45° Elbow, Long Radius, BE, BE, 5", S-10S, ASME-B16.9, ASTM A403 Grade WPS31254,Seamless

  • 45° Elbow, Long Radius, BE, BE, 5", S-10S, ASME-B16.9, ASTM A403 Grade WPS31254,Seamless
  • 45° Elbow, Long Radius, BE, BE, 5", S-10S, ASME-B16.9, ASTM A403 Grade WPS31254,Seamless
  • 45° Elbow, Long Radius, BE, BE, 5", S-10S, ASME-B16.9, ASTM A403 Grade WPS31254,Seamless
Place of Origin CHINA
Brand Name TOBO
Certification BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number ASTM A403 Grade WPS31254
Minimum Order Quantity 0.5-1 tons
Price negotiable
Packaging Details in plastic bags then in bundles
Delivery Time According to the qty
Payment Terms L/C, D/A, D/P, T/T, Western Union,
Supply Ability 7500 tons per year
Product Details
Material Stainless Steel Name 45 Degree Elbow
Technics Seamless Size Customized Size
Application Connect Pipes,oil Pipelines Shape Equal
Type Elbow Color Customer's Requirement
Highlight

Seamless Steel 45 Degree Elbow

,

ANSI Stainless Steel 90 Degree Elbow

,

Curved Tube Stainless Steel Elbow
Leave a Message
Product Description

45° Elbow, Long Radius, BE, BE, 5", S-10S, ASME-B16.9, ASTM A403 Grade WPS31254,Seamless



BUTT WELD FITTINGS.

We are engaged in manufacturing of a wide range of Butt Weld Fitting that is available in varied types such as L/R & S/R elbow, tee, concentric and eccentric reducers, reducing elbow & tee, cross and caps. Sourced from reliable vendors, these fittings are highly acknowledged for their high tensile strength, durability and accurate alloy composition. These find application in several industries such oil & gas, automobile, acid & chemical, pharmaceutical and cement industries. We are known for our butt welding fitting pieces.

Sizes : 1/2" NB - 48" NB
Wall Thickness Available : Schedule 10s - Schedule XXS
Dimension Standard: ANSI B16.9, MSS SP 43



Seamless, ERW, Fabricated

FORM:

  • Elbows in Long & Short Radius in 45 deg, 90 deg, 180 deg.
  • Return Bend, U Bend, Long Radius Bend.
  • Equal, Unequal Tee & Barred Tee.
  • Eccentric Reducer & Concentric Reducer.
  • Caps & Crosses.
  • Long & Short Stub End.
  • Swage Nipple & Barrel Nipple
  • Laterals
  •

VALUE ADDED SERVICES

  • Hot Dipped Galvanizing
  • Epoxy & FBE Coating
  • Electro Polish
  •

TEST CERTIFICATE
Manufacturer Test Certificate as per EN 10204 / 3.1B



A403 WPS31254 Stainless Steel Elbow Chemical Composition

Element Content (%)
Iron, Fe 55.69
Chromium, Cr 20
Nickel, Ni 18
Molybdenum, Mo 6.1
Nitrogen, N 0.20
Carbon, C 0.010



A403 WPS31254 Stainless Steel Elbow Mechanical Properties

Properties Metric Imperial
Tensile strength 680 MPa 98600 psi
Yield strength 300 MPa 43500 psi
Modulus of elasticity 195 GPa 28300 ksi
Shear modulus 75 GPa 10900 ksi
Poisson’s ratio 0.30 0.30
Elongation at break 50 % 50 %
Hardness, Brinell 210 210
