Weld Neck Flange, RFFE, BE, 3", S-40S, CL150, ASME-B16.5, ASTM A182 Gr.F 44 (UNS $31254)

Basic Information

Place of Origin:	CHINA
Brand Name:	TOBO
Certification:	BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number:	Forged Steel Flange

Minimum Order Quantity:	0.5-1 tons
Price:	negotiable
Packaging Details:	in plastic bags then in bundles
Delivery Time:	According to the qty
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	6000TONS/MONTH

Get Best Price Contact Now

Pressure:	Class150,150#-2500#,5K-30K	Logo:	Customized Logo
Keyword:	Steel,A105,NPT Threaded Blind Flange,weld Neck Flange Ansi 150 Rf,Titanium	Material:	Alloy 31
Product Name:	Flange	Standard Or Nonstandard:	ASME B16.5
Application:	Gas, Petroleum, Auto Parts, Concrete Pump, Water	Type:	Blind,weld Neck Flange,threaded,Pipe Flange,socket Welding

Weld neck flange, RFFE, BE, 3", S-40S, CL150, ASME-B16.5, ASTM A182 Gr.F 44 (UNS $31254)

Quick Details

Place of Origin:: hebei

Brand Name:: ST

Model Number:: flange 5147

Standard:: ANSI, bs, DIN, GB, ISO, JIS, Jpi, ASME

UNS S31254 F44

A fully austenitic alloy with excellent corrosion resistance in a wide variety of aggressive, aqueous environments, widely used in the chemical processing and power industry for piping.

F44 is an austenitic stainless steel used in seawater and other aggressive chloride-bearing media. This grade has excellent resistance to pitting and crevice corrosion, high resistance to general corrosion and stress corrosion cracking, with a higher strength than conventional austenitic stainless steels, and good weldabilit

F44 is also known as 254 SMO® ,1.4547 and SS2378.

Material: A182 F44 (254SMO Flange,UNS S31254 Flange,1.4547 Flange)
Pressure: 150-2500LBS (2500#/Class 2500)
Standard: ANSI B16.5
Ends: Raised Face

UNS S31254 A182 F44 Chemical Properties

	C	Cr	Cu	Fe	Mo	Mn	N	Ni	P	S	Si
Min	–	19.5	0.5	Balance	6.0	–	0.18	17.5	–	–	–
Max	0.02	20.5	1.0		6.5	1.0	0.22	18.5	0.030	0.010	0.8

Weld Neck Flange, RFFE, BE, 3", S-40S, CL150, ASME-B16.5, ASTM A182 Gr.F 44 (UNS $31254) 0

Weld Neck Flange, RFFE, BE, 3", S-40S, CL150, ASME-B16.5, ASTM A182 Gr.F 44 (UNS $31254) 1

FAQ

1.Q: Are you manufacture or trade company?
A:We are manufacture specialized in PVC pipes and rubber hoses ; Our produces have CE and ISO certification.

2.Q: How can I get the samples?

A:If you need some samples to test, we can make as per your request .You should pay for the transportation freight of samples and our samples cost, while the samples cost can be refundable after you place the order if the amount meets our requirement.

3.Q:How much the transportation freight of samples?

A:The freight depends on the weight and packing size and your area.

4.Q:How long can I expect to get the sample?

A:The samples will be ready for delivery within one week. The samples will be sent via express and arrive in 4-7 days.

5.Q:Can we have our Logo or company name to be printed on your products or package?

A:Sure.Your Logo can be put on your products by Hot Stamping,Printing,Embossing,UV Coating,Silk-screen Printing or Sticker.

6.Q:How to order?

A: Please send us your purchase order by Email or you can ask us to send you a proforma invoice for your order. We need to know the following information for your order:

1) Product information-Quantity, Specification (Size, Material, Technological and Packing requirements etc.)

2) Delivery time required.

3) Shipping information-Company name, Street address, Phone &Fax number, Destination sea port.

4) Forwarder's contact details if there's any in China.
