Place of Origin: | China |
---|---|
Brand Name: | TOBO |
Certification: | ISO/PED/TUV/SGS/LR/BV |
Model Number: | 20Cr13 S42020 |
Minimum Order Quantity: | 500Kg |
Price: | negotiable |
Packaging Details: | in plastic bags then in bundles |
Delivery Time: | According to the qty |
Payment Terms: | T/T, L/C, Western Union, MoneyGram |
Supply Ability: | 7500 tons per year |
Standard:: | ASTM A312 A213 A269 A554 A249 A270 | Color: | White Silver Gold |
---|---|---|---|
Types:: | Stainless Steel Seamless Pipe / Tube | Material Grade: | 20Cr13 S42020 |
Outer Diameter: | 6mm-830mm | Application: | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding Etc |
Brand: | TOBO | Origi: | Shanghai |
Highlight: | marine stainless steel tubing,stainless steel round tube |
Standard Specification:
ASTM A213 / A213M - 11a:Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A269 - 10:Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
ASTM A312 / A312M - 12:Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
ASTM A511 / A511M - 12:Standard Specification for Seamless Stainless Steel Mechanical Tubing
ASTM A789 / A789M - 10a:Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
ASTM A790 / A790M - 11:Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
DIN 17456-2010:GENERAL PUROSE SEAMLESS CIRCULAR STAINLESS STEEL TUBES.
DIN 17458-2010:Seamless Circular of Austenitic Stainless Steel Tube
EN10216-5 CT 1/2 : Stainless Steel Seamless Pipe & Tube
GOST 9941-81:SEAMLESS COLD- AND WARM-WORKED TUBES MADE OF CORROSION RESISTANT STEEL.
Others like BS, JIS standard or can supply
Seamless Stainless Steel Pipe:
1. Material: TP316, TP316L
2 Standard: ASTM A312 A213 A269 A554 A249 A270
SIZE RANGE :
STEEL TYPES |
SIZE RANGE |
Stainless steel seamless pipe&tube |
OD: 6-830mm WT: 0.6-60mm |
U-Tube |
OD: 12-38mm WT: 0.6-4mm |
OTHER MAIN STEEL TYPE AND GRADE :
PRODUCTS |
TYPICAL STEEL GRADE |
Austenitic |
TP304,TP304L,TP304H,TP316,TP316L,TP316H,TP316Ti |
Duplex / Super Duplex |
S31803, S32205, S32750 |
MAIN PRODUCTION STANDARDS:
STANDARD TYPE |
STANDARD |
EN |
EN10216-5 , EN10216-2 |
DIN |
DIN 17456 , DIN 17458 |
ASTM |
ASTM A312, A213, A269, A511, A789, A790 ETC |
GOST |
GOST 9941 , GOST 5632 |
JIS |
JIS G3459 , JIS G3463 |
GB |
GB/T14975,GB/T14975, GB13296, GB5310, GB9948 |
SPECIFICATIONS:
Mechanical Property |
Material Item |
304 |
304L |
304 |
316L |
Top Technology |
Tensile Strength |
≥520 |
≥485 |
≥520 |
≥485 |
||
Yield Strength |
≥205 |
≥170 |
≥205 |
≥170 |
||
Extension |
≥35% |
≥35% |
≥35% |
≥35% |
||
Hardness (HV) |
<90 |
<90 |
<90 |
<9 |
PACKING:
Package of Stainless Steel Pipes/Tubes : our products are packed, stored, transported according to the international regulation. We do care about the quality of our products; even some little details are paid attention to. We wrap the stainless steel products with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement. Plus, our storage racks are made of wood. Other kinds of metals are settled in other places, far from the stainless steel. Any unwanted chemical reaction can be prevented.
Applications of Stainless Steel Pipes/Tubes:
1). Petroleum, Chemical enterprise, super heater of boiler, heat exchanger
2). High temperature resistant transmission fluid pipe in power station
3). Ship with pressure pipe
4). The exhaust purification device
5). Construction and ornament
