ASTM A420 WPL3 / WPL6 / WPL9 But Weld Fittings Elbow 45 Deg 90 Deg Elbow 10” SCH80

  • ASTM A420 WPL3 / WPL6 / WPL9 But Weld Fittings Elbow 45 Deg 90 Deg Elbow 10” SCH80
  • ASTM A420 WPL3 / WPL6 / WPL9 But Weld Fittings Elbow 45 Deg 90 Deg Elbow 10” SCH80
  • ASTM A420 WPL3 / WPL6 / WPL9 But Weld Fittings Elbow 45 Deg 90 Deg Elbow 10” SCH80
  • ASTM A420 WPL3 / WPL6 / WPL9 But Weld Fittings Elbow 45 Deg 90 Deg Elbow 10” SCH80
  • ASTM A420 WPL3 / WPL6 / WPL9 But Weld Fittings Elbow 45 Deg 90 Deg Elbow 10” SCH80
Place of Origin CHINA
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number ASTM A420 WPL3 / WPL6 / WPL9
Minimum Order Quantity 5PCS
Price Negotiation
Packaging Details PLY-WOODEN CASE OR PALLET
Delivery Time 15DAYS
Payment Terms T/T, L/C, Western Union
Supply Ability 9980000PCS Per Month
Product Details
Products Name Butt Weld Fittings Elbow ,reducer,tee,stub End ,cap Material ASTM A420 WPL3 / WPL6 / WPL9
Thickness Sch5-Sch160, STD, XS, XXS Standard ANSI/ASTM B16.9
Surface Finish Sand Blast, Black Painting, Galvanizing Finish Manufacturing Process Push, Press, Forge, Cast, Etc.
Application Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding Etc
Highlight

butt welded pipe fittings

,

industrial pipe fittings
Leave a Message
Product Description

ASTM A420 WPL3 / WPL6 / WPL9 But Weld Fittings Elbow 45 Deg 90 Deg Elbow 10” SCH80







Specifications



1.Butt weld fittings
2.sch5s-schxxs
3.ISO9001,ISO9000
4.Market:America,Africa,Middle East,Southeast of Asia



 Type

Butt weld fittings elbow ,reducer,tee,stub end ,cap



Standard

ASME/ANSI B16.9



Size

1/2’’~48’’(Seamless);16’’~72’’(Welded)

Wall thickness

Sch5~Sch160XXS



Manufacturing process

Push, Press, Forge, Cast, etc.



Material

Carbon steel, stainless steel, alloy steel, duplex stainless, nickel alloy steel



1)  wall thickness: 1 / 2 "NPS Sch5S to 24" OD x 30mm
2)  wall thickness: from 10 "to 58" OD x 30mm

Manufacturing standards:

1)ASTM ASME A/SA 403 MSS SP43 & SP75  ANSI B16.9  ANSI B16.28  ASTM A815   ASTM B363 B366
2)DIN2605 DIN2615 DIN2616 DIN2617
3)GB12459 GB13401
4)JIS2313

Process: stainless steel, nickel copper used cold, Mandrel molding (elbow can minimize thickness thinning) Using carbon steel, and other thermal processing, forming within Mandrel


Dimensions: seamless 1 / 2 "-20" (DN15 - DN500), a slit 1 / 2 "-48" (DN15 - DN1200)

Standards:GB/T12459, GB/T13401,SH3408,SH3409,HG/T21635,
      HG/T21631,ASME B16.9,MSS SP-43,DIN 2605,JIS B2313

Thickness:SCH5S-SCH160

material: stainless steel, nickel copper, carbon steel and low alloy steel, alloy steel







carbon steel 45º elbow carbon steel 45º elbow carbon steel 45º elbow

Product name : carbon steel 45º elbow
Item : buttweld-Elbow
Details :
Nominal Diameter
Outside Diameter
at Bevel

Center to End

Center to Center

Back to Face


45°Elbow


  90°Elbow

180°Elbow
B
       A
      O
       K

DN

NPS
Series A
Series B

Long
Radius

Long
Radius

Short
  Radius

Long
Radius

Short
  Radius

Long
Radius

Short
  Radius
15
 1/2
21.3
18
16
38
-
76
-
48
-
20
 3/4
26.9
25
19
38
-
76
-
51
-
25
 1
33.7
32
 22
38
25
76
51
56
41
32
 1.1/4
42.4
38
25
48
32
95
64
70
52
40
 1.1/2
48.3
45
29
57
38
114
76
83
62
50
 2
60.3
57
35
76
51
152
102
106
81
65
 2.1/2
76.1(73)
76

44
95
64
190
127
132
100
80
 3
88.9
89
51
114
76
229
152
159
121
90
 3.1/2
101.6
-
57
133
89
267
178
184
140
100
 4
114.3
108
64
152
102
305
203
210
159
125
 5
139.7
133
79
190
127
381
254
262
197
150
 6
168.3
159
95
229
152
457
305
313
237
200
 8
219.1
219
127
305
203
610
406
414
313
250
 10
273.0
273
159
381
254
762
508
518
391
300
 12
323.9
325
190
457
305
914
610
619
467
350
 14
355.6
377
222
533
356
1067
711
711
533
400
 16
406.4
426
254
610
406
1219
813
813
610
450
 18
457.2
478
286
686
457
1372
914
914
686
500
 20
508.0
529
318
762
508
1524
1016
1016
762
550
 22
559
-
343
838
559
 1676 1118 1118 838
600
 24
610
630
381
914
610
 1829 1219 1219 914
650
 26
660
-
406
991
660
 1982 1320 - -
700
 28
711
720
438
1067
711
 2134 1422 - -
750
 30
762
-
470
1143
762
 2286 1524 - -
800
 32
813
820
502
1219
813
 2438 1626 - -
850
 34
864
-
533
1295
864
 2590 1728 - -
900
 36
914
920
565
1372
914
 2744 1828 - -
950
 38
965
-
600
1448
965
 2896 1930 - -
1000
 40
1016
1020
632
1524
1016
 3048 2032 - -
1050
 42
1067
-
660
1600
1067
 3200 2134 - -
1100
 44
1118
1120
695
1676
1118
 3352 2236 - -
1150
 46
1168
-
727
1753
1168
 3506 2336 - -
1200
 48
1220
1220
759
1829
1219
 3658 2440 -
