Common Carbon Structural Steel Plate / Stainless Steel Plate S235JR A283 Grade C

  • Common Carbon Structural Steel Plate / Stainless Steel Plate S235JR A283 Grade C
  • Common Carbon Structural Steel Plate / Stainless Steel Plate S235JR A283 Grade C
  • Common Carbon Structural Steel Plate / Stainless Steel Plate S235JR A283 Grade C
  • Common Carbon Structural Steel Plate / Stainless Steel Plate S235JR A283 Grade C
  • Common Carbon Structural Steel Plate / Stainless Steel Plate S235JR A283 Grade C
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number S235JR,A283 Grade C,A36,St37-2,A537 Grade 70,SS400,SM400A
Minimum Order Quantity 1 ton
Price Depending on quantity
Packaging Details PLY-WOODEN CASE OR PALLET
Delivery Time 10-100 days depending on quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 10000 Tons per month
Product Details
Product Name Carbon Steel Plate Product Type Steel Plate
Rolling Range Thickness*Width*Length 2-700mm*1220-4200mm*5000-18000mm Test Ultrasonic Examination,Normalized,Quenched And Tempered,HIC,SSCC And Third Party Inspections By End User.
Main Steel Grades S235JR,A283 Grade C,A36,St37-2,A537 Grade 70,SS400,SM400A Steel Standard ABS,LR,DNV,BV,GL,CCS,KR,NK,RINA
Additional Service Shot Blasting And Painting,Cutting And Welding As Per User's Request Application Carbon Steel Plates Are Used To Produce Structural Parts Of The Bolted And Welded Steel In Dustrial Area
Highlight

Stainless Steel Coils

,

Stainless Steel Flat Sheets
Leave a Message
Product Description

Carbon Steel Plate, Common Carbon Structural Steel Plate S235JR, A283 Grade C, A36, St37-2, A537 Grade 70, SS400, SM400A





Steel Name: Carbon steel plate,Common carbon structural steel plate

Main steel grades: S235JR,A283 Grade C,A36,St37-2,A537 Grade 70,SS400,SM400A

Steel standard: EN 10025,DIN 17100,DIN 17102,ASTM,GB/T700,JIS G3106

Main application:Carbon steel plates are used to produce structural parts of the bolted and welded steel in dustrial area.

Rolling range: Thickness*Width*Length  2-700mm*1220-4200mm*5000-18000mm

Surface Treatment: Hot rolled and Coated

Test: Ultrasonic examination,Normalized,Quenched and Tempered,HIC,SSCC and Third party inspections by end user.

Supply Ability: 10000 Tons per month

Additional service:Shot blasting and painting,Cutting and welding as per user’s request.



S235JRG2 steel plate Chemical analysis -% by mass*

Chemical elements

C≤ 16mm max

C>16mm max

Si max

Mn max

P max.

S max.

%,by mass

0.17

0.17

--

1.40

0.045

0.045

S235JRG2 steel sheet Mechanical properties

thickness

Yield Strength ReH[N/mm2]
transv.min.

Tensile
Strength
Rm[N/mm2]transv.

Fracture Elongation[%]transv. min.

Notch mpactEnergy1)
Ch Vcomplete samplelongitud. min [J]

t≤ 16mm t >16mm

235 225





Degree: 20
AV: 27J

t< 3mm t ≥ 3mm



360-510 340-470



Up to 1.5mm
1.51-2.00mm
2.01-2.50mm
2.51-2.99mm
≥ 3mm





16
17
18
19
24



Common Carbon Structural Steel Plate / Stainless Steel Plate S235JR A283 Grade C

Want to get more information about Clad steel plate,please CONTACT TOBO  NOW



Other steel products we can offer:

Carbon steel plate   Boiler steel plate  High strength steel plate

Shipbuilding steel plate  Oil platform steel plate  Low alloy steel plate

Pipeline steel plate  Angle steel  Bulb flat steel  Flat bar  Stainless steel plate

Clad steel plate  Galvanized steel plate  Channel Steel  Weathering steel plate

Seamless steel pipe   Extra High strength ship plate



All steel grades for Carbon steel plates we can offer as follows:



STANDARD

               STEEL            GRADE

EN10025

S235JR,S235J0,S235J2

DIN 17100

DIN 17102

St33,St37-2,Ust37-2,RSt37-2,St37-3

StE255,WstE255,TstE255,EstE255

ASTM











ASME

A36/A36M     A36

A283/A283M

A283 Grade A,A283 Grade B,A283 Grade C,A283 Grade D

A573/A573M

A573 Grade 58,A573 Grade 65,A573 Grade 70



SA36/SA36M   SA36

SA283/SA283M

SA283 Grade A,SA283 Grade B,SA283 Grade C,SA283 Grade D

SA573/SA573M

SA573 Grade 58,SA573 Grade 65,SA573 Grade 70

GB/T700

Q235A,Q235B,Q235C,Q235D,Q235E

JIS G3106

SS330,SS400,SS490,SS540,SM400A,SM400B,SM400C
