Incoloy 825 stainless steel plate (NS 142/UNS NO8825) JIS, AISI, ASTM, GB, DIN, EN

  • Incoloy 825 stainless steel plate (NS 142/UNS NO8825) JIS, AISI, ASTM, GB, DIN, EN
  • Incoloy 825 stainless steel plate (NS 142/UNS NO8825) JIS, AISI, ASTM, GB, DIN, EN
  • Incoloy 825 stainless steel plate (NS 142/UNS NO8825) JIS, AISI, ASTM, GB, DIN, EN
  • Incoloy 825 stainless steel plate (NS 142/UNS NO8825) JIS, AISI, ASTM, GB, DIN, EN
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number (NS 142/UNS NO8825
Minimum Order Quantity 1 Ton/Tons neogotiationTrial Order
Price US $ 1,000 - 3,000 / Ton
Packaging Details Wooden Cases
Delivery Time delivery time is according to the actual order
Payment Terms L/C, T/T, Western Union
Supply Ability 3000 Ton/Tons per Week neogotiation
Product Details
Product Name Incoloy 825 Stainless Steel Plate (NS 142/UNS NO8825) Product Type Nickel Plate
Standard AISI, ASTM, BS, DIN, GB, JIS Grade Incoloy 825
Ultimate Strength (≥ MPa) 500 Ni (Min) 38
Elongation (≥ %) 25 Application Chemical And Petroleum Processing Equipment
Highlight

Stainless Steel Coils

,

Thin Stainless Steel Sheet
Leave a Message
Product Description

Incoloy 825 stainless steel plate (NS 142/UNS NO8825) JIS, AISI, ASTM, GB, DIN, EN



Quick Details

Quick Details

Place of Origin:
Shanghai, China (Mainland)
 Type:
Nickel Plate
 Application:
chemical and petroleum processing equipment
Grade:
incoloy 825
 Ni (Min):
38
 Powder Or Not:
Not Powder
Ultimate Strength (≥ MPa):
500
 Elongation (≥ %):
25
 Model Number:
Incoloy 825
Brand Name:
TOBO

Packaging & Delivery

Packaging Details: Export standards or customer requirement
Delivery Detail: 10-20 days

Specifications

Special alloy:Incoloy 825
Type:wire,bar,pipe,ring,disc,plate,strip
Material:incoloy800H,incoloy901,incoloy925,incoloy926

                           Bar



          Incoloy 825 stainless steel plate (NS 142/UNS NO8825)



                          Pipe

Incoloy 825 stainless steel plate (NS 142/UNS NO8825)





                            Ring                                                      Disc

 Incoloy 825 stainless steel plate (NS 142/UNS NO8825)     Incoloy 825 stainless steel plate (NS 142/UNS NO8825)



                         Plate



Incoloy 825 stainless steel plate (NS 142/UNS NO8825)





Incoloy 825 Chemical composition:

Alloy

%

Ni

Cr

Fe

C

Mn

Si

Cu

Mo

Al

Ti

P

S

825

Min.

38

19.5

balance







1.5

2.5

1.0

0.6





Max.

46

23.5

balance

0.05

1

0.5

3

3.5

0.2

1.2

0.02

0.03


Incoloy 825 Physical properties

Density

8.1 g/cm³

Melting point

1370-1400°C


Incoloy 825 Alloy mi nimum mechanical properties in the room temperature

Alloy state

Tensile strength
Rm N/mm²

Yield strength
R P0. 2N/mm²

Elongation
A 5 %

Brinell hardness
HB

825

550

220

30

≤200



Characteristic as below :
1. Good stress corrosion cracking resistance performance
2. Good resistance for pitting and crevice corrosion performance
3. Good anti-oxidation and non-oxidzing heat acid performance
4. Good mechanical performance in both room temperature and up to 550°C
5. Have the pressure vessel authenticate when manufacture temperature up to 450°C



Incoloy 825 Metallurgical structure:
825 is the face-centered cubic lattice structure.



Incoloy 825 Corrosion resistance
825 is an all-purpose project alloy, have good corrosion resistance of the acid and alkali metal property in both oxidation and reduction environments. High nickel content made it with effective stress corrosion cracking resistance performance. 825 have excellent corrosion resistance in different kinds of media, such as sulfuric acid, phosphoric acid, nitric acid and organic acid, alkali metal such as sodium hydroxide, potassium hydroxide, and hydrochloric acid. A variety of media corrosion of nuclear-burning dissolver show 825 high integrated prpperty, like sulfuric acid, nitric acid and potassium hydroxide are all dealing in a same device.




Incoloy 825 Application field:
825widely use in many kinds of industry field that the working temperature no more than 550°C.


Incoloy 825 Typical application field:
1. Sulfuric acid factory usage for heating pipe, container, basket, chain and so on.
2. Cooling heat exchanger, marine product pipeline system and gas pipeline of acidic environment.
3. Heat exchanger, steam machine, washing, impregnation pipe, etc. for phosphoric acid produce
4. Oil refining in the air heat exchanger
5. Food project
6. Chemical process
7. Application of high pressure oxygen flam-retardant alloy
