Blind Flange, FFFE, 3", CL150, ASME-B16.5, ASTM A182 Gr.F 44 (UNS S31254)
| Place of Origin | CHINA |
|---|---|
| Brand Name | TOBO |
| Certification | BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Model Number | Forged Steel Flange |
| Minimum Order Quantity | 0.5-1 tons |
| Price | negotiable |
| Packaging Details | in plastic bags then in bundles |
| Delivery Time | According to the qty |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 6000TONS/MONTH |
Product Details
| Logo | Customized Logo | Keyword | Steel,A105,NPT Threaded Blind Flange,weld Neck Flange Ansi 150 Rf,Titanium |
|---|---|---|---|
| Application | Gas, Petroleum, Auto Parts, Concrete Pump, Water | Material | SS |
| Pressure | Class150,150#-2500#,5K-30K | Product Name | Flange |
| Standard Or Nonstandard | ASME B16.5 | Type | Blind,weld Neck Flange,threaded,Pipe Flange,socket Welding |
| Highlight | 3 inch blind flange CL150,ASME B16.5 forged steel flange,ASTM A182 F44 blind flange |
||
Product Description
Blind flange, FFFE, 3", CL150, ASME-B16.5, ASTM A182 Gr.F 44 (UNS S31254)
ASTM A182 F44 FLANGES, ASME SA182 F44 FLANGES, ASTM A182 UNS S8904 FLANGE, A182 SMO 254 FLANGES, STAINLESS STEEL SMO 254 FLANGES, UNS S31254 STAINLESS STEEL FLANGES, SS F44 FLANGES, MANUFACTURER IN INDIA.
Savoy Piping Inc., is an ISO 9001:2015, PED/27/EC and OHSAS 18001:2007 Approved Manufacturer of ASTM A182 F44 Flanges in Specification in Types Like A182 F44 Weldneck Flange, A182 F44 Blind Flange, A182 F44 Socketweld Flange, A182 F44 Slip On Flange, A182 F44 Threaded Flange, A182 F44 Laped Joint Flange, A182 F44 Screw Flange, A182 F44 Plate Flange, 44 WNRF Flange, BLRF Flange, SWRF Flange, A182 F44 SORF Flange etc.
Manufacturer and Exporter of ASTM A182 F44 Flanges in Dimension accordance with ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092-1, DIN, etc. Certified with NACE, PWHT, HIC, SSC, Magnetic Particle Test, Dye Penereteration Test etc.
ASTM A182 F44 Flange Chemical Compostion and Properties
The chemical composition of grade ASTM A182 F44 Flange is outlined in the following table
| Steel Grade | C | Si | Mn | P | S | Cr | Ni | Mo | Cu | N |
| F44 | 0.02 max | 0.8 max | 1.0 max | 0.030 max | 0.010 max | 19.5-20.5 | 17.5-18.5 | 6.0-6.5 | 0.50-1.00 | 0.18-0.22 |
| 1.4547 | 0.02 max | 0.7 max | 1.0 max | 0.030 max | 0.010 max | 19.5-20.5 | 17.50-18.50 | 6.0-7.0 | 0.50-1.00 | 0.18-0.25 |
ASTM A182 F44 Flange Mechanical and Physical Properties
ASTM A182 F44 Flange Physical Properties
Physical properties of ASTM A182 F44 grade stainless steel in the annealed condition
| Hardness (HB) | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) (Long.) | Impact Value (J) (Long.) |
| 260 max | 650-850 | 300-340 | 35 min | 100 min |
FAQ
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 4-8 weeks if no stock or need to be customized. It is according to purchase quantities.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000$, 100% deposit. Payment>=1000$, 30% deposit ,balance before shipment.
