Duplex Stainless Steel Seamless Pipe 3-12m Length ASTM A789 UNS S32750 Pipe

  • Duplex Stainless Steel Seamless Pipe 3-12m Length ASTM A789 UNS S32750 Pipe
  • Duplex Stainless Steel Seamless Pipe 3-12m Length ASTM A789 UNS S32750 Pipe
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number S31803 (F51), S32205 (F60) Alloy 2205,S32550 (F61),S32750 (F53), Alloy 2507 and S32760 (F55)
Minimum Order Quantity 100KGS
Price negotiable
Packaging Details Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time 10days->
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 1500 tons per month
Product Details
Standard S31803 (F51), S32205 (F60) Alloy 2205,S32550 (F61),S32750 (F53), Alloy 2507 And S32760 (F55 Color White Silver Gold
Types Duplex Stainless Steel Pipe Outer Diameter 1.5mm-2000mm
Highlight

duplex stainless steel seamless pipe

,

ASTM A789 stainless steel pipe

,

UNS S32750 seamless pipe
Leave a Message
Product Description

Duplex Stainless Steel Seamless Pipe 3-12m Length ASTM A789 UNS S32750 High Temperature

UNS 31803 (F51), UNS 32205 (F60) Alloy 2205, UNS S32550 (F61), UNS S 32750 (F53), Alloy 2507 and UNS 32760 (F55)

Standards: ASTM/ASME A789/SA789, A790/SA790, A450,A530

Material: UNS S31803(Cr22Ni5Mo3/1.4462)/2205,UNS S32750(1.4410),UNS S31500(Cr18NiMo3Si2), UNS32760(1.4501)

Chemical Composition

Grade

C

 max

Si

max

Mn

max

P

max

S

max

Cr

Ni

Mo

N

UNS S32750

0.030

0.8

1.2

0.030

0.015

24.0-26.0

6.0-8.0

3.0-5.0

0.24-0.32

UNS S31803

0.030

1.0

2.0

0.020

0.020

21.0-23.0

4.5-6.5

2.5-3.5

0.08-0.20

UNS S31500

0.030

1.0

1.2-2.0

0.030

0.030

18.0-19.0

4.5-5.5

2.5-3.5

0.05-0.10

  Physical Properties

Grade

Y.S.MPa min

T.S.Mpa min

Elongation %

Hardness HRC

UNS S32750

550

800

15

20

UNS S31803

450

620

25

20

UNS S31500

440

630

30

20

Duplex Stainless Steel Pipe Application:

Chemical processing, Transport and Storage.

Oil and gas exploration and offshore rigs .

Oil and gas refining.

Marine environments.

Pollution control equipment.

Pulp and paper manufacturing

Chemical process Plant

Material Grade:



American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H,  TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...

Europen Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

Russia Standard

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ

TOBO GROUP :


Make development by enlarging scale brand building and internationalization.
Keep Challenging and Innovation.
Advance manufacturing instruments.
Create perfect quality.
Take strict testing as guarantee, upgrade grade as object.
EXHIBITION AND CUSTORMER SATISFACTORY





APPLICATIONS FIELD :



1. Pipe and Tubes for petrochemical industry

2. Pharmaceutical industry
3. Food industry
4. Aviation and aerospace industry
5. Architectural decoration industry



Duplex Stainless Steel Seamless Pipe 3-12m Length ASTM A789 UNS S32750 Pipe 0Duplex Stainless Steel Seamless Pipe 3-12m Length ASTM A789 UNS S32750 Pipe 1Duplex Stainless Steel Seamless Pipe 3-12m Length ASTM A789 UNS S32750 Pipe 2
