Olet Socket 31803 /32750/32760 Forged Pipe Fittings 3000# 1/8"- 4"

Basic Information

Place of Origin:	China
Brand Name:	TOBO
Certification:	ISO/PED/TUV/SGS/LR/BV
Model Number:	TOBO-16

Minimum Order Quantity:	1 pcs
Price:	negotiable
Packaging Details:	Wooden case or as request
Delivery Time:	7-15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	100000pcs per month

Get Best Price Contact Now

Product Name:	TOBO Olet, Sockolet / Weldolet	Standard:	ASTM / ASME A/SA 182
Size:	1/8"-4"	Material:	F51,S31803, A182, F43,S32750
Class:	2000LB, 3000LB, 6000LB	Chemical Composition:	Ni MIn63%,Cu 28%-34%,Fe Max2.5%
Type:	Weldolet, Sockolet, Elbowlet, Thredolet, Nipolet, Letrolet, Swepolet	Place Of Origin:	China
Highlight:	forged steel pipe fittings , forged high pressure pipe fittings

Weldolet/Threadolet/Olet Socket 31803 /32750/32760 Forged fittings 3000# 1/8"-4"

Packaging & Delivery

Packaging Details

plywood case or plywood pallet, or as per the customers' requirement.

Delivery Time

20 days

Sockolet / Weldolet / Threadolet / Elbowolet / Flangeolet forged fittings.

ASTM A105 MSS SP-97 Weldolet class 3000 6000 9000 Forged Fitting Olet Butt Welding Olet

Weldolet/Threadolet/Olet Socket 31803 /32750/32760 Forged fittings 3000# 1/8"-4"

weldolet sockolet

Standard	(ASME/ANSI B16.11, MSS-SP-97, MSS-SP-79,JIS B2316, BS 3799etc)
Pressure(Thickness)	2000LB, 3000LB, 6000LB( SCH80, SCH160, XXS)
Process	Free forging, plate cutting .forged
Size	1/8"-4"(DN6-DN100)
Connect Type	Welded, threaded, BW, SW
Shape	Equal
Printing	Carbon steel and alloy steel with yellow print, black print, oil or zinc
Material	Carbon steel: 20#, 16Mn, ASTM A105,Q235,A350LF2, A350LF3, Stainless steel: ASTM A182 F304, F304L,F316,F316L, F317L, F321, F321H, F347, F347H, F310, F44 F51,S31803, A182, F43,S32750 Line Pipe: ASTM A694 F42,F46,F52,F56,F60,F65,F70, Low Alloy steel: A182 F12,F11,F22,F5,F9,F91,ECT Special Material: Monel, Duplex S.S, Alloy, Inconel, 904L etc.
Packing	Nylon bags, Wooden cases, or according to the customers' requirements
Certificates	ISO, API, CE, CCS, Factory audit by SGS
Delivery time	10-45 days depending on quantity
Shipment	FOB Tianjin/Shanghai, CIF, CFR, etc
Application	Petroleum, chemical, power, gas, metallurgy, shipbuilding, etc
Inspection	factory in-house or Third Party inspection available upon requests.

Product Name	Forging Steel Pipe Fittings
Standard	ASME/ANSI 16.11,JIS,B2316,DIN RESSURE CLASS: 3000#,6000#
Type	Thread& Socket Elbow: 45°,90° Tee: Equal, CON &ECC Reducer: Equal, CON &ECC Olet: weldolet, nippleolet, latrolet, elbolet Cap, Coupling, Union, Nipple... Special Fittings: According to the drawings
Materials	Nickel Alloy: ASTM/ASME S/B366 UNS N08020, N04400, N06600, N06625, N08800, N08810, N08825, N10276,N10665,N10675 Super Stainless Steel: ASTM/ASME S/A182 F44, F904L, F317L Stainles steel: ASTM/ASME S/A182 F304, F304L, F304H, F316, F316L, F321, F321H, F347H Duplex Steel: ASTM A182 F51, F53, F55 Alloy Steel: ASTM/ASME S/ A182 F11, F12, F22, F5, F9, F91 Carbon Steel: ASTM/ASME S/A105, ASTM/ASME S/A350 LF2, ASTM/ASME S/A694/A694M, F42, F52, F56, F60, F65, F70....ASTM/ASME S/A350 LF2, ASTM/ASME S/A694/A694M, F42, F52, F56, F60, F65, F70....
Dimension	From DN15 to DN150
Pressure of products	Socket weled : 3000LB 6000LB 9000LB (sch80 sch160 xxs) Threaded : 2000LB 3000LB 6000LBS (sch80 sch160 xxs)
Marking	Supply Logo + Standard + Size(mm) + HEAT NO +or as your requirement
Test	Chemical Component Analysis, Mechanical Properties, Metallurgical Analysis, Impact Testing, Hardness testing , Ferrite Testing, Intergranular corrosion testing, X-ray Inspection (RT), PMI, PT, UT, HIC & SSC test, etc. or as your requirment
Brand	TOBO Group
Certificates	API, ISO, SGS, BV, CE, PED, KOC, CCRC, PDO, CH2M HILL and etc.
Application	Petroleum, chemical, machinery, electric power, shipbuilding, papermaking, construction, etc

Stainless Steel Socket Weld 316 Forged OUTLET/ WELDOLET/NIPPLE/UNION/PLUG Pipe Fitting

Q: Are you trading company or manufacturer?

A: TOBO Group is a manufacturer for pipe fittings .

Q: Do you supply EPC Services?

A: We provides complete range of International project services for Engineering, Procurement, Fabrication, Construction, Commissioning, Management and Financing to our clients for various projects, and these services are ensured by the strategic partner of top China Govt. EPC.

Q: How to order?

A: 1.To specify british,or American or German threads.

2.To specify galvanized or black

3.To specify plain or banded or beaded

4.To specify figure number,size and quantity in pieces

Q: How about the MOQ?

A: Generally, the trail order will be accepted.

Q: How about the delivery time?

A: With 15-30days after down payment received;

Of course, the detail will be confirmed by the quantity and the different products.

Q: Do you have any certifications?

A: Yes, with ISO, BV, SGS, TUV, API, KOC, CRCC, PDO and so on.

Q: Do you have Mill Test Certificates?

A: Yes.

Q: Do you accept the third party inspection?

A: Yes. We accept.

Q: Do you provide customized products?

A: Yes. Customers give us drawings and specifications, and we will manufacture accordingly.
