Cold Drawn Stainless Steel Seamless Pipe 6" Equal Tee SCH STD Alloy 20

Basic Information

Place of Origin:	China/Japan/Germany
Brand Name:	TOBO/TPCO/TISCO/VALIN/METAL
Certification:	ISO/PED/TUV/SGS/LR/BV
Model Number:	Alloy 20 UNS N08020

Minimum Order Quantity:	300 Kilogram/Kilograms
Packaging Details:	Export standards or customer requirements
Delivery Time:	7-30 working days after received deposit
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50 Metric Ton/Metric Tons per Month

Get Best Price Contact Now

Product Name:	Tee	Product Type:	Steel Pipe
Grade:	200 Series &300 Series &400 Series	Shape:	Round
OD:	168.3 - 3048 Mm	Surface:	Painted
Application:	Oil Pipe	Techinque:	Cold Drawn
Highlight:	marine stainless steel tubing , seamless stainless steel tube

Pipe Fittings 6" Equal Tee, SCH STD Alloy 20 UNS N08020 NACE MR0175

What are the characteristics of Alloy 20?

· Excellent general corrosion resistance to sulfuric acid

· Excellent resistance to chloride stress corrosion cracking

· Excellent mechanical properties and fabricability

· Minimal carbide precipitation during welding

· Excels in resisting corrosion to hot sulfuric acids

Chemical Composition, %

Ni	Fe	Cr	Cu	Mo	Nb	C	Mn	P	S	Si
32.00-38.00	Balance	19.0-21.0	3.0-4.0	2.0-3.0	8xC-1.0 max	.07max	2.0 max	.045 max	.035 max	1.0 max

In what applications is Alloy 20 used?

· Synthetic rubber manufacturing equipment

· Processing of pharmaceuticals, plastics and organic and heavy chemicals

· Tanks, piping, heat exchangers, pumps, valves, and other process equipment

· Acid cleaning and pickling equipment

· Chemical process piping, reactor vessels

· Bubble caps

· Petrochemical process equipment

· Food and dye production

Mechanical Properties

Annealed Material

Form	Tensile Min.	Yield Min. (.2% offset)	Elongation Min.	Reduction of Area Min.
Bar (hot or cold finished)	80 ksi	35 ksi	30%	50%
Sheet/Plate	80 ksi	35 ksi	30%	-

Product Specification

Name	pipe fitting elbow
Material	stainless steel	ASTM A240 304 304L 316L 321 321H 347 347H 904L ASTM A789 S31803 S32205 S32750
	Carbon Steel	ASTM A234 WPB A420 WPL3 WPL6 A516 GR70 GR65 GR60 GR55 ISO3183/API 5L L36/X52 L415/X60 L450/X65 L485/X70?
	Alloy Steel	ASTM A335 P11 P22 SA387 GR.11 GR.22
	Titanium	Gr1 Gr2 Gr3 Gr5 Gr7 Gr12
	Copper/Brass	We can also produce according to customer's requirements
Standard??	ASME B16.9, ANSI B16.9, ASTM , JISB2312,DIN,BS, GBT12459-05, GB13401-05,GOST
	ASME B16.9-2007,MSS SP 43-1991,MSS SP-75,ASTM B363
Wall thickness	Sch5S, Sch10S, Sch40S, Sch80S Sch10,Sch20,Sch30,STD,Sch40,Sch60,XS,Sch80,Sch100,Sch120,Sch140,Sch160,XXS,
Size	1/2"-96" ? DN15-DN2400
Type	Butt welded or Seamless
Shape	Equal or Reducing
Product	1.Elbow?L/R & S/R (45/90/180 DEG) according to customer's requirement can produce the other's degree, such as 22.5 degree 30 degree 60 degree etc.
	2. Tee(Straight and Reducing)
	3. Reducer(Concentric and Eccentric)
	4. Cross
	5. Cap(Round and Elliptical)
	6. Stub End
Quality Control	Good quality control system which covers every process of the manufacturing-Raw material inspection,cutting,bending,sizing,shot blasting,beveling,coating,marking,packing,delivery;
Application	Pipe fitting is the occupation of installing or repairing piping or tubing systems that convey liquid, gas, and occasionally solid materials. This work involves selecting and preparing pipe or tubing, joining it together by various means, and the location and repair of leaks.
Surface	Black painting ; Pickling ; Sand blasting
Certificate	ISO9001 ; ISO9001:2008
Package	Wood case or Wooden pallets or according to the customer's requirements.
Features	1) Chemical and Physical characteristic: durable, corrosion resistant and high-temperature resistant 2) We also produce pipes with special specifications according to customers' requirements;
Lead Time	Within 30 days or according to the customer's requirements.
MOQ	1 Piece
OEM	YES
