Inconel 625 Threaded Flange Forged Steel Fittings 1/2" To 48" ( DN15-1200)

China Inconel 625 Threaded Flange Forged Steel Fittings 1/2" To 48" ( DN15-1200) supplier
Inconel 625 Threaded Flange Forged Steel Fittings 1/2" To 48" ( DN15-1200) supplier Inconel 625 Threaded Flange Forged Steel Fittings 1/2" To 48" ( DN15-1200) supplier Inconel 625 Threaded Flange Forged Steel Fittings 1/2" To 48" ( DN15-1200) supplier

Large Image :  Inconel 625 Threaded Flange Forged Steel Fittings 1/2" To 48" ( DN15-1200)

Product Details:

Place of Origin: China
Brand Name: Forged Steel Flang
Certification: SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: 001

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Depending on quantity
Packaging Details: 10-100 days depending on quantity
Delivery Time: 10-100 days depending on quantity
Payment Terms: T/T or Western Union or LC
Supply Ability: 3,0000pcs per month
Contact Now
Detailed Product Description
Size: 1/2"-48" Standard: ASTM, Etc
Product Name: Forged Steel Flange Product Type: Threaded Flange
Thickness: SCH5~SCH160



Inconel 625 Threaded Flange Forged Steel Fittings 1/2" To 48" ( DN15-1200)

Quick Details

Material: Inconel 625, etc Technics: Forged Type: Inconel 625 Threaded Flange
Place of Origin: Shanghai, China (Mainland) Head Code: Round Brand TOBO
Connection: Welding Shape: Equal

Packaging & Delivery

Packaging Details: plywood case or fumigation woodern case
Delivery Detail: 2 - 10 days

Specifications

Inconel 625 Threaded Flange

1.Size: ½" to 48"
2.Class / Pressure: 150#, 300#, 600#, 900#, 1500#, 2500#, etc

3.Standard: ASME, JIS, DIN, ANSI, etc.

4.Material: Inconel 625, etc

Inconel 625 Threaded Flange is widely demanded as pipe flanges i.e called as threaded pipe flanges used in different industrial applications. They are the special type of pipe flanges which can be attached to the pipe without welding. Threaded flanges are threaded in the bore which match an external thread on the pipe. These threads are tapered in order to create a seal between the threaded flange and the pipe as the tapers approach the same diameter. Sometimes a seal weld is also used together with the threaded connection. They are available in various sizes and materials.

Description Of Inconel 625 Threaded Flange

Type Inconel 625 Threaded Flange
Size 1/2" To 48" (DN15-1200)
Wall thickness



sch10, sch20, sch30, std, sch40, sch60,

xs, sch80, sch100, etc



Standards ASME, ASTM, DIN, JIS, etc
Material

Carbon Steel: ASTM: SA105N/A105, ASTM SA350 LF2,etc

Stainless Steel: ASTM A182 F304/304L/316/316L, etc

Alloy Steel: ASTM A182 F1/F5/F9/F11/F22/F91, Etc.

Duplex stainless steel: ASTM A182 F51/F53/F55/F60, etc

Nicke alloys: Nickel 200, Monel 400, Inconel 600/625, Incoloy 825/800,

Hastelloy C276, Hastelloy C22, Hastelloy B1/B2/B3, Alloy 20, etc

Cu-Ni: 90/10,70/30, etc



Surface treatment Transparent oil, rust-proof black oil or hot galvanized
Applications Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc







UNS N06625
Werkstoff Nr. 2.4856



What are the characteristics of Inconel 625?

· High creep-rupture strength

· Oxidation resistant to 1800° F

· Seawater pitting and crevice corrosion resistant

· Immune to chloride ion stress corrosion cracking

· Non-magnetic

1.1.1

Chemical Composition, %

Cr Ni Mo Co + Nb Ta Al Ti C
20.00-30.00 Remainder 8.0-10.0 1.0 max 3.15-4.15 .40 max .40 max .10 max



Fe Mn Si P S
5.0 max .50 max .50 max .015 max .015 max

1.1.2 Mechanical & Physical Properties – Inconel 625

Density 8.4 g/cm3
Melting Point 1350 °C (2460 °F)
Tensile Strength Psi – 135,000 , MPa – 930
Yield Strength (0.2%Offset) Psi – 75,000 , MPa – 517
Elongation 42.5 %

In what applications is Inconel 625 used?

· Aircraft ducting systems

· Aerospace

· Jet engine exhaust systems

· Engine thrust-reverser systems

· Specialized seawater equipment

· Chemical process equipment



Inconel 625 is a corrosion and oxidation resistant nickel alloy that is used both for its high strength and outstanding aqueous corrosion resistance. Inconel Alloy 625 has excellent fatigue strength and stress-corrosion cracking resistance to chloride ions. This nickel alloy has excellent weldability and is frequently used to weld AL-6XN.





Inconel 625 Threaded Flange Packing & Shipping

1) Packing Method:

Normal packing: plastic film or bubble paper wrapped on product's surface ,protect ends with caps,

pack with wooden case or load on fumifation plywood pallet .

Custom made as customers request .

2) Shipping Way:

Usually by Sea, By Air, By Train or River-and-Sea Coordinated Transport.
