Seamless Stainless Steel Elbow Butt Weld Elbows A403 WP321 WP317L, WP321

  • Seamless Stainless Steel Elbow Butt Weld Elbows A403 WP321 WP317L, WP321
  • Seamless Stainless Steel Elbow Butt Weld Elbows A403 WP321 WP317L, WP321
  • Seamless Stainless Steel Elbow Butt Weld Elbows A403 WP321 WP317L, WP321
  • Seamless Stainless Steel Elbow Butt Weld Elbows A403 WP321 WP317L, WP321
  • Seamless Stainless Steel Elbow Butt Weld Elbows A403 WP321 WP317L, WP321
Place of Origin CHINA
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number A403 WP321 WP317L, WP321, WP347 / WPS31254
Minimum Order Quantity 1PC
Price USD1-60 PER PC
Packaging Details PLY-WOODEN CASE OR PALLET
Payment Terms T/T, Western Union, L/C
Supply Ability 9000000PCS PER MONTH
Product Details
Elbow 45 Deg, 90 Deg, 180 Deg, Long Redius, Short Redius Outer Diameter 15MM-2400MM
Type R=1D,1.5D,3D, 5D, 6D, 8D, 10D & 20D.
Highlight

Pipe Fittings Elbow

,

Butt Welding Elbow
Leave a Message
Product Description



Long Radius Elbow Seamless Stainless Steel Elbow A403 WP321 WP317L, WP321, WP347 /  WPS31254





1) seamless, single-slit tube wall thickness: 1 / 2 "NPS Sch5S to 24" OD x 30mm
2) double-slit tube wall thickness: from 10 "to 58" OD x 30mm

Manufacturing standards:

1) ASTM ASME A/SA 403 MSS SP43 & SP75  ANSI B16.9  ANSI B16.28  ASTM A815   ASTM B363 B366
2) DIN2605 DIN2615 DIN2616 DIN2617
3) GB12459 GB13401
4) JIS2313

Process: stainless steel, nickel copper used cold, Mandrel molding (elbow can minimize thickness thinning) Using carbon steel, and other thermal processing, forming within Mandrel


Dimensions: seamless 1 / 2 "-20" (DN15 - DN500), a slit 1 / 2 "-48" (DN15 - DN1200)

Standards:GB/T12459, GB/T13401,SH3408,SH3409,HG/T21635,
      HG/T21631,ASME B16.9,MSS SP-43,DIN 2605,JIS B2313

Thickness:SCH5S-SCH160

material: stainless steel, nickel copper, carbon steel and low alloy steel, alloy steel





ASME B16.9

 size

Outer Diameter
(OD)

Wall thickness (T)

90o L / R Elbow center to tail A

45o L / R center to bend the tail end B

90o S / R to the end of A Center Elbow

 Three links to the Center for the tail end C.M

The length of the cap
E

Sch.5S

Sch.10S

Sch.40S

Sch.80S

1/2

0.840

0.065

0.083

0.109

0.147

1.50

0.625

-

1.00

1.00

3/4

1.050

0.065

0.083

0.113

0.154

1.12

0.438

-

1.13

1.00

1

1.315

0.065

0.109

0.133

0.179

1.50

0.875

1.00

1.50

1.50

1-1/4

1.660

0.065

0.109

0.140

0.191

1.88

1.00

1.25

1.88

1.50

1-1/2

1.900

0.065

0.109

0.145

0.200

2.25

1.12

1.50

2.25

1.50

2

2.375

0.065

0.109

0.154

0.218

3.00

1.38

2.00

2.50

1.50

2-1/2

2.875

0.083

0.120

0.203

0.276

3.75

1.75

2.50

3.00

2.00

3

3.500

0.083

0.120

0.216

0.300

4.50

2.00

3.00

3.38

2.50

4

4.500

0.083

0.120

0.237

0.337

6.00

2.50

4.00

4.13

3.00

5

5.563

0.109

0.134

0.258

0.375

7.50

3.12

5.00

4.88

3.50

6

6.625

0.109

0.134

0.280

0.432

9.00

3.75

6.00

5.63

4.00

8

8.625

0.109

0.148

0.322

0.500

12.00

5.00

8.00

7.00

5.00

10

10.750

0.134

0.165

0.375

0.500

15.00

6.25

10.00

8.50

6.00

12

12.750

0.156

0.180

0.375

0.500

18.00

7.50

12.00

10.00

7.00

14

14.000

0.156

0.250

0.375

0.500

21.00

8.75

14.00

11.00

7.50

16

16.000

0.165

0.250

0.375

0.500

24.00

10.00

16.00

12.00

8.00

18

18.000

0.165

0.250

0.375

0.500

27.00

11.25

18.00

13.50

9.00

20

20.000

0.188

0.250

0.375

0.500

30.00

12.50

20.00

15.00

10.00

24

24.000

0.218

0.250

0.375

0.500

36.00

13.50

24.00

17.00

12.00

Applications range: For use in the petroleum, smelting, foodstuff, power, papermaking, chemical, medical equipment, aviation, boiler heat exchanger, and other fields.
Note:Providing customers with customerized composition,size,package.



Seamless Stainless Steel Elbow Butt Weld Elbows A403 WP321 WP317L, WP321

Tags:

Stainless Steel 90 Degree Elbow

Pipe Fittings Elbow

Butt Welding Elbow
