. Every process will be checked by responsible QC which insures every product's quality.
6. Professional packing teams which keep every packing ely.
7. Trial order can be done in very short time.
8. Samples can be provided as your requirements.
