A182 F11, F12, F22, F5, F9, F91 WELD NECK FLANGE, CL600,8inch ASME B16.5

Basic Information

Place of Origin:	China
Brand Name:	TOBO
Certification:	ISO
Model Number:	2205

Minimum Order Quantity:	1
Price:	USD 60/ PC
Packaging Details:	according to customer requirement
Delivery Time:	15 workdays
Payment Terms:	T/T
Supply Ability:	3000/ Per month

Get Best Price Contact Now

Type:	WN , SO , BL ,SW	Technics:	Forged, Casting, Rolled, Cold Forming, Cold Drawing
Standard:	ANSI, DIN, BS, ASME B16.9, GB	Name:	Forged Steel Flanges
Material:	Carbon Steel, Stainless Steel, Alloy, SS316L, Stainless Steel(ASTM A403 WP304	Type:	UNSN0622
Highlight:	ASTM A182 Forged Steel Flanges , PN16 Forged Steel Flanges , Weld Neck Forged Steel Flanges

A182 F11, F12, F22, F5, F9, F91 WELD NECK FLANGE, CL600,8inch ASME B16.5

Product Description

Product Name	Carbon steel / Stainless steel / Alloy Flanges
Standard	ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092
Type	WN Flange, So Flange, LJ Flange, LWN Flange, SW Flange, Orifice Flange, Reducing Flange, figure 8 blind (blank&Spacer) Special Flange: According to the drawing Picture
Materials	Nickel Alloy: ASTM/ASME S/B366 UNS N08020, N04400, N06600, N06625, N08800, N08810, N08825, N10276,N10665,N10675 Super Stainless Steel: ASTM/ASME S/A182 F44, F904L, F317L Stainles steel: ASTM/ASME S/A182 F304, F304L, F304H, F316, F316L, F321, F321H, F347H Duplex Steel: ASTM A182 F51, F53, F55 Alloy Steel: ASTM/ASME S/ A182 F11, F12, F22, F5, F9, F91 Carbon Steel: ASTM/ASME S/A105, ASTM/ASME S/A350 LF2, ASTM/ASME S/A694/A694M, F42, F52, F56, F60, F65, F70....ASTM/ASME S/A350 LF2, ASTM/ASME S/A694/A694M, F42, F52, F56, F60, F65, F70....
Dimension	(150#,300#,600#): DN15-DN1500 900# : DN15-DN1000 1500#: DN15-DN600 2500#:D N15-DN300
Marking	Supply Logo + Standard + Size(mm) + HEAT NO +or as your requirement
Test	Chemical Component Analysis, Mechanical Properties, Metallurgical Analysis, Impact Testing, Hardness testing , Ferrite Testing, Intergranular corrosion testing, X-ray Inspection (RT), PMI, PT, UT, HIC & SSC test, etc. or as your requirment
Brand	TOBO
Certificates	API, ISO, SGS, BV, CE, PED, KOC, CCRC, PDO, CH2M HILL and etc.
Advantages	1. Abundant stock and prompt delivery 2. Reasonable for whole packages and processes. 3. 15 years' QC team service & sales management API& ASTM trained engineers. 4. More than 150 customers spread worldwide. (Petrofac, G.S Engineer, Fluor, Hyundai Heavy industry, Kuwait National Oil, Petrobras, PDVSA, PetroEcuador, SHELL, etc.)
